ADC AVIDIA SWD4573I1 User Manual

System configuration and management
Table of Contents

Advertisement

Quick Links

S
YSTEM
Catalog Number
SWD4573I1
Avidia
C
ONFIGURATION AND
U
SER
S
W
WITCH
M
ANUAL
V
ARE
ERSION
M
ANAGEMENT
2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVIDIA SWD4573I1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ADC AVIDIA SWD4573I1

  • Page 1 YSTEM ONFIGURATION AND WITCH Catalog Number SWD4573I1 Avidia ANUAL ERSION ANAGEMENT...
  • Page 2 Information contained in this document is company private to ADC DSL Systems, Inc., and shall not be modified, used, copied, reproduced or disclosed in whole or in part without the written consent of ADC.
  • Page 3 BOUT ANUAL This manual documents the new configuration and management features included in SwitchWare Version 2.0. This manual is intended for system engineers responsible for configuring and managing an Avidia System. It assumes a basic understanding of voice and data communications, including xDSL and ATM technologies.
  • Page 4: Document Conventions

    Document Conventions OCUMENT ONVENTIONS Two types of messages, identified by icons, appear throughout the document: Notes contain information about special circumstances. Cautions indicate the possibility of equipment damage or the possibility of personal injury. OMMAND NTERFACE The following typeface conventions are specific to the Command-Line Interface chapters of this manual.
  • Page 5: Web Interface Conventions

    NTERFACE The following typeface conventions are specific to the Web-Based Interface chapters of this manual. • This font indicates a reference to an element on the screen. • Italic type indicates the format in which you type the information specified in the procedure.
  • Page 6 Summary of Changes for Version 2.0 Avidia System Configuration and Management User Manual...
  • Page 7: Table Of Contents

    ABLE OF ONTENTS Part I: Introduction and Initial Setup ___________________________1 Chapter 1: Avidia System Configuration and Management Overview_______________ 3 Configuration Features ...4 Performance Monitoring Features ...6 System Administration and Diagnostic Features ... 7 Avidia System File Management ...8 Restoring System Files...8 How Image Files are Used ...8 How Configuration Files are Used...8 How Hardware Profile Files are Used ...9...
  • Page 8 Table of Contents Chapter 3: Applications and Configuration Overview ___________________________19 ATM...20 ATM Traffic Configuration...20 ATM Traffic Management ...22 ATM Device Addresses ...23 ATM Virtual Circuits ...24 Frame Relay Transmission ...26 SONET...28 Redundancy ...28 Dual Homing ...29 Line Card Redundancy ...32 Automatic Protection Switching ...33 Inband Management ...35 Inband to Avidia ...36...
  • Page 9 OAM Alarms and Loopbacks...57 About Alarm Surveillance... 57 About ATM Loopbacks ...58 OAM Location ID ... 59 Preparing to Run OAM Loopbacks...59 Example ATM-Layer Loopbacks ...61 After Running Loopbacks ... 68 Avidia Alarm Manager ...69 Configuring Avidia System Information...69 Setting Up Connections ... 70 DS1 Line/Management Combination Card...70 Frame-based Services...
  • Page 10 Table of Contents Chapter 5: Configuring System Parameters ___________________________________85 Configuring System Information ...86 Configuring the System Name ...86 Configuring the System Contact ...87 Configuring the System Location...88 Configuring the System Date and Time ...89 Configuring Boot File Information ...90 Displaying System Information...91 Configuring IP Addresses...91 Configuring the System IP Address, Subnet Mask and Default Gateway ...92 Configuring the Gateway IP Address...93...
  • Page 11 Configuring ADSL Alarm Profiles ... 104 Adding ADSL Alarm Profiles... 104 Displaying ADSL Alarm Profiles ... 105 Deleting ADSL Alarm Profiles ... 106 Configuring ADSL Handshaking ... 107 Setting Handshaking Parameters... 107 Displaying Handshaking Parameters ... 108 Configuring ADSL Service ... 109 Adding ADSL Port Configurations...
  • Page 12 Table of Contents Configuring SDSL Cell Service ...124 Adding SDSL Cell Port Configurations ...125 Displaying SDSL Cell Port Configurations ...126 Configuring IDSL Line Profiles ...127 Adding IDSL Line Profiles ...127 Displaying IDSL Line Profiles...128 Deleting IDSL Line Profiles...129 Configuring IDSL Alarm Profiles ...130 Adding IDSL Alarm Profiles ...130 Displaying IDSL Alarm Profiles ...131 Deleting IDSL Alarm Profiles...133...
  • Page 13 Chapter 8: Configuring ATM Virtual Circuits ________________________________ 153 Configuring ATM Traffic Profiles ... 154 Adding ATM Traffic Profiles ... 155 Displaying ATM Traffic Profiles... 156 Deleting ATM Traffic Profiles... 157 Configuring APS ... 158 Configuring APS ... 158 Issuing Manual APS Commands ... 159 Displaying APS Configuration ...
  • Page 14 Table of Contents Configuring ATM Routing ...196 Adding ATM Routing Table Entries...196 Displaying ATM Routing Table Entries ...197 Changing ATM Routing Admin Status...199 Deleting ATM Routing Table Entries ...199 Configuring ATM Policing...200 ATM Port Policing ...200 PVC Policing ...201 PVP Policing ...202 Chapter 9: Configuring Frame Relay Interworking ____________________________205 Configuring Frame Relay Links ...206 Adding a Frame Relay Link ...206...
  • Page 15 Chapter 10: Configuring Bridging and Routing _______________________________ 227 Configuring Bridging and Routing Sessions ... 228 Adding Sessions ... 228 Modifying Sessions ... 230 Displaying Sessions ... 233 Deleting Sessions ... 235 Configuring IP Routing ... 235 Adding IP Routing Table Entries... 236 Displaying the IP Routing Table...
  • Page 16 Table of Contents Configuring Global IP Routing Settings...251 Configuring Global IP Routing Settings ...251 Displaying Global IP Routing Settings ...251 Chapter 11: Configuring Subtended Systems _________________________________253 Adding a Subtended System ...254 Modifying a Subtended System Configuration ...255 Displaying Subtending Information...257 Chapter 12: Monitoring Subscriber Connections ______________________________259 Monitoring ADSL Performance ...260 Monitoring ADSL Loop Status ...260...
  • Page 17 Monitoring DS1/T1 Performance... 286 Monitoring DS3 Performance ... 289 Monitoring ATM Connection Statistics ... 292 ATM PVCC Connection Statistics... 292 ATM PVPC Connection Statistics ... 293 Monitoring APS Status... 295 Monitoring Frame Relay Performance Statistics ... 296 Monitoring Link Statistics... 296 Monitoring LMI Statistics...
  • Page 18 Table of Contents Chapter 16: Monitoring System Alarms and Status ____________________________327 Monitoring System Alarms and Events ...328 Monitoring SDSL Frame Alarms ...331 Monitoring SDSL Frame Alarm Status...331 Monitoring SDSL Frame Alarm History...333 Monitoring SDSL Cell Alarms ...334 Monitoring IDSL Alarm Status ...337 Monitoring System Hardware Status...339 Chapter 17: System Maintenance and Administration __________________________341 Configuring and Initiating OAM Loopbacks...342...
  • Page 19 Managing Security... 359 Adding User Accounts ... 359 Displaying User Accounts... 361 Modifying User Accounts ... 361 Deleting User Accounts ... 363 Changing a User Password... 364 Displaying System Inventory ... 364 Viewing SDSL Frame CPE general information ... 365 Rebooting Cards ...
  • Page 20 Table of Contents Chapter 20: Configuring Subscriber Services _________________________________385 Configuring ADSL Line Profiles...386 Configuring ADSL Alarm Profiles...388 Configuring ADSL Service ...391 Configuring SDSL Frame Line Profiles ...393 Adding SDSL Frame Line Profiles ...394 Deleting SDSL Frame Line Profiles ...394 Configuring SDSL Frame Alarm Profiles ...395 Adding SDSL Frame Alarm Profiles ...395 Deleting SDSL Frame Alarm Profiles...396 Configuring SDSL Frame Service...397...
  • Page 21 Chapter 22: Configuring ATM Virtual Circuits _______________________________ 427 Configuring ATM Traffic Profiles ... 428 Adding ATM Traffic Profiles ... 429 Deleting ATM Traffic Profiles... 430 Configuring APS ... 430 Configuring APS ... 431 Issuing Manual APS Commands ... 432 Configuring PVPCs ... 433 Adding Primary PVPCs ...
  • Page 22 Table of Contents Chapter 23: Configuring Frame Relay Interworking ___________________________467 The Frame Relay Interworking Configuration Table ...468 Adding a Frame Relay Configuration...470 Modifying a Frame Relay Configuration...475 Viewing an Entire Frame Relay Configuration ...478 Deleting a Frame Relay Configuration...483 Chapter 24: Configuring Bridging and Routing _______________________________485 Configuring Bridging and Routing Sessions ...486 Adding Sessions ...488 Modifying Sessions ...491...
  • Page 23 Chapter 26: Monitoring Network Connections ________________________________ 517 Monitoring SONET Performance... 518 Medium/Section/Line Current Performance ... 518 Path Current Performance ... 522 Monitoring DS1 Performance ... 524 Monitoring E1 Performance ... 527 Monitoring DS3 Performance ... 530 Monitoring APS Status... 532 Chapter 27: Monitoring Physical Interfaces __________________________________ 535 Opening the Interface Window...
  • Page 24 Table of Contents Managing IDSL Diagnostics ...568 Detecting Network Devices ...570 Managing Image Files ...571 Uploading Files to a TFTP Server...572 Downloading Files to the Avidia System...573 Copying Files ...576 Deleting Files ...577 Downloading Files to a Modem...577 Managing Security ...580 Adding User Accounts ...582 Deleting User Accounts...584 Modifying User Accounts ...584...
  • Page 25 Appendix B: Contacting ADC ______________________________________________ 603 Technical Support... 603 World Wide Web... 603 Limited Warranty ... 603 Advance Replacement ... 604 Billing ... 605 Returns... 605 Appendix C: SPVC Last Release Cause Codes_________________________________ 607 Appendix D: Glossary _____________________________________________________ 611 Index_______________________________________________________________________ 617...
  • Page 26 Table of Contents xxvi Avidia System Configuration and Management User Manual...
  • Page 27: Part I: Introduction And Initial Setup

