Goodrive350 series high-performance multifunction VFD
Function
code
P01.20 Wake-up-from-sleep delay
P01.21 Restart after power cut
The value specified in "Description" or "Default value" contains one decimal, so the fieldbus scale is
10. If the value received by the upper computer is 50, the value of "Wake-up-from-sleep delay" of the
VFD is 5.0 (5.0=50/10).
To set the "Wake-up-from-sleep delay" to 5.0s through Modbus communication, you need first to
multiply 5.0 by 10 according to the scale to obtain an integer 50, that is, 32H in the hexadecimal form,
and then transmit the following write command:
01
VFD
address
After receiving the command, the VFD converts 50 into 5.0 based on the fieldbus scale, and then sets
"Wake-up-from-sleep delay" to 5.0s.
For another example, after the upper computer transmits the "Wake-up-from-sleep delay" parameter
read command, the master receives the following response from the VFD:
01
VFD
address
The parameter data is 0032H, that is, 50, so 5.0 is obtained based on the fieldbus scale (50/10=5.0).
In this case, the master identifies that the "Wake-up-from-sleep delay" is 5.0s.

9.4.7 Error message response

Operation errors may occur in communication-based control. For example, some parameters can
only be read, but a write command is transmitted. In this case, the VFD returns an error message
response.
Error message responses are transmitted by the VFD to the master. The following table describes the
codes and definitions of the error message responses.
Code Name
Invalid
01H
command
Name
0.0–3600.0s (valid when P01.19 is 2)
0: Restart is disabled
1: Restart is enabled
06 01 14 00 32
Parameter
Write
command address
03 02
Read 2-byte
command data
The command code received by the upper computer is not allowed
to be executed. The possible causes are as follows:
• The function code is applicable only on new devices and is not
implemented on this device.
• The slave is in the faulty state when processing this request.
Description
Parameter
data
00 32
Parameter
data
Definition
-279-
Communication
Default
value
0.0s
49 E7
CRC
39 91
CRC
