INVT Goodrive350 Series Operation Manual page 238

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Encoder pulse
P24.18
filter width
Pulse reference
P24.19
filter width
Pulse number of
P24.20
pulse reference
Enable angle
compensation of
P24.21
synchronous
motor
Switch-over
frequency
threshold of
P24.22
speed
measurement
mode
Synchronous
motor angle
P24.23
compensation
coefficient
P24.24 Reserved
Description
1: Filter
Bit3: Reserved
Bit4: Enable/disable pulse reference filter
0: No filter
1: Filter
Bit5: Pulse reference filter mode
0: Self-adaptive filter
1: Use P24.19 filter parameters
Bit6: Frequency-divided output source setting
0: Encoder signals
1: Pulse reference signals
Bits7–15: Reserved
0–63
The filtering time is P24.18×0.25 μs. The value 0
or 1 indicates 0.25 μs.
0–63
The filtering time is P24.19×0.25 μs. The value 0
or 1 indicates 0.25 μs.
0–65535
0–1
0–630.00Hz
-200.0–200.0%
0–65535
-229-
Function parameter list
Default
Modify
value
○
2
○
2
◎
1024
○
0
○
1.00Hz
○
100.0%
○
0