    NTRODUCTION AND This section contains the following chapters, which provide an overview of Avidia system configuration and management and specific instructions for preparing to configure and manage a system. Chapter Number Chapter Title Avidia System Configuration and Management Overview Preparing for System Configuration and Management Applications and Configuration Overview Avidia System Configuration and Management User Manual NITIAL...
  • Page 28 Avidia System Configuration and Management User Manual...
  • Page 29: Chapter 1: Avidia System Configuration And Management Overview

    VIDIA YSTEM ONFIGURATION ANAGEMENT VERVIEW ® Each Avidia system provides two different user interfaces for system configuration and management. Both interfaces are preinstalled on the management card. The command-line interface provides comprehensive system configuration and management features using a text-only interface. You access the command-line interface using either an ASCII terminal or a PC running a terminal emulation program, connected to the management card craft port.
  • Page 30: Configuration Features

    Configuration Features ONFIGURATION The Avidia system enables you to configure: • system information, such as system name and location, contact, date and time • management card IP address, subnet mask, and default gateway • trap receivers and trap generation status •...
  • Page 31 • SDSL frame-based card line profiles that define the transmission rate. SDSL line profiles are applied to SDSL channels during configuration. • SDSL frame-based card alarm profiles that enable or disable margin, ES, Unavailable Seconds (UAS) and Loss of Sync Word (LOSW) alarms and define the alarm thresholds. SDSL alarm profiles are applied to SDSL channels during configuration.
  • Page 32: Performance Monitoring Features

    Performance Monitoring Features ERFORMANCE The Avidia system enables you to display or monitor system status. The following status can be seen through the Avidia command-line interface: • ATM PVC and PVP connection statistics • APS status • bridge and STP port status •...
  • Page 33: System Administration And Diagnostic Features

    The following status can be seen through the Avidia Web interface: • statistics – IDSL current performance – SONET medium/section/line – SONET path – DS1 current performance – DS3 current performance – physical slot interfaces • current status – ADSL loop status –...
  • Page 34: Avidia System File Management

    Avidia System File Management VIDIA YSTEM Each Avidia line, channel, and management card ships with the necessary system files preinstalled in NVRAM (Non-Volatile Random Access Memory). Restoring System Files To restore system files for a card, copy a complete set of system files from the Avidia MuxWare™...
  • Page 35: How Hardware Profile Files Are Used

    If you replace a management card, you can save the configuration files stored in the line and channel card RAM to the management card NVRAM. However, the management card configuration file containing all of the system profile information will be lost. Therefore, before replacing a management card, back up all of the configuration files from NVRAM, then restore the files onto the new management card.
  • Page 36 Management Tools and Protocols Avidia System Configuration and Management User Manual...
  • Page 37: Chapter 2: Preparing For System Configuration And Management

    REPARING FOR Follow these steps to prepare for initial Avidia system configuration. To configure an Avidia system that is already in service, begin with Connect a terminal or PC running terminal emulation software to the management card craft port. See “Step 1: Connect a Terminal and Log On”...
  • Page 38: Step 1: Connect A Terminal And Log On

    Step 1: Connect a Terminal and Log On 1: C ONNECT A The first step in an initial Avidia system configuration is to set up a local connection to the command-line interface. You access the command-line interface locally by connecting either an ASCII terminal or a PC running a terminal emulation program to the management card craft port.
  • Page 39: Step 2: Set The Management Card Ip Addresses

    2: S ET THE DDRESSES You set the management card IP address, subnet mask and default gateway (if one exists) to enable communication with external networks and to enable access to the Web interface. You cannot use IP addresses 192.168.1.0 through 192.168.21.255 with subnet mask 255.255.255.0 as these addresses are restricted for internal Avidia system use.
  • Page 40: Setting The Gateway Ip Address

    Step 2: Set the Management Card IP Addresses Examples ::ip=> addr 192.168.0.1 255.255.255.0 ::ip=> addr 192.168.0.1 ::ip=> addr 192.168.0.1 255.255.255.0 192.168.0.100 Setting the Gateway IP Address If a gateway exists on the network to which the Avidia system is attached and you did not configure the gateway with the IP address, type the defaultroute command in the following format then press ENTER...
  • Page 41: Step 3: Select A Management Interface

    3: S ELECT A You can perform most of the same system configuration and management functions using either the command-line interface or the Web interface. However, you can only manage user accounts using the Web interface. The command-line interface includes some on-screen help for basic commands and navigation, while the Web interface offers a more comprehensive online Help system to assist you.
  • Page 42: Accessing The Web Interface

    Step 4: Select an Access Method and Complete Setup Accessing the Web Interface Using the Avidia Web interface requires: • a PC running Windows 95, Windows 98 or Windows NT, or a Solaris workstation • an Ethernet card installed in one of the expansion slots ®...
  • Page 43: Next Steps

    To verify IP communications between the PC and the Avidia management card, do a ping from the PC to the IP address of the Avidia management card. To do a ping, from a DOS prompt, type the ping command in the following format then press ENTER , where <ipaddress>...
  • Page 44 Next Steps Avidia System Configuration and Management User Manual...
  • Page 45: Chapter 3: Applications And Configuration Overview

    ONFIGURATION This chapter provides overview information about applications and technologies used in the Avidia system. Understanding the concepts discussed in this chapter will assist you during system configuration. For information about: ATM Traffic Configuration ATM Traffic Management ATM Virtual Circuits ATM Device Addresses Frame Relay Transmission SONET...
  • Page 46: Atm

    The following sections provide information on setting up an ATM network. ATM Traffic Configuration ATM traffic profiles are preconfigured combinations of traffic descriptors and related parameters, which define the traffic Quality of Service (QoS) contract. Traffic profiles are used to configure virtual circuits (VCCs and VPCs). During virtual circuit configuration you assign a traffic profile to each circuit.
  • Page 47 The following table lists traffic parameters that must be set when you configure ATM traffic profiles. Parameter Description PCR0+1 The peak cell rate to apply to both tagged and non-tagged cells, in cells per second. SCR0+1 The sustainable cell rate, or minimum guaranteed transmission rate, to be applied to all cells, in cells per second.
  • Page 48: Atm Traffic Management

    ATM Traffic Management ATM connections are assigned a traffic profile, which specifies the Quality of Service (QoS) that will be available to the connection. Avidia traffic management features ensure that each connection is able to maintain its specified QoS. ATM Traffic Management Features The following traffic management features are supported by the Avidia system: •...
  • Page 49: Establishing A Connection

    Establishing a Connection When a new VC or VP is created, CAC compares the requested QoS with resources available for both upstream and downstream traffic. If the requested QoS is available for both directions, the connection is established. If the requested QoS is not available, CAC denies the connection request and generates an error message.
  • Page 50: Atm Virtual Circuits

    ATM Virtual Circuits ATM virtual circuits are logical connections in the ATM network over which ATM cells are transmitted between two points. Permanent Virtual Circuits (PVCs), supported by Avidia systems, comprise a Virtual Path Connection (VPC) and, frequently, multiple Virtual Channel Connections (VCCs) within the VPC.
  • Page 51 Card OC3 and DS3 DSX-/T1 Cell-based ADSL Cell-based SDSL Before configuring ATM virtual circuits, complete the following: Set up xDSL service for the ports to be configured. Set up ATM traffic profiles for both upstream and downstream traffic. Map the ATM virtual circuits to be configured, including the VPIs and VCIs to be assigned, verifying the values with the preceding tables.
  • Page 52: Frame Relay Transmission

    Frame Relay Transmission The following illustration shows an example of a configured PVC, including the specific VPI and VCI values associated with each segment of the connection. Subscriber VPI/VCI values are obtained from ADSL access provider VPI-0 VCI-100 Megabit Modem 700F 600F 500L...
  • Page 53 • Configure the FRF.5 or FRF.8 circuit for each port. This includes creating the cross connect through the Avidia system (from the line card to the IDSL frame card), and configuring cell loss priority, congestion control, and the traffic type. The available traffic types are: –...
  • Page 54: Sonet

    SONET SONET The Synchronous Optical Network (SONET) is the transport standard for transmitting data over fiber-optic cable. It supports data rates in the gigabit range, optical interfaces, network management, and diagnostic testing methods. SONET comprises four layers, as described in the following table: Layer Description Medium...
  • Page 55: Dual Homing

    Dual Homing Through dual homing, a second network interface (DS1, DS3 or OC3 line card) is used in the Avidia system and provides support that includes: • backup or redundant PVCs with the same destination • static load sharing where traffic is directed separately to a primary and to a secondary line card, increasing the amount of traffic that you can send through the system (see page...
  • Page 56 Redundancy Backup ATM PVCs ATM service requires the configuration of ATM PVCs which comprise VPCs and VCCs. VPCs and VCCs are the logical connections over which ATM cells are transmitted; these are referred to as the primary VPCs and VCCs. You can create backup VPCs and VCCs to which the system can automatically switch in the event that primary VPCs or VCCs fail.
  • Page 57 Traffic Management for Dual Homing When implementing dual homing, you can create backup PVCs and configure static load sharing to both line cards in an Avidia system. Account for these variables when setting up a system: • the number of VPCs and VCCs that can be switched from a primary to a second line card •...
  • Page 58: Line Card Redundancy

    Redundancy Line Card Redundancy The Avidia system line cards provide two types of ATM connection redundancy: • connection redundancy between the line card and the destination ATM end system • line card redundancy, should a line card fail Connection Redundancy Between Line Card and ATM End System When a connection goes down between the line card and the destination ATM end system, the line card detects the failure and attempts to re-establish the connection by automatically retrying or re-routing it, using signaling.
  • Page 59: Automatic Protection Switching

    Managing Traffic for Redundancy You can configure the Avidia system for static load sharing, using two installed line cards. However, if one line card fails, the second line card takes over the functionality of the failed line card, and re-establishes all the connections. This can result in too heavy a traffic load on the second line card.
  • Page 60: Aps Commands

    Redundancy APS Modes What happens after traffic has switched to the protection channel depends on the APS configuration. There are three modes: • Non-Revertive mode prevents traffic from automatically switching back to the working channel when it becomes operational. In this mode, traffic remains on the protection channel until it is manually switched back to the working channel or the card is reset.
  • Page 61: Inband Management

    NBAND ANAGEMENT Inband management offers the ability to manage Avidia networks, including attached modems or subtended systems, from a Network Management System (NMS) or Element Management System (EMS), such as StarGazer. This management occurs over the same ATM network that is used for data transmission, but on a ATM PVC that you set up specifically for management.
  • Page 62: Inband To Avidia

