Goodrive350 series high-performance multifunction VFD
4.2.6 Vertical installation
Note: During vertical installation, you must install windshield, otherwise, the VFD will experience
mutual interference, and the heat dissipation effect will be degraded.
Cold
air
Hot
air
Cold
air
Hot
air
Figure 4.5 Vertical installation
-19-
Windshield
Windshield
Installation guide
