INVT Goodrive350 Series Operation Manual page 187

Goodrive350 series high-performance multifunction VFD
Function
Name
code
FDT1 level
P08.32
detection value
FDT1 lag
P08.33
detection value
FDT2 level
P08.34
detection value
FDT2 lag
P08.35
detection value
Detection value
P08.36 for frequency
arrival
Description
4: Switch over by EtherCAT/PROFINET
communication
Tens: Motor switch over during running
0: Disable switch over during running
1: Enable switch over during running
When the output frequency exceeds the
corresponding frequency of FDT level,
multi-function digital output terminal outputs
"frequency level detection FDT" signal, this signal
will be valid until the output frequency lowers to
below the corresponding frequency (FDT
level-FDT lag detection value), the waveform is
shown in the figure below.
Output frequency f
FDT level
Y1,
RO1, RO2
Setting range of P08.32: 0.00Hz–P00.03 (Max.
output frequency)
Setting range of P08.33: 0.0–100.0% (FDT1 level)
Setting range of P08.34: 0.00Hz–P00.03 (Max.
output frequency)
Setting range of P08.35: 0.0–100.0% (FDT2 level)
When the output frequency is within the positive
/negative detection range of the set frequency, the
multi-function digital output terminal outputs
"frequency arrival" signal as shown below.
-178-
Function parameter list
Default
50.00Hz
50.00Hz
FDT lag
Time t
Time t
0.00Hz
Modify
value
○
○
5.0%
○
○
5.0%
○