    Inband Management Inband to Avidia The Avidia system automatically creates two dedicated management PVCs to Megabit Modems 700F, 600F, and 500L. SNMP requests are sent to the Avidia system from an NMS/EMS. When the Avidia system receives the SNMP request, it either responds or forwards depending on the value of the community string (see the “Determining IP Addressing and Subnet Masks”...
  • Page 63: Inband For Subtending

    Inband for Subtending Multiple Avidia systems can be implemented, viewed, and managed as if they were one system. This type of management is known as subtending. One system is connected at the edge of the network and is the subtending system. The other systems are managed by the subtending system.
  • Page 64: Bridging And Spanning Tree Protocol

    Bridging and Routing Bridging and Spanning Tree Protocol You can configure bridging sessions that forward Ethernet data based on MAC addresses. A bridge moves information across a network from a source to a destination at the data link layer (of an OSI reference model). The information is sent to a physical address on the Ethernet interface known as a Media Access Control (MAC) address, which is preassigned by a manufacturer.
  • Page 65: Encapsulation For Bridging, Routing, Or Brouting

    Static Routing. You can configure a session with a statically entered route. Through this function, the connection provides broadcast filtering and prevents eavesdropping by specifying destination gateways. With static IP routing, you can access only specific remote IP subnets or hosts. When setting parameters for an external router, configure a Static Route entry in any of the external routers that may have been specified as a Default Router or as a Gateway.
  • Page 66 Bridging and Routing You can set up ATM PVCs between cards in the Avidia system and to modems and run sessions over them. The maximum number of ATM PVCs that you can terminate on the AMC for bridging, routing, or brouting sessions is 96. See the table on of ATM PVCs that you can terminate on other Avidia cards.
  • Page 67: Implementing Bridging/Routing/Brouting Sessions

    Implementing Bridging/Routing/Brouting Sessions Use the Avidia command-line interface or the Web interface to set up bridge, router, or brouter sessions. The following lists procedures you must accomplish to configure sessions. You will find the tasks for these procedures in either the command-line interface or Web interface sections of this manual: •...
  • Page 68 Bridging and Routing The following figure shows an example campus server configuration. Management Workstation Network Tiger Modem Computer Bobcat Modem Computer Determining IP Addressing and Subnet Masks When you set up enterprise or campus server applications, use this general criteria for assigning IP addresses.
  • Page 69 Avidia System A WAN IP 10.12.0.2 Mask 255.255.255.248 LAN IP 20.10.0.1 Switch Avidia System B WAN IP 10.13.0.10 Mask 255.255.255.248 LAN IP 21.10.0.1 Avidia System C WAN IP 10.14.0.18 Mask 255.255.255.248 LAN IP 22.10.0.9 • Each Avidia WAN IP on its own subnet •...
  • Page 70: Downloading Files To A Modem

    Downloading Files to a Modem OWNLOADING This version enables file download from the Avidia system to remotely connected ADSL and SDSL frame modems. This feature is supported for modems meeting the following criteria: Modem Megabit Modem type models supported ADSL 700F, 600F, 500L SDSL 300S...
  • Page 71: Subtending Multiple Systems

    UBTENDING ULTIPLE Multiple systems can be implemented, viewed, and managed as if they were one system. This type of management is known as subtending. To subtend, connect and configure Avidia systems in one of two ways: a star configuration or a daisy chain configuration. In either implementation, multiple systems connect to one system that aggregates the transmission of all the attached systems and provides one network uplink.
  • Page 72 Subtending Multiple Systems In the deployment of xDSL services, subtending helps the service provider satisfy the customer’s demand for bandwidth against the WAN trunk capacities. Subtending helps to expand the availability of service more cost effectively and expand to the more remote subscribers.
  • Page 73 Interface card AV8000 • Slot 11 or 12 as a line (AV311, AV312, interface AV313) • Slots 2 - 10, 11 or 12 (whichever was not the line interface), or 13 - 21 as a channel interface DS3 (AV323) • Slot 11 or 12 as a line interface •...
  • Page 74: Star Management

    Subtending Multiple Systems Star Management In a star configuration, you can attach up to three systems (subtended systems) directly to the one system that connects on the edge of the network (subtending system). The subtending system aggregates the traffic from the subtended systems, switches all the traffic (its own and that of the subtended systems), and provides the network uplink.
  • Page 75 The following sections describe how to select cards for the various subtending connections. The figures use the sample system shown above as an example. Select the uplink card. Install one card for the network uplink, such as the ATM switch shown to the right, in the subtending system.
  • Page 76: Star Configuration

    Subtending Multiple Systems Select the subtended line cards. Install a card in the line-side of the subtended system (see the table on page 47) that is compatible with the card you selected in “Select the subtending channel cards” above. For example, if you select a DS1 card for subtending, then use one of the following: •...
  • Page 77 Configure Service. For each card that is subtending or subtended, configure the applicable service: • DS1/DSX-1: see “Configuring DS1 Service” on page 143 “Configuring DS1 Service” on page 417 • DS3: see “Configuring DS3 Service” on page 149 “Configuring DS3 Service” on page 422 •...
  • Page 78: Daisy Chain Management

    Subtending Multiple Systems Select Policing. The UPC policing function monitors and regulates traffic flow at the interface to ensure the traffic conforms to the configured traffic contract (see information about the traffic contract). Policing protects the network from intentional or unintentional changes in the traffic contract that could affect other connections.
  • Page 79 Subtended Avidia 8000/3000/2200 Avidia 8000/3000/2200 Plan your daisy chain system considering these factors: • Plan an alternate or second path (such as a SONET ring) to re-route traffic in the event of a failure of any link in the daisy chain. •...
  • Page 80 Subtending Multiple Systems Select the subtending channel card. Install a card in the channel-side of each of the first two systems that are subtending the downstream system, up to the maximum allowed number of cards (see the table on page •...
  • Page 81: Daisy Chain Configuration

    Daisy Chain Configuration Consider what traffic contract you need to set up for each connection and what policing, through the Usage Parameter Control (UPC), applies to the connection.The traffic contract and policing you select is dependent on the service you provide. The traffic contract and policing selection should maximize the network throughput and minimize end-to-end delays, thus efficiently utilizing the network.
  • Page 82 Subtending Multiple Systems Configure ATM Connections. Configure the cross connections (ATM circuits), using the profiles that you created for service (see the command-line interface or interface). Essentially, these are the connections you must set up, as shown in the following figure: •...
  • Page 83: Oam Alarms And Loopbacks

    OAM A LARMS AND Operation, Administration and Maintenance (OAM) provides a set of standard functions that the network uses for fault management that: • surveys alarms • performs loopback tests (connectivity verification) • provides continuity checks between ATM devices OAM testing is not disruptive to ATM virtual channels (VPCs and VCCs), which makes it ideal for testing and troubleshooting live ATM networks.
  • Page 84: About Atm Loopbacks

    OAM Alarms and Loopbacks About ATM Loopbacks Avidia supports a fault management function that provides connectivity verification through ATM-layer loopback tests. You can run two different types of OAM loopbacks for both OAM flows F4 and F5: • segment • end-to-end The OAM loopbacks are supported on these Avidia cards: OC3, DS3, DS1/DSX-1, SDSL cell, and ADSL cell.
  • Page 85: Oam Location Id

    OAM Location ID OAM segment and end-to-end tests rely on OAM Location ID addresses to designate a source that originates the loopback test and a destination that is the target loopback device. The OAM Source Location ID address for Avidia systems is a unique sixteen-octet address and is entered in the format xx:xx:xx:xx:xx:xx:xx: xx:xx:xx:xx:xx:xx:xx:xx:xx, where x is an integer 0 through 9 or an alpha character a through f.
  • Page 86 OAM Alarms and Loopbacks Checklist Use the following as a checklist of information or processes needed to perform OAM ATM-layer loopback tests: • Pre-configure all Avidia systems and ATM switches with an OAM Location ID. • Ensure that all links and loops under test are operational. •...
  • Page 87: Example Atm-Layer Loopbacks

    Example ATM-Layer Loopbacks The following sections provide an overview on running some segment loopbacks. For an: • Avidia channel card to loopback at a modem, see • Avidia line card to loopback at an ATM switch, see loopback when a VPC or VCC terminates at the switch). •...
  • Page 88 OAM Alarms and Loopbacks Avidia Channel Card to Modem Segment Loopback The ADSL modems (Megabit Modem 700F, 600F, and 500L software versions 2.6 and later) support F5 flow OAM loopbacks. (Megabit Modem 700F, 600F, and 500L software version 2.7 and earlier do not support F4 flow loopback for VPCs.) Since an xDSL modem terminates ATM service, the modem automatically loops back any OAM loopback cells it receives on any configured PVC.
  • Page 89 Avidia Line Card to ATM Switch Segment or End-to-End Loopback The Avidia line card to ATM switch segment or end-to-end loopback originates and terminates at the source Avidia line card (point B). The loopback target or destination is the ATM switch (point C), as shown in the figure below.
  • Page 90 OAM Alarms and Loopbacks ATM Switch to Modem Segment or End-to-End Loopback The ATM switch to modem segment or end-to-end loopback test originates and terminates at an ATM switch (point C). The loopback target or destination is the modem (point A), as shown in the figure below.
  • Page 91 ATM Switch to Avidia Line Card Segment Loopback The ATM switch to Avidia line card segment loopback originates and terminates at the source ATM switch (point C). The loopback target or destination is the Avidia line card (point B), as shown in the figure below . At the ATM switch, the user must specify for this test the: •...
  • Page 92 OAM Alarms and Loopbacks To perform this test, the user must be familiar with the OAM commands for the ATM node. The user must specify the: VPI/VCI for an OAM F5 flow VCC or VPI only for an OAM F4 flow VPC •...
  • Page 93 Chapter 3: Applications and Configuration Overview Avidia Line Card to Modem End-to-End Loopback The ADSL modems (Megabit Modem 700F, 600F, and 500L software versions 2.6 and later) support F5 flow OAM loopbacks. (Megabit Modem 700F, 600F, and 500L software version 2.7 and earlier do not support F4 flow loopback for VPCs.) Since an xDSL modem terminates ATM service, the modem automatically loops back any OAM loopback cells it receives on any configured PVC.
  • Page 94: After Running Loopbacks

