Goodrive350 series high-performance multifunction VFD
Function
code
P08.08 Deceleration time at jogging 0.0–3600.0s
P08.00 Acceleration time 2
P08.01 Declaration time 2
P08.02 Acceleration time 3
P08.03 Declaration time 3
P08.04 Acceleration time 4
P08.05 Declaration time 4
Switching frequency of
P08.19 acceleration/deceleration
Reference frequency of
P08.21 acceleration/deceleration
P08.28 Automatic fault reset times
Automatic fault reset time
P08.29

5.5.8 Frequency setup

The VFD supports multiple kinds of frequency reference modes, which can be categorized into two
types: main reference channel and auxiliary reference channel.
There are two main reference channels, namely A frequency reference channel and B frequency
reference channel. These two channels support simple arithmetical operation between each other,
and they can be switched dynamically by setting multi-function terminals.
There is one input mode for auxiliary reference channel, namely terminal UP/DOWN switch input. By
setting function codes, you can enable the corresponding reference mode and the impact made on
the VFD frequency reference by this reference mode.
The VFD actual reference is comprised of the main reference channel and auxiliary reference
Name
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.00–P00.03 (Max. output frequency)
0.00Hz: No switch over
If the running frequency is larger than
time P08.19, switch to acceleration
/deceleration time 2
0: Max. output frequency
1: Set frequency
2: 100Hz
time Note: Valid for straight-line
acceleration/deceleration only
0–10
0.1–3600.0s
interval
Description
-82-
Basic operation instructions
Default
value
Depends
on model
Depends
on model
Depends
on model
Depends
on model
Depends
on model
Depends
on model
Depends
on model
0
0
0
1.0s
