Goodrive20-UL Series VFD
Function
Name
code
Max.
P03.24
voltage limit
Pre-exciting
P03.25
time
Weakenin
g
P03.26
proportion
al gain
Speed
display
P03.27 selection
of vector
control

P04 group SVPWM control

Function
Name
code
V/F curve
P04.00
setting
P03.24 set the Max. Voltage of the VFD, which
is dependent on the site situation.
Setting range: 0.0–120.0%
Pre-activate the motor when the VFD starts up.
Build up a magnetic field inside the VFD to
improve the torque performance during the
starting process.
Setting time: 0.000–10.000s
0–8000
0: Display at the actual value
1: Display at the setting value
Description
These function codes define the V/F curve of
Goodrive20-UL motor 1 to meet the need of
different loads.
0: Straight line V/F curve; applying to the
constant torque load
1: Multi-dots V/F curve
2: 1.3th power low torque V/F curve
3: 1.7th power low torque V/F curve
4: 2.0th power low torque V/F curve
Curves 2–4 apply to the torque loads such as
fans and water pumps. Users can adjust
according to the features of the loads to get the
best performance.
5: Customized V/F (V/F separation); in this
mode, V can be separated from f and f can be
adjusted through the frequency reference
channel set by P00.06 or the voltage reference
channel set by P04.27 to change the feature of
Description
-48-
Function parameters
Default Modify
◎
100.0%
○
0.300s
○
1200
○
0
Default Modify
◎
0