    OAM Alarms and Loopbacks Segment Loopback for a Subtended Avidia System Multiple systems can be implemented, viewed, and managed as if they were one system. This type of management is known as subtending. Avidia systems can subtend other Avidia systems or Avidia systems can be subtended by other ATM devices, such as ATM switches.
  • Page 95: Avidia Alarm Manager

    VIDIA LARM An Alarm Manager stores all the alarm information for the entire system. The alarm manager is stored on the management card, however each individual card installed in the system also stores alarm information for its own ports. If you replace the management card, the new management card retrieves the current alarm information from the individual cards to build a new alarm database.
  • Page 96: Setting Up Connections

    Setting Up Connections ETTING ONNECTIONS The following sections list the tasks you need to perform to set up service for these interfaces. DS1 Line/Management Combination Card The DS1 line/management card acts as both a line and an AMC card, providing configuration and management support for the Avidia system as well as eight DS1 uplinks to transmit subscriber traffic as ATM cells.
  • Page 97: Frame-Based Services

    Frame-based Services Set up service for either an IDSL or SDSL frame-based card using one of the following sections. SDSL Frame Service The following shows the configuration process for setting up SDSL frame-based service. • Create one or more SDSL frame line profiles. See Profiles”...
  • Page 98 Setting Up Connections IDSL Service Do the following to configure IDSL frame-based services: • Create one or more IDSL line profiles. See (command-line interface) or interface). • Create one or more IDSL alarm profiles. See page 130 (command-line interface) or (Web interface).
  • Page 99 Connection Type Use This Setup Frame Relay Select this connection type for modems using Frame Relay. Step 1 Configure the frame relay link for each port, which involves setting the LMI (Local Management Interface) parameters. The LMI type defines the method of exchanging status information between the customer device and the network.
  • Page 100: Cell-Based Services

    Setting Up Connections Cell-based Services Set up service for either an ADSL or SDSL cell-based card using one of the following sections. ADSL The following shows the configuration process for setting up ADSL cell-based service. • Create one or more ADSL line profiles. See page 100 (command-line interface) or (Web interface).
  • Page 101: Saving Configurations

    AVING ONFIGURATIONS As soon as you make configuration changes, the information is saved to RAM on the management card and each of the cards affected by the configuration. However, if you unplug or reboot any of these cards before you manually save the configuration changes to NVRAM, the changes are lost.
  • Page 102 Saving Configurations Avidia System Configuration and Management User Manual...
  • Page 103 This section contains the following chapters, which explain how to configure and manage an Avidia system using the Avidia command-line interface: Chapter Number Chapter Title Introduction to the Command-Line Interface Configuring System Parameters Configuring Subscriber Services Configuring Network Services Configuring ATM Virtual Circuits Configuring Frame Relay Interworking Configuring Bridging and Routing Configuring Subtended Systems...
  • Page 104 Avidia System Configuration and Management User Manual...
  • Page 105: Part Ii: The Avidia Command-Line Interface

    OMMAND The Avidia command-line interface provides comprehensive Avidia system management, including configuration, performance monitoring, and system maintenance and administration. The command-line interface comes preinstalled on the Avidia management card, and is accessed through a terminal connected to the management card craft port or over a network using a telnet session.
  • Page 106: Logging On To The Command-Line Interface

    Logging On to the Command-Line Interface OGGING N TO THE You can log on to the command-line interface locally, using a terminal, or remotely, using a telnet session. For connection instructions, see logged on to the command-line interface at a time, and the local user takes priority over the remote user.
  • Page 107: Chapter 4: Introduction To The Command-Line Interface

    Type your password, then press The password for the preconfigured admin user name is dslam. The system displays a list of general commands and navigational tips, followed by the ::root=> prompt. The command-line interface Inactivity Timer automatically logs the current user off if the keyboard remains inactive for five minutes.
  • Page 108: Navigating The Command-Line Interface

    Navigating the Command-Line Interface AVIGATING THE To navigate the command-line interface: • Type a prompt name then press • Type up then press ENTER • Type top then press • Type exit, quit or bye then press OMMAND Typeface conventions: •...
  • Page 109: Getting Help

    Command-line interface commands: • can be abbreviated as long as the abbreviation is distinct • are not case sensitive ETTING The following help commands are available from each prompt. Display a list of commands available from the current prompt. Display more detailed information about the commands available from the current prompt.
  • Page 110 Logging Off the Command-Line Interface Avidia System Configuration and Management User Manual...
  • Page 111: Chapter 5: Configuring System Parameters

    This chapter describes how to configure system parameters, such as system identifiers, trap receivers and community strings. Section Configuring System Information Configuring IP Addresses Configuring Trap Generation Status Configuring Trap Receivers Configuring Community Strings Avidia System Configuration and Management User Manual ONFIGURING ARAMETERS YSTEM...
  • Page 112: Configuring System Information

    Configuring System Information ONFIGURING You configure system information from the ::system=> prompt. From the ::root=> prompt, type the following command then press configuration system Configuring the System Name The system name displays as part of the system prompt, which makes it easy to keep track of which system you are logged on to.
  • Page 113: Configuring The System Contact

    Configuring the System Contact The system contact information makes it easy for you to quickly identify who to contact regarding the system. From the ::system=> prompt, type the contact command in the following format then press contact (<contact>|"<contact with spaces>") Parameters <contact>...
  • Page 114: Configuring The System Location

    Configuring System Information Configuring the System Location The system location information helps you keep track of where each system in the network is located. To set the system location, type the location command in the following format then ENTER press location (<location>|"<location with spaces>") Parameters <location>...
  • Page 115: Configuring The System Date And Time

    Configuring the System Date and Time It is important to set the system date and time so the alarms and events logs reflect the actual time each event occurred. From the ::system=> prompt, type the time command in the following format then press time <hh>:<mm>:[<ss>] [<mm>/<dd>/<yyyy>] The Avidia system automatically supports leap year dates.
  • Page 116: Configuring Boot File Information

    Configuring System Information Configuring Boot File Information You must specify the location from which to boot the management card image file. For an explanation of Avidia image files, see ::system=> prompt, type the boot command in the following format then press boot (nvram|network) [<file>...
  • Page 117: Displaying System Information

    Displaying System Information You can display the current system information to verify your configuration. From the ::system=> prompt, type show then press displays. ::system=> show System Name: System Contact: System Location: System Description: System Up Time (d:h:m:s) AMC Card Ethernet Port MAC Address: Agent Trap: Agent Authentication Trap: Boot Server IP Address:...
  • Page 118: Configuring The System Ip Address, Subnet Mask And Default Gateway

    Configuring IP Addresses Configuring the System IP Address, Subnet Mask and Default Gateway From the ::ip=> prompt, type the addr command in the following format then press addr <ipaddr> [<netmask>] [<defaultroute>] Parameters <ipaddr> The management card IP address for the Avidia system. This address is based on the Ethernet network to which the Avidia system is attached (format xxx.xxx.xxx.xxx).
  • Page 119: Configuring The Gateway Ip Address

    Configuring the Gateway IP Address If a gateway exists on the network to which the Avidia system is attached and you did not configure the gateway with the IP address, from the ::ip=> prompt type the defaultroute command in the following format then press 192.168.0.100.
  • Page 120: Configuring Trap Generation Status

    Configuring Trap Generation Status ONFIGURING Traps are messages sent from the management card regarding system events, such as alarms. The Avidia system distinguishes between two types of traps. Agent authentication traps are generated when the system receives an invalid SNMP community string. (See Community Strings”...
  • Page 121: Configuring Trap Receivers

    ONFIGURING Trap receivers are network management stations (NMSs) that are designated to receive SNMP traps (messages) sent by the management card. The management card can send traps to multiple trap receivers. However, trap receivers are not required to operate the Avidia system. You configure trap receivers from the ::trap=>...
  • Page 122: Displaying Trap Receivers

    Configuring Trap Receivers Displaying Trap Receivers To verify your trap receiver configuration, from the ::trap=> prompt, type show then press ENTER . A screen similar to the following displays. ::trap=> show Index Network Address 90.0.0.5 90.0.0.6 Deleting Trap Receivers From the ::trap=> prompt, type show then press receivers.
  • Page 123: Configuring Community Strings

    ONFIGURING Community strings are text strings that allow an NMS or EMS, such as StarGazer™ to access the Avidia system. They also assign the NMS the appropriate read/write privileges. You can configure multiple community strings, delete community strings and display the configured community strings.
  • Page 124: Displaying Community Strings

    Configuring Community Strings Displaying Community Strings From the ::community=> prompt, type show then press following displays. The read_view and write_view columns indicate whether or not the community string has read or write privileges. All indicates that the community string has the privilege, while a minus sign indicates that it does not.
  • Page 125: Chapter 6: Configuring Subscriber Services

    ONFIGURING This chapter describes how to configure service for ADSL, SDSL frame, SDSL cell, and IDSL lines through the command-line interface. Section Configuring ADSL Line Profiles Configuring ADSL Alarm Profiles Configuring ADSL Handshaking Configuring ADSL Service Configuring SDSL Frame Line Profiles Configuring SDSL Frame Alarm Profiles Configuring SDSL Frame Service Configuring SDSL Cell Line Profiles...
  • Page 126: Configuring Adsl Line Profiles

    Configuring ADSL Line Profiles ADSL L ONFIGURING ADSL line profiles contain a preconfigured set of parameters, including the transmit rate, rate adaptation mode, target margin, and interleave delay. ADSL port configuration requires you to apply an ADSL line profile to the line, therefore you must configure the desired ADSL line profile before configuring the ADSL port.
  • Page 127 <upstream delay> The upstream interleave delay, in milliseconds. This specifies the delay between consecutive data bits. Larger delays improve noise immunity but reduce transmission speeds. A delay of 16 milliseconds is ideal for maximum noise immunity. However, a delay of 4 to 6 milliseconds is recommended for maximum transmission speed. <downstream delay>...
  • Page 128: Displaying Adsl Line Profiles

    Configuring ADSL Line Profiles Displaying ADSL Line Profiles From the ::line=> prompt, type the show command in the following format then press ENTER show [<index>] Parameter [<index>] The ADSL line profile table index number of the profile you want to display. Omitting this parameter displays the entire ADSL line profile table.
  • Page 129: Deleting Adsl Line Profiles

