INVT Goodrive350 Series Operation Manual page 156

Goodrive350 series high-performance multifunction VFD
Function
Name
code
coefficient
Corresponding
frequency of high
P03.31
speed friction
torque
Torque control
P03.32
enable
Flux weakening
P03.33
integral gain
P03.34 Reserved
Control
P03.35 optimization
setting
Speed loop
P03.36
differential gain
High-frequency
current loop
P03.37
proportional
coefficient
High-frequency
current loop
P03.38
integral
coefficient
Current loop
P03.39 high-frequency
switch-over point
P03.40 Inertia
Description
P03.29–400.00Hz
0:Disable
1:Enable
0–8000
0–65535
0–0x1111
Ones place: Torque command selection
0: Torque reference
1: Torque current reference
Tens place: Reserved
0: Reserved
1: Reserved
Hundreds place: Whether to enable ASR integral
separation
0: Disable
1: Enable
Thousands place: Reserved
0: Reserved
1: Reserved
0.00–10.00s
Under closed-loop vector control mode (P00.00=3)
and P03.39, the current loop PI parameters are
P03.09 and P03.10; above P03.39, the PI
parameters are P03.37 and P03.38.
Setting range of P03.37: 0–65535
Setting range of P03.38: 0–65535
Setting range of P03.39: 0.0–100.0% (relative to
max. frequency)
0: Disable
-147-
Function parameter list
Default
Modify
value
○
50.00Hz
◎
0
○
1200
●
0
○
0x0000
○
0.00s
○
1000
○
1000
○
100.0%
○
0
