Goodrive350 series high-performance multifunction VFD
P15––Functions of communication extension card 1
Function
Name
code
P15.00–
See the operation manual of communication extension card for details
P15.27
P15.28 Master/slave
CAN
communication
address
P15.29 Master/slave
CAN
communication
baud rate
selection
P15.30 Master/slave
CAN
communication
timeout period
P15.31–
See the operation manual of communication extension card for details
P15.69
P16––Functions of communication extension card 2
Function
Name
code
P16.00–
See the operation manual of communication extension card for details
P16.23
Identification
time for the
P16.24
extension card in
card slot 1
Identification
time for the
P16.25
extension card in
card slot 2
Identification
time for the
P16.26
extension card in
card slot 3
Communication
P16.27
timeout period of
Description
0–127
0: 50Kbps
1: 100 Kbps
2: 125Kbps
3: 250Kbps
4: 500Kbps
5: 1M bps
0.0 (invalid)–300.0s
Description
0.0–600.0s
If it is set to 0.0, identification fault will not be
detected
0.0–600.0s
If it is set to 0.0, offline fault will not be detected
0.0–600.0s
If it is set to 0.0, offline fault will not be detected
0.0–600.0s
If it is set to 0.0, offline fault will not be detected
-203-
Function parameter list
Default
Modify
value
◎
1
◎
2
○
0.0s
Default
Modify
value
0.0s 0.0
0.0s 0.0
0.0s /
0.0s /