    Deleting ADSL Line Profiles You cannot delete profiles that are assigned to ports. From the ::line=> prompt, type show then press profile table. Note the index number of the ADSL line profile you want to delete. Type the delete command in the following format then press delete <index>...
  • Page 130: Configuring Adsl Alarm Profiles

    Configuring ADSL Alarm Profiles ADSL A ONFIGURING ADSL alarm profiles determine the conditions that generate SNMP traps. When the configured thresholds are met or exceeded, the SNMP agent sends a trap to the configured trap receiver(s). Only one trap is sent for each 15-minute data collection period. ADSL port configuration requires assigning an alarm profile, therefore you must configure the desired alarm profile prior to configuring the ADSL port.
  • Page 131: Displaying Adsl Alarm Profiles

    <dlof> Downstream loss of frame threshold. <dlos> Downstream loss of signal threshold. <des> Downstream errored seconds threshold. Example ::alarm=> new 10 10 10 10 10 10 Displaying ADSL Alarm Profiles From the ::alarm=> prompt, type the show command in the following format then press ENTER show [<index>] Parameter...
  • Page 132: Deleting Adsl Alarm Profiles

    Configuring ADSL Alarm Profiles The following screen shows an example of both show alarm commands. ::alarm=> show 1 Upstream Index LOFs LOSs ::alarm=> show Upstream Index LOFs LOSs Deleting ADSL Alarm Profiles You cannot delete profiles that are assigned to ports. From the ::alarm=>...
  • Page 133: Configuring Adsl Handshaking

    ADSL H ONFIGURING The ADSL handshaking and line code parameters provide compatibility with a wide range of modems. The selected handshaking protocol determines the line code options available: • If handshaking is set to t1.413, the line code is automatically set to t1.413 •...
  • Page 134: Displaying Handshaking Parameters

    Configuring ADSL Handshaking Displaying Handshaking Parameters From the ::handshake=> prompt, type the show command in the following format then ENTER press show [<port>] Parameter [<port>] The port for which you want to display the handshaking parameters (format slot.port). Omitting this parameter displays the parameters for all configured ADSL channels. Examples ::handshake=>...
  • Page 135: Configuring Adsl Service

    ADSL S ONFIGURING Before configuring an ADSL port, make sure you have: Set up the desired ADSL line profile (see instructions). Set up the desired ADSL alarm profile (see for instructions). You configure ADSL channels from the ::adsl=> prompt. From the ::root=> prompt, type the following command then press configuration adsl Adding ADSL Port Configurations...
  • Page 136: Displaying Adsl Port Configurations

    Configuring ADSL Service Parameters <port> The channel slot and port number (format slot.port). <lpindex> The index number of the line profile you want to assign to this channel. <apindex> The index number of the alarm profile you want to assign to this channel. (up|down) The administrative status of the line.
  • Page 137: Configuring Sdsl Frame Line Profiles

    Examples ::adsl=> show 4.1 ::adsl=> show The following screen illustrates an example of both show adsl commands. In addition to displaying the configured parameters, it also displays the line coding and line type. ::adsl=> show Port Coding Type Physical/Interleave Physical/Interleave Physical/Interleave ::adsl=>...
  • Page 138: Adding Sdsl Frame Line Profiles

    Configuring SDSL Frame Line Profiles Adding SDSL Frame Line Profiles Currently, Fixed Rate is the only supported rate adaptation mode, therefore all SDSL frame line profiles are automatically configured for Fixed Rate. From the ::line=> prompt, type the new command in the following format then press ENTER to create a new SDSL frame line profile.
  • Page 139: Deleting Sdsl Frame Line Profiles

    Examples ::line=> show 1 ::line=> show The following screen illustrates an example of both show line commands. ::line=> show 1 Index Rate_Mode Fixed Rate ::line=> show Index Rate_Mode Fixed Rate Fixed Rate Deleting SDSL Frame Line Profiles You cannot delete profiles that are assigned to ports. From the ::line=>...
  • Page 140: Configuring Sdsl Frame Alarm Profiles

    Configuring SDSL Frame Alarm Profiles SDSL F ONFIGURING SDSL frame alarm profiles determine the conditions that generate SNMP traps. When the configured thresholds are met or exceeded, the SNMP agent sends a trap to the configured trap receiver(s). Only one trap is sent for each 15-minute data collection period. SDSL frame port configuration requires assigning an alarm profile, therefore you must configure the desired alarm profile prior to configuring the SDSL frame port.
  • Page 141: Displaying Sdsl Frame Alarm Profiles

    <esmode> The errored seconds alarm setting. Type enable or disable. <uas> The unavailable seconds threshold. When the number of unavailable seconds in the current 15-minute data collection interval exceeds the specified threshold, the UAS alarm is activated. Unavailable seconds are seconds during which the SDSL frame loop is not synchronized.
  • Page 142: Deleting Sdsl Frame Alarm Profiles

    Configuring SDSL Frame Alarm Profiles The following screen shows an example of both show alarm commands. ::alarm=> show 1 Index LOSW Mgn_Mode enable enable ::alarm=> show Index LOSW Mgn_Mode enable enable disable 6 enable Deleting SDSL Frame Alarm Profiles You cannot delete profiles that are assigned to ports. From the ::alarm=>...
  • Page 143: Configuring Sdsl Frame Service

    SDSL F ONFIGURING Before configuring an SDSL port, make sure you have: Set up the desired SDSL line profile (see page 111 for instructions). Set up the desired SDSL alarm profile (see page 114 for instructions). You configure SDSL frame channels from the ::frame=> prompt. From the ::root=> prompt, type the following command then press configuration sdsl frame Adding SDSL Frame Port Configurations...
  • Page 144: Displaying Sdsl Frame Port Configurations

    Configuring SDSL Frame Service Parameters <port> The channel slot and port number (format slot.port). <lpindex> The index number of the line profile you want to assign to this channel. <apindex> The index number of the alarm profile you want to assign to this channel. (up|down) The administrative status of the line.
  • Page 145: Configuring Sdsl Cell Line Profiles

    The following screen illustrates an example of both show sdsl commands. ::frame=> show Line Port Profile ::frame=> show 4.1 Line Port Profile SDSL C ONFIGURING SDSL cell line profiles contain a preconfigured set of parameters, including the rate adaptation mode and the transmit rate. SDSL cell port configuration requires you to apply an SDSL cell line profile to the line, therefore you must configure the desired SDSL cell line profile before configuring the SDSL cell port.
  • Page 146: Displaying Sdsl Cell Line Profiles

    Configuring SDSL Cell Line Profiles Parameters <rate> The desired transmit rate, in kbps. The valid range supported by the SDSL cell card is from 64 to 2,048, in increments of 64. However, the specified rate must be supported by the remote modem.
  • Page 147: Deleting Sdsl Cell Line Profiles

    Deleting SDSL Cell Line Profiles You cannot delete profiles that are assigned to ports. From the ::line=> prompt, type show then press profile table. Note the index number of the SDSL cell line profile you want to delete. Type the delete command in the following format then press delete <index>...
  • Page 148: Adding Sdsl Cell Alarm Profiles

    Configuring SDSL Cell Alarm Profiles Adding SDSL Cell Alarm Profiles From the ::alarm=> prompt, type the new command in the following format then press ENTER to create a new SDSL cell alarm profile. The profile is automatically assigned the next available index number in the SDSL cell alarm profile table.
  • Page 149: Displaying Sdsl Cell Alarm Profiles

    Displaying SDSL Cell Alarm Profiles From the ::alarm=> prompt, type the show command in the following format then press ENTER show [<index>] Parameter [<index>] The SDSL cell alarm profile table index number of the profile you want to display. Omitting this parameter displays the entire SDSL cell alarm profile table. Examples ::alarm=>...
  • Page 150: Deleting Sdsl Cell Alarm Profiles

    Configuring SDSL Cell Service Deleting SDSL Cell Alarm Profiles You cannot delete profiles that are assigned to ports. From the ::alarm=> prompt, type show then press SDSL cell alarm profiles. Note the index number of the profile you want to delete. Type the delete command in the following format then press delete <index>...
  • Page 151: Adding Sdsl Cell Port Configurations

    Adding SDSL Cell Port Configurations Each SDSL cell port is automatically assigned a default configuration. The default profile index number for each SDSL cell profile type is 1. This procedure describes how to modify the configuration to reflect the desired service. From the ::cell=>...
  • Page 152: Displaying Sdsl Cell Port Configurations

    Configuring SDSL Cell Service [-scramble (enable|disable)] Enables or disables cell scrambling. Cell scrambling, used in Avidia, is not an ATM defined format for SDSL, but is implemented by many vendors. An ATM cell has two parts: header and payload. Cell scrambling scrambles the payload so that it does not resemble the header.
  • Page 153: Configuring Idsl Line Profiles

    The following screen illustrates an example of both show SDSL cell commands. ::cell=> show 4.1 Port Line Alarm Profile Profile Status ::cell=> show Port Line Alarm Profile Profile Status IDSL L ONFIGURING IDSL line profiles contain a preconfigured set of parameters, including the transmit rate, performance monitoring mode, and SES (severely errored second) threshold.
  • Page 154: Displaying Idsl Line Profiles

    Configuring IDSL Line Profiles (path|seg) The performance monitoring mode, which determines how IDSL current performance data (see “Monitoring IDSL Current Performance” on page “Managing IDSL Diagnostics” on page path—Statistics are reported for each segment of the connection path (loop) cumulatively. In the customer direction, node 0 (Avidia system) reports statistics for the first segment, node 1 reports statistics for the first and second segments, etc.
  • Page 155: Deleting Idsl Line Profiles

    The following screen illustrates an example of both show line commands. ::line=> show 1 Index Mode Segmented ::line=> show Index Mode Segmented Path Path Information Index PM Mode Rate (kbps) SES Threshold Deleting IDSL Line Profiles You cannot delete profiles that are assigned to ports. You cannot delete the default profile.
  • Page 156: Configuring Idsl Alarm Profiles

    Configuring IDSL Alarm Profiles Parameter <index> The index number of the IDSL line profile you want to delete. Example ::line=> delete 2 IDSL A ONFIGURING IDSL alarm profiles determine the conditions that generate SNMP traps. When the configured thresholds are met or exceeded, the SNMP agent sends a trap to the configured trap receiver(s). IDSL port configuration requires you to apply an IDSL alarm profile to the line, therefore you must configure the desired IDSL alarm profile before configuring an IDSL port.
  • Page 157: Displaying Idsl Alarm Profiles

