INVT Goodrive350 Series Operation Manual page 90

Goodrive350 series high-performance multifunction VFD
Function
code
Waiting time of restart after
P01.22
P01.23
P01.24 Stop speed delay
Open-loop 0Hz output
P01.25
Deceleration time of
P01.26
Time of starting section of
P01.27
deceleration S curve
Time of ending section of
P01.28
deceleration S curve
P01.29 Short-circuit brake current
Hold time of short-circuit
P01.30
Hold time of short-circuit
P01.31
P01.32 Pre-exciting time of jogging
Starting frequency of braking
P01.33
for jogging to stop
P01.34 Delay to enter sleep
P05.01– Digital input function
P05.06
P08.06 Running frequency of jog
P08.07 Acceleration time at jogging
Name
power cut
Start delay
selection
emergency-stop
brake at startup
brake at stop
selection
Description
0.0–3600.0s (valid when P01.21 is 1)
0.0–60.0s
0.0–100.0s
0: No voltage output
1: With voltage output
2: Output as per DC brake current of stop
0.0–60.0s
0.0–50.0s
0.0–50.0s
0.0–150.0% (rated VFD current)
0.00–50.00s
0.00–50.00s
0–10.000s
0–P00.03
0–3600.0s
1: Forward running
2: Reverse running
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
21: Acceleration/deceleration time
selection 1
22: Acceleration/deceleration time
selection 2
30: Acceleration/deceleration disabled
0.00Hz–P00.03 (Max. output frequency)
0.0–3600.0s
-81-
Basic operation instructions
Default
value
1.0s
0.0s
0.0s
0
2.0s
0.1s
0.1s
0.0%
0.00s
0.00s
0.000s
0.00Hz
0.0s
/
5.00Hz
Depends
on model
