reactor according to the following table. If the distance is longer than 100 m, contact INVT's technical
support technicians.
DC reactors can be directly connected to VFDs of 380 V, 132 kW or higher and the 660 V series. DC
reactors can improve the power factor, avoid damage to bridge rectifiers caused due to large input
current of the VFD when large-capacity transformers are connected, and also avoid damage to the
rectification circuit caused due to harmonics generated by grid voltage transients or phase-control
loads.
Input reactor
VFD model
GD350-1R5G-4
GD350-2R2G-4
GD350-004G-4
GD350-5R5G-4
GD350-7R5G-4
GD350-011G-4
GD350-015G-4
GD350-018G-4
GD350-022G-4
GD350-030G-4
GD350-037G-4
GD350-045G-4
GD350-055G-4
GD350-075G-4
GD350-090G-4
GD350-110G-4
GD350-132G-4
GD350-160G-4
GD350-185G-4
Table D.5 Reactors for AC 3PH 380V (-15%)–440V (+10%)
DC reactor
Input reactor
ACL2-1R5-4
ACL2-2R2-4
ACL2-004-4
ACL2-5R5-4
ACL2-7R5-4
ACL2-011-4
ACL2-015-4
ACL2-018-4
ACL2-022-4
ACL2-037-4
ACL2-037-4
ACL2-045-4
ACL2-055-4
ACL2-075-4
ACL2-0110-4
ACL2-110-4
ACL2-160-4
ACL2-160-4
ACL2-200-4
-345-
Optional peripheral accessories
Output reactor
DC reactor Output reactor
/ OCL2-1R5-4
/ OCL2-2R2-4
/ OCL2-004-4
/ OCL2-5R5-4
/ OCL2-7R5-4
/ OCL2-011-4
/ OCL2-015-4
/ OCL2-018-4
/ OCL2-022-4
/ OCL2-037-4
/ OCL2-037-4
/ OCL2-045-4
/ OCL2-055-4
/ OCL2-075-4
/ OCL2-110-4
/ OCL2-110-4
DCL2-132-4 OCL2-200-4
DCL2-160-4 OCL2-200-4
DCL2-200-4 OCL2-200-4