    <hourly SES> The hourly SES threshold is the number of severely errored seconds that must be met or exceeded on the IDSL line within an hour for a trap to occur. The range is 0 (disable) to 127, with 10 as the default. A severely errored second generates when the number of block errors (CRC violations) defined by the SES threshold parameter (see are detected during a one second interval.
  • Page 158 Configuring IDSL Alarm Profiles Examples ::alarm=> show 1 ::alarm=> show The following screen shows an example of both show alarm commands. ::alarm=> show 1 Hourly Index ::alarm=> show Hourly Index Information Index Hourly ES Hourly SES Daily ES Daily SES Hourly Daily Daily...
  • Page 159: Deleting Idsl Alarm Profiles

    Deleting IDSL Alarm Profiles You cannot delete profiles that are assigned to ports. You cannot delete the default profile. From the ::alarm=> prompt, type show then press IDSL alarm profiles. Note the index number of the profile you want to delete. Type the delete command in the following format then press delete <index>...
  • Page 160: Modifying The Idsl Transmit Clock Source

    Configuring IDSL Service Modifying the IDSL Transmit Clock Source You modify the source of the transmit clock for the IDSL card from the ::clock=> prompt. From the ::root=> prompt, type the following command then press ::clock=> prompt. configuration IDSL clock Type the set command in the following format then press set <slot>...
  • Page 161: Modifying Idsl Port Configurations

    Example ::clock=> show 5 The following screen illustrates an example of the show clock command. ::clock=> show 5 IDSL clock source for slot 5: local Modifying IDSL Port Configurations Each IDSL port is automatically assigned a default configuration. This procedure describes how to modify the configuration to reflect the desired service.
  • Page 162: Displaying Idsl Port Configurations

    Configuring IDSL Service Parameters <port> The channel slot and port number (format slot.port). <lpindex> The index number of the line profile you want to assign to this port. <apindex> The index number of the alarm profile you want to assign to this port. (up|down) The administrative status of the line.
  • Page 163 Examples ::idsl=> show 4.1 ::idsl=> show The following screen illustrates an example of both show idsl commands. ::idsl=> show 4.1 Line Port Profile ::idsl=> show Line Port Profile Information Port Line Profile Alarm Profile Admin Status Avidia System Configuration and Management User Manual Chapter 6: Configuring Subscriber Services Alarm Admin...
  • Page 164: Configuring Xdsl Subscriber Names

    Configuring xDSL Subscriber Names DSL S ONFIGURING X You can assign a subscriber name to each xDSL port. You configure xDSL subscriber names from the ::service=> prompt. From the ::root=> prompt, type the following command then press ENTER to display the ::service=> prompt. configuration atm frame service Adding New xDSL Subscriber Names From the ::service=>...
  • Page 165 Deleting Subscriber Names From the ::service=> prompt, type the delete command in the following format then press ENTER delete <port> Parameter <port> The port for which you want to delete a subscriber name (format slot.port). Example ::service=> delete 4.1 Displaying Subscriber Names From the ::service=>...
  • Page 166 Configuring xDSL Subscriber Names Avidia System Configuration and Management User Manual...
  • Page 167: Chapter 7: Configuring Network Services

    ONFIGURING This chapter describes how to set up network-side services by configuring line card ports through the command-line interface. Section Configuring OC3 Service Configuring DS1 Service Configuring DS3 Service Avidia System Configuration and Management User Manual ETWORK ERVICES Page...
  • Page 168: Configuring Oc3 Service

    Configuring OC3 Service OC3 S ONFIGURING You must configure each line card port to reflect whether the physical interface is SONET or SDH. You configure the line card port from the ::optics=> prompt. From the ::root=> prompt, type the following command then press configuration optics Configuring the OC3 Interface Type Each OC3 card has two SONET ports, designated as ports 1a and 1b.
  • Page 169: Displaying The Configured Oc3 Interface Type

    Displaying the Configured OC3 Interface Type From the ::optics=> prompt, type show then press following displays. ::optics=> show ***** THE OC3 CONFIGURATION TABLE FOR PORT 2.1 Loopback Configuration: Cell Scrambling : ***** THE OC3 CONFIGURATION TABLE FOR PORT 2.2 Loopback Configuration: Cell Scrambling : DS1 S ONFIGURING...
  • Page 170: Configuring Ds1 Ports

    Configuring DS1 Service Configuring DS1 Ports From the ::ds1=> prompt, type the set command in the following format then press set <port> [-type (esf|d4) [-coding (b8zs|ami)] [-clock (loop|local)] [-lbo index] [-trap (enabled|disabled)] [-admin (up|down)] [-id (<circuit identifier>|"<circuit identifier with spaces>")] [-loopback (none|local|line|payload|remote)] [-scrambling (enable|disable)] Parameters...
  • Page 171 [-lbo index] The line build out, in feet. Determine the value for <index>, based on the length of the line (for DSX1) or equalization (for DS1), as follows: Index [-trap (enabled|disabled)] Enables or disables DS1 trap generation. Type -trap enabled or -trap disabled. [-admin (up|down)] Specifies the administrative status of the line.
  • Page 172: Displaying Ds1/T1 Port Configurations

    Configuring DS1 Service [-loopback (none|local|line|payload|remote)] The type of loopback to start, if any. See page 345 for information. [-scrambling (enable|disable)] Enables or disables cell scrambling. Cell scrambling, used in Avidia, is not an ATM defined format for DS1, but is implemented by many vendors. An ATM cell has two parts: header and payload.
  • Page 173 Examples ::ds1=> show 4.1 ::ds1=> show The following screen illustrates an example of a show ds1 command. ::ds1=> show 4.1 THE DS1 CONFIGURATION TABLE FOR PORT 4.1 ***** THE DS1 CONFIGURATION TABLE FOR PORT 11.1 Circuit Identifier: LBO/Equalization: Transmit Clock Source: Elapsed Time: Valid Intervals: Invalid Intervals:...
  • Page 174 Configuring DS1 Service The DS1 Configuration Table displays the following information. Information Time Elapsed Valid Intervals Line Type Line Coding Send Code Circuit Identifier Loopback Configuration Line Status Signal Mode Transmit Clock Source Facilities Data Link Invalid Intervals Line Build Out Last Line Status Change Loop Back Status DS1 Channel Number...
  • Page 175: Configuring Ds3 Service

    DS3 S ONFIGURING You configure DS3 service from the ::ds3=> prompt. From the ::root=> prompt, type the following command then press configuration ds3 Configuring DS3 Ports From the ::ds3=> prompt, type the set command in the following format then press set <port>...
  • Page 176: Displaying Ds3 Port Configurations

    Configuring DS3 Service [-mode (direct|plcp)] The ATM mapping setting, which sets how ATM cells map to DS3 frames. Type the option that is compatible with your DS3 network, either -mode direct to directly map ATM cells to DS3 frames, or -mode plcp to use the ATM Physical Layer Convergence Protocol (PLCP).
  • Page 177 Examples ::ds3=> show 4.1 ::ds3=> show The following screen illustrates an example of a show ds3 command. ::ds3=> show 12.1 THE DS3 CONFIGURATION TABLE FOR PORT 12.1 Time Elapsed: Valid Intervals: Line Coding: Circuit Identifier: Cell Scrambling : Framing Mode : Line Status: Transmit Clock Source: Invalid Intervals:...
  • Page 178 Configuring DS3 Service Information Circuit Identifier Cell Scrambling Framing Mode Line Status Transmit Clock Source Invalid Intervals Last Line Status Change Line Status Change Trap Enable Loop Back Status Channelization DS1 For Remote Loop Admin Status Descriptions A text string that identifies the circuit. This feature is not yet supported.
  • Page 179: Chapter 8: Configuring Atm Virtual Circuits

    ONFIGURING This chapter describes how to establish connections between ports across the Avidia chassis through the command-line interface. Section Configuring ATM Traffic Profiles Configuring APS Configuring PVPCs Configuring PVCCs Configuring SPVCs Configuring ATM Routing Configuring ATM Policing Avidia System Configuration and Management User Manual ATM V IRTUAL IRCUITS...
  • Page 180: Configuring Atm Traffic Profiles

    Configuring ATM Traffic Profiles ATM T ONFIGURING ATM traffic profiles are preconfigured combinations of traffic descriptors and related parameters, which define the traffic quality of service (QoS) contract. See Configuration” on page 20 You assign traffic profiles to both upstream and downstream traffic during PVPC and PVCC configuration.
  • Page 181: Adding Atm Traffic Profiles

    Adding ATM Traffic Profiles The ATM Traffic Profiles are stored in an ATM Traffic Descriptor Table. Each profile has an index number assigned to it. You use the index number to assign a profile to a PVPC or PVCC. From the ::traffic=> prompt, type show then press Descriptor Table.
  • Page 182: Displaying Atm Traffic Profiles

    Configuring ATM Traffic Profiles <CLR> The maximum Cell Loss Ratio, or number of lost cells divided by the total number of transmitted cells. This value is represented as 10 this parameter. The valid range is 5 - 12. <SCR01> The desired sustained cell rate (minimum guaranteed transmission rate), in cells per second, to be applied to all cells regardless of the CLP tagging.
  • Page 183: Deleting Atm Traffic Profiles

    Examples ::traffic=> show 2 ::traffic=> show The following screen illustrates an example of both show traffic commands. ::traffic=> show Index TYPE UBR: NoTrafficDescriptor CBR: CLPTransparentNoScr ::traffic=> show 1 Index TYPE CBR: CLPTransparentNoScr Deleting ATM Traffic Profiles From the ::traffic=> prompt, type show then press traffic profiles.
  • Page 184: Configuring Aps

    Configuring APS ONFIGURING Avidia systems use Automatic Protection Switching (APS) to switch ATM traffic from the main SONET channel (the working channel) to a secondary SONET channel (the protection channel) when a failure occurs. This redundancy enables service to continue despite failures on the working SONET channel.
  • Page 185: Issuing Manual Aps Commands

    [-wtr <secs>] Omit this parameter if you selected the autonorev or norev for the APS mode. When the APS is set to rev, the Wait To Revert (WTR) timer specifies the number of seconds that you want the system to wait before switching traffic from the protection channel back to the working channel after a failure on the main channel has been cleared.
  • Page 186: Displaying Aps Configuration

