Goodrive350 series high-performance multifunction VFD
Function
Name
code
Angle
compensation
P18.29 value of
synchronous
motor
P18.30 Reserved
Pulse reference
P18.31
Z pulse value
Pulse-given main
control board
P18.32
measured speed
value
Pulse-given PG
P18.33 card measured
speed value
Present encoder
P18.34
filter width
P18.35 Reserved
P19––Extension card state check
Function
Name
code
Type of card at
P19.00
slot 1
Type of card at
P19.01
slot 2
Type of card at
P19.02
slot 3
Description
-180.0–180.0
0–65535
0–65535
-3276.8–3276.7Hz
-3276.8–3276.7Hz
0–63
0–65535
Description
0–65535
0: No card
1: PLC programmable card
2: I/O card
3: Incremental PG card
4: Incremental PG card with UVW
5: Ethernet communication card
6: DP communication card
7: Bluetooth card
8: Resolver PG card
9: CANopen communication card
10: WIFI card
11: PROFINET communication card
12: Sine/Cosine PG card without CD signal
13: Sine/Cosine PG card with CD signal
14: Absolute encoder PG card
15: CAN master/slave communication card
-211-
Function parameter list
Default
Modify
value
●
0.00
●
0
●
0
●
0.0Hz
●
0.0Hz
●
0
●
0
Default
Modify
value
●
0
●
0
●
0
