Goodrive350 series high-performance multifunction VFD
Function
Name
code
constant-power
zone
Min.
flux-weakening
P03.23 point of
constant-power
zone
P03.24 Max. voltage limit
P03.25 Pre-exciting time
Flux-weakening
P03.26
proportional gain
Vector control
P03.27
speed display
Static friction
P03.28 compensation
coefficient
Corresponding
P03.29 frequency point
of static friction
High speed
P03.30 friction
compensation
Description
T
Min. flux-weakening limit of motor
P03.22 and P03.23 are valid during constant
power. When motor speed is above rated speed,
motor enters flux-weakening running state. The
flux-weakening control coefficient can change the
flux-weakening curvature, the larger the
coefficient, the steeper the curve, the smaller the
coefficient, the smoother the curve.
Setting range of P03.22: 0.1–2.0
Setting range of P03.23: 10%–100%
P03.24 sets the maximum output voltage of the
VFD, which is the percentage of rated motor
voltage. Set the value according to onsite
conditions.
Setting range:0.0–120.0%
Carry out motor pre-exciting during starting to build
a magnetic field inside the motor to improve the
torque characteristics of motor during starting.
Setting range: 0.000–10.000s
0–8000
0: Display as per actual value
1: Display as per the set value
0.0–100.0%
0.50– P03.31
0.0–100.0%
-146-
Function parameter list
Flux-weakening
coefficient of motor
0.1
1.0
2.0
f
Default
Modify
value
○
20%
○
100.0%
○
0.300s
○
1000
○
0
○
0.0%
○
1.00Hz
○
0.0%