    Configuring APS Parameters <slot> The slot number containing the OC3 card for which you want to issue a manual APS command. <(prot2workready|prot2work|work2prot|lockout|clear> The command you want to issue. • prot2workready conditions (such as the configured Wait To Revert Time or a failure condition) that prohibit switching to that channel.
  • Page 187 Examples ::aps=> show ::aps=> show 12 A screen similar to the following displays. ::aps=> show Slot Enable enable(1) Information Slot Enable Mode Command TrapEn Avidia System Configuration and Management User Manual Mode nonRevertiveAuto(2) Description The slot for which the APS configuration is displayed. Whether APS is enabled or disabled for the slot.
  • Page 188: Configuring Pvpcs

    Configuring PVPCs PVPC ONFIGURING Configure primary PVPCs and backup PVPCs using the command-line interface. Backup PVPCs are redundant to primary PVPCs. A primary PVPC automatically switches to a backup PVPC if the primary PVPC were to fail. PVPCs carry data between defined points within the Avidia chassis, such as between a cell-based channel card and a line card.
  • Page 189: Configuring Cell Channel Card Pvpcs

    The following table describes the information displayed after you type the atm show command: Information Slot MaxPVPCs MaxPVCCs PVPCs PVCCs MaxVPIBits MaxVCIBits Configuring Cell Channel Card PVPCs You can configure cross-connect PVPCs between ATM ports on cell-based channel cards and ATM ports on line cards.
  • Page 190 Configuring PVPCs Adding ADSL Cell Channel Card PVPCs From the ::pvpc=> prompt, do one of the following: • To add one PVPC, type the new command in the following format then press PVPC table index number is automatically assigned. new <src port> <vpi> <dst port> <vpi> [-admin (up|down)][-txtraf <src index>] [-rxtraf <src index>] [-backup [<lport>...
  • Page 191 [-txtraf <src index>] [-rxtraf <src index>] (Optional) The index number of the transmit (-txtraf) and receive (-rxtraf) traffic profiles you want to assign to the source port of this PVPC. Transmitted traffic refers to all traffic transmitted out of the Avidia chassis, while received traffic refers to all traffic received into the Avidia chassis.
  • Page 192 Configuring PVPCs Adding a Backup PVPC to an Existing Cell Channel Card PVPC You can configure backup PVPCs at the same time you configure a primary PVPC, as described in the previous section. However, you can also add a backup PVPC to an existing primary PVPC configuration.
  • Page 193: Changing Cell Channel Card Pvpc Admin Status

    Parameter <index> The PVPC Table row index number of the primary PVPC for which you want to switch traffic from the backup PVPC back to the primary PVPC. Example ::pvpc=> restore 3 Changing Cell Channel Card PVPC Admin Status From the ::pvpc=> prompt, type show then press parameters for all PVPCs.
  • Page 194: Deleting Primary And Backup Cell Channel Card Pvpcs

    Configuring PVPCs Deleting Primary and Backup Cell Channel Card PVPCs If you remove a card from the system, the PVPCs associated with the ports on that card are disabled, however the PVPC configuration is not automatically removed from the PVPC table. Be sure to delete unused PVPC configurations so the PVPC configuration table accurately reflects the PVPCs in use in the system.
  • Page 195: Displaying Cell Channel Card Pvpc Information

    Displaying Cell Channel Card PVPC Information From the ::pvpc=> prompt, type the show command in the following format then press ENTER show [<port> [<vpi>]] Parameters [<port>] The port number for which you want to display the configured PVPC (format slot.port). Omitting this parameter displays all configured PVPCs.
  • Page 196: Configuring Pvccs

    Configuring PVCCs The following table describes the information displayed after you type a show pvp command: Column Index Source Port Destination Port TxTraffic Index RxTraffic Index Admin Oper PVCC ONFIGURING Configure primary PVCCs and backup PVCCs using the command-line interface. Backup PVCCs are redundant to primary PVCCs.
  • Page 197: Configuring Cell Channel Card Pvccs

    Configuring Cell Channel Card PVCCs You can configure cross-connect PVCCs between cell-based channel cards and either line cards or the management card. You configure PVCCs from the ::pvcc=> prompt. From the ::root=> prompt, type the following command then press prompt. configuration atm cell pvcc Adding Cell Channel Card PVCCs From the ::pvcc=>...
  • Page 198 Configuring PVCCs <vci> The VCIs associated with the preceding <port> parameter in the command line. When using the range command, the first PVCC is assigned the VCI you specify for this parameter, and each additional PVCC is assigned the next sequential VCI. Before assigning a VCI, verify that it has not already been assigned to a PVCC with the same VPI on the same port.
  • Page 199 Adding a Backup PVCC to an Existing Cell Channel Card PVCC You can configure backup PVCCs at the same time you configure a primary PVCC, as described in the previous section. However, you can also add a backup PVCC to an existing primary PVCC configuration.
  • Page 200 Configuring PVCCs Parameter <index> The PVCC Table row index number of the primary PVCC for which you want to switch traffic from the backup PVCC back to the primary PVCC. Example ::pvcc=> restore 3 Changing Cell Channel Card PVCC Admin Status From the ::pvcc=>...
  • Page 201 Deleting Primary and Backup Cell Channel Card PVCCs You can delete primary and backup cell channel card PVCCs from the ::pvcc=> prompt. If you remove a card from the system, the PVCCs associated with the ports on that card are disabled, however the PVCC configuration is not automatically removed from the PVCC table.
  • Page 202 Configuring PVCCs Deleting Mismatched Internal Cell Channel Card PVCCs When you delete cell channel card PVCCs, mapping information stored in the internal PVCC tables may not automatically be deleted. This results in mismatched PVCCs, or PVCCs for which the mapping data is not consistent across all PVCC tables. Therefore, after deleting PVCCs, you should check for mismatched internal PVCCs and delete them.
  • Page 203 Example ::vcl=> delete 65665 0 213 Displaying Cell Channel Card PVCC Information From the ::pvcc=> prompt, type the show command in the following format then press ENTER show [<port> [<vpi> [<vci>]]] Parameters [<port>] (Optional) Specifies a port for which to display the PVCC configuration (format slot.port). Omitting this parameter displays all configured PVCCs.
  • Page 204 Configuring PVCCs The following table describes the information displayed after you type a show pvc command. Column Index Admin Oper Source Port Destination Port Source TxTraffic Index Source RxTraffic Index Description The PVCC table index number of the displayed PVCC. The configured status of the PVCC, either up (activated) or down (deactivated).
  • Page 205: Configuring Frame Channel Card Pvccs

    Configuring Frame Channel Card PVCCs You can configure cross-connect PVCCs between frame-based channel cards and line cards or the management card. You configure PVCCs from the ::pvcc=> prompt. From the ::root=> prompt, type the following command then press prompt. configuration atm frame pvc Adding Frame Channel Card PVCCs For frame channel cards, the VPI is always zero and the system automatically assigns the VCI.
  • Page 206 Configuring PVCCs <lport> The PVCC line card slot and port number (format slot.port). <cslot> The channel card slot number for the PVCC. <lslot> The line card slot number for the PVCC. <lvpi> The line card VPI. See the table on each card.
  • Page 207 [-txtraf <index>] [-rxtraf <index>] (Optional) The index number of the transmit (-rxtraf) and receive (-txtraf) traffic profiles you want to assign to this PVCC. See instructions on viewing the list of configured profiles. If you do not specify the index, an index of 0 (no profile) is assigned.
  • Page 208 Configuring PVCCs Parameters <index> The PVCC Table row index number of the primary PVCC for which you want to configure a backup PVCC. [<lport> <vpi> <vci>] (Optional) Configures a backup PVCC using the specified line card port (format slot.port), VPI and VCI. The VPI and VCI values can either be the same values as the primary PVCC or different values.
  • Page 209 Changing Frame Channel Card PVCC Admin Status From the ::pvcc=> prompt, type show then press parameters for all PVCCs. Note the index number of the PVCC you want to activate or deactivate. Type the admin command in the following format then press admin <index>...
  • Page 210 Configuring PVCCs Parameters <index> The index number of the PVCC you want to delete. [-backup] (Optional) Type -backup to delete the backup PVCC associated with the primary PVCC and leave the primary PVCC configuration in place. Omitting this parameter deletes both the primary PVCC and any configured backup PVCC.
  • Page 211 Note the ifIndex number, VPI and VCI of the internal PVCC you want to delete. Type the delete command in the following format then press delete <ifIndex> <vpi> <vci> Type up to display the ::atm=> prompt. From the ::atm=> prompt, type the following command then press ::pvcservice=>...
  • Page 212 Configuring PVCCs Displaying Frame Channel Card PVCC Information From the ::pvcc=> prompt, type the show command in the following format then press ENTER show [<slot> [<vpi> [<vci>]]] Parameters [<slot>] (Optional) Specifies a slot for which to display the PVCC configuration. Omitting this parameter displays all configured PVCCs.
  • Page 213 The following screen illustrates an example of both show PVCC commands. ::pvc=> show Channel Index Admin Oper Port down down 2.2 ::pvc=> show 2 0 50 Channel Index Admin Oper Port The following table describes the information displayed after you type a show pvc command. Column Description Index...
  • Page 214: Configuring Spvcs

    Configuring SPVCs Changing the Encapsulation Mode You can change a PVCC encapsulation mode from the ::pvcc=> prompt. From the ::pvcc=> prompt, type the encap command in the following format then press encap <index> [-port <xDSL_port>] [-mode (vcmux|llc)] Parameters <index> The index number of the PVCC for which you want to change the encapsulation mode. See “Displaying Frame Channel Card PVCC Information”...
  • Page 215: Adding Spvcs

    Adding SPVCs From the ::spvc=> prompt, type the new command in the following format, then press ENTER new <slot.port> <vpi> <vci> <dstaddr> [-txtraf <src index>] [-rxtraf <src index>][-interval <interval>] [-retrynumber <n>][-mode <(vcmux|llc)>][-admin (up|down)] Parameters <slot.port> The SPVC channel card slot and port (format slot.port). <vpi>...
  • Page 216: Changing Spvc Admin Status

    Configuring SPVCs Example ::spvc=> new 4.3 100 100 39:26:34:34:75:85:11:08 -txtraf 3 -rxtraf 4 -interval 100 -retrynumber 50 -admin up Changing SPVC Admin Status From the appropriate ::spvc=> prompt, type the admin command in the following format, then press ENTER admin <slot.port> <vpi> <vci> <(up|down)> Parameters <slot.port>...
  • Page 217: Displaying Spvcs

