INVT Goodrive350 Series Operation Manual page 94

Goodrive350 series high-performance multifunction VFD
Function
code
Reference object of B
P00.08
frequency command
Combination mode of setup
P00.09
Function of multi-function
P05.01–
digital input terminal (S1–S4,
P05.06
P08.42
P08.43
P08.44 UP/DOWN terminal control
Name
source
HDIA, HDIB)
Reserved
Reserved
Description
9: PROFIBUS/CANopen/DeviceNet
communication
10: Ethernet communication
11: High speed pulse HDIB
12: Pulse string AB
13: EtherCAT/PROFINET
communication
14: PLC card
15: Reserved
0: Max. output frequency
1: A frequency command
0: A
1: B
2: (A+B)
3: (A-B)
4: Max (A, B)
5: Min (A, B)
10: Frequency increase (UP)
11: Frequency decrease (DOWN)
12: Clear frequency increase/decrease
setting
13: Switch-over between setup A and
setup B
14: Switch-over between combination
setup and setup A
15: Switch-over between combination
setup and setup B
/
/
0x000–0x221
Ones: Frequency enabling selection
0: UP/DOWN terminal setting is valid
1: UP/DOWN terminal setting is invalid
Tens: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency modes
2: Invalid for multi-step speed when
multi-step speed takes priority
-85-
Basic operation instructions
Default
value
0
0
/
/
/
0x000