    Displaying SPVCs From the ::spvc=> prompt, type the show command in the following format, then press ENTER show [<slot.port> [<vpi> [<vci>]]] Parameters [<slot.port>] (Optional) The slot and port for which you want to display SPVC information (format slot.port). Omitting this parameter displays all configured SPVC information for the system.
  • Page 218 Configuring SPVCs Examples ::spvc=>show ::spvc=>show 3.2 100 100 A screen similar to the following displays: ::spvc=> Source Admin Oper Slot connected Source Source Last TxTraf RxDesc Index Index Cause Information Description Admin The SPVC administrative status. Options: • Up—activated • Down—deactivated Oper The SPVC operational status.
  • Page 219: Displaying Spvc Details

    Displaying SPVC Details From the appropriate ::spvc=> prompt, type the detailshow command in the following ENTER format, then press detailshow <slot.port> <vpi> <vci> Parameters <slot.port> The slot and port for which you want to display SPVC information (format slot.port). Omitting this parameter displays all configured SPVC information for the system. <vpi>...
  • Page 220: Deleting Spvcs

    Configuring SPVCs Information Admin Status Operation Status Source Slot Source VPI Source VCI Destination Address Source Tx Traffic Index Source Rx Traffic Index Last Release Cause Retry Failures Retry Interval Retry Limit Deleting SPVCs From the appropriate ::spvc=> prompt, type the delete command in the following format, then press ENTER delete <slot.port>...
  • Page 221: Restarting Spvcs

    Parameters <slot.port> The SPVC channel card slot and port (format slot.port). <vpi> The VPI of the VCC between the CPE and the line card. <vci> The VCI of the VCC between the CPE and the line card. Example ::spvc=> delete 4.3 100 100 Restarting SPVCs You can manually attempt to restart an SPVC that is not operational.
  • Page 222: Configuring Atm Routing

    Configuring ATM Routing ATM R ONFIGURING If an Avidia system has two line cards installed, you can configure IISP (Interim Inter-Switch Signaling Protocol) static routes to provide line card redundancy. IISP enables static routing of signaling messages between clustered AVIDIA systems. When a line card fails, the system uses the IISP static route configuration to reroute SPVCs to another line card.
  • Page 223: Displaying Atm Routing Table Entries

    <slot.port> The line card slot and port to which you want to route the traffic when the current line card fails. [-admin (active|inactive)] The administrative status of the routing table entry. Type -admin active to activate it or type -admin inactive to deactivate it. Example ::route=>...
  • Page 224 Configuring ATM Routing Examples ::route=> show ::route=> show 11.1 A screen similar to the following displays: ::route=> Destination Index Address 39:26:34:34:75:85:11:08 39:69:24:97:21:35:34:36 Information Index Destination Address Length Slot Admin Oper Slot Length Admin 11.1 Active 11.1 Inactive Description The ATM Routing Table row number. The ATM address of the destination ATM end system.
  • Page 225: Changing Atm Routing Admin Status

    Changing ATM Routing Admin Status From the ::route=> prompt, type the admin command in the following format, then press ENTER admin <index> <(active|inactive)> Parameters <index> The ATM Routing Table index number of the entry you want to change. <(active|inactive)> Type active to activate the SPVC, or type inactive to deactivate it. Deleting ATM Routing Table Entries From the ::route=>...
  • Page 226: Configuring Atm Policing

    Configuring ATM Policing ATM P ONFIGURING Policing, or UPC, enables you to specify whether traffic must conform to the configured traffic contract. When policing is enabled, traffic that does not conform to the contract is deleted. You can enable or disable policing by ATM port. ATM Port Policing You enable or disable policing (UPC) for ATM ports from the ::port=>...
  • Page 227: Pvc Policing

    Displaying the UPC Table To verify the policing configuration for each port, from the ::port=> prompt, type show then ENTER press . A screen similar to the following displays. ::port=> show Index Port Status enable disable enable enable enable PVC Policing Policing, or UPC, enables you to specify whether traffic must conform to the configured traffic contract.
  • Page 228: Pvp Policing

    Configuring ATM Policing Parameters <index> The index number of the PVCC Table entry you want to configure. <enable|disable> The administrative status of policing on the selected port. Example ::vcl=> modify 4 enable Displaying the PVCC Policing Table To verify the policing configuration for each PVCC, from the ::vcl=> prompt, type show then press ENTER .
  • Page 229 Configuring PVPC Policing From the ::port=> prompt type show to display the PVPC Table. Note the index number of the PVPC Table entry for which you want to configure policing. From the ::vpl=> prompt type the modify command as follows, then press modify <index>...
  • Page 230 Configuring ATM Policing Avidia System Configuration and Management User Manual...
  • Page 231: Chapter 9: Configuring Frame Relay Interworking

    ONFIGURING This chapter describes how to configure and monitor frame relay interworking from the command-line interface. Section Configuring Frame Relay Links Configuring Frame Relay FRF.8 Circuits Configuring Frame Relay FRF.5 Circuits You configure frame relay from the ::frame-relay=> prompt. From the ::root=> prompt, type the following command then press prompt.
  • Page 232: Configuring Frame Relay Links

    Configuring Frame Relay Links ONFIGURING You configure frame relay link parameters from the ::link=> prompt. From the ::root=> prompt, type the following command then press configuration frame-relay link Adding a Frame Relay Link From the ::link=> prompt, type the new command in the following format then press ENTER new <slot.port>...
  • Page 233: Modifying Frame Relay Link Settings

    [-enqinterval <int>] The inquiry interval value. Inquiry interval is the number of poll intervals before a full status inquiry message is sent. The valid range is 1 to 255, with 6 as the default. [-errthreshold <val>] The error threshold value. Error threshold is the number of consecutive poll intervals in which the LMI status inquiry messages are not received that are required for the link to be declared down.
  • Page 234 Configuring Frame Relay Links [-lmitype (LMI|ANNEXA|ANNEXD|NONE)] The LMI (Local Management Interface) type defines a method of exchanging status information between the customer device and the network. The options are: LMI—LMI Rev-1 ANNEXA—ITU 0.933 Annex-A ANNEXD—ANSI T1 617 Annex-D NONE—no LMI support If the LMI type is set to NONE, the poll interval, inquiry interval, error threshold, and monitor events parameters are not used.
  • Page 235: Deleting Frame Relay Links

    Deleting Frame Relay Links Before deleting a frame relay configuration, you must first delete all the circuit configurations under that link. From the ::link=> prompt, type show then press links. Note the index number of the frame relay link you want to delete. From the ::link=>...
  • Page 236: Displaying Frame Relay Link Settings

    Configuring Frame Relay Links Displaying Frame Relay Link Settings From the ::link=> prompt, type the show command in the following format then press ENTER show [<slot.port>] Parameter [<slot.port>] The channel card slot and port (format slot.port) for which you want to display the configuration.
  • Page 237: Configuring Frame Relay Frf.8 Circuits

    Status Box Link State PollInt FullEnqInt ErrThreshold MonEvents ONFIGURING FRF.8 defines how frames are translated between ATM and frame devices. You configure frame relay FRF.8 circuit parameters from the ::frf8=> prompt. From the ::root=> prompt, type the following command then press prompt.
  • Page 238: Adding A Frame Relay Frf.8 Circuit

    Configuring Frame Relay FRF.8 Circuits Adding a Frame Relay FRF.8 Circuit From the ::frf8=> prompt, type the new command in the following format then press ENTER . The index number and the frame relay VPI/VCI on the frame card are automatically assigned.
  • Page 239 [-lpmode (1|2)] The LP mode determines the content of the ATM CLP (Cell Loss Priority) field when translating from frame relay to ATM. 1—The frame relay header DE (Discard Eligibility) field is mapped into the ATM CLP field of every ATM cell generated by the segmentation process of the AAL5 (ATM Adaptation Layer Type 5) PDU (Protocol Data Unit) containing the information for that frame.
  • Page 240 Configuring Frame Relay FRF.8 Circuits [-devalue (0|1)] The DE value determines the content of the frame relay DE field when the DE mode is set to 2. 0—The network cannot discard frames. 1—The network can discard frames. [-CIR <value>] The committed information rate (circuit throughput) in seconds. The valid range is 0 to 144000, with 0 as the default.
  • Page 241: Modifying Frame Relay Frf.8 Circuit Parameters

    Modifying Frame Relay FRF.8 Circuit Parameters You can modify a subset of the parameters that you configured when creating the frame relay circuit. From the ::frf8=> prompt, type show then press circuits. Note the index number of the frame relay FRF.8 circuit configuration you want to modify. From the ::frf8=>...
  • Page 242 Configuring Frame Relay FRF.8 Circuits [-cimode (1|2)] The CI Mode determines the content of the ATM EFCI field. 1—The frame relay FECN field is mapped to the ATM EFCI field of every ATM cell generated by the segmentation process of the AAL5 PDU containing the information of that frame.
  • Page 243: Deleting Frame Relay Frf.8 Circuits

    Deleting Frame Relay FRF.8 Circuits From the ::frf8=> prompt, type show then press circuits. Note the index number of the frame relay FRF.8 circuit you want to delete. From the ::frf8=> prompt, type the delete command in the following format then press ENTER to delete the circuit.
  • Page 244 Configuring Frame Relay FRF.8 Circuits Status Box Fport DLCI Admn Description The index number of the frame relay FRF.8 circuit. The frame card slot and port number in the format slot.port. For example, slot 4 port 1 would be 4.1. The Data Link Connection Identifier (range: 16-991).
  • Page 245: Configuring Frame Relay Frf.5 Circuits

    Status Box TPIx ONFIGURING FRF.5 defines how frames are encapsulated so that they can be carried by the ATM network to another frame device. You configure frame relay FRF.5 circuit parameters from the ::frf5=> prompt. From the ::root=> prompt, type the following command then press prompt.
  • Page 246: Adding A Frame Relay Frf.5 Circuit

    Configuring Frame Relay FRF.5 Circuits Adding a Frame Relay FRF.5 Circuit From the ::frf5=> prompt, type the new command in the following format then press ENTER . The index number and the VPI/VCI on the frame card are automatically assigned. new <fslot.port>...
  • Page 247 [-clpmask (0|1)] The CLP Mask determines the content of the ATM cell CLP field when the Tx LP mode is set to 2. 0—The network cannot discard cells. 1—The network can discard cells. [-rxlpmode (1|2)] The Rx LP mode determines the loss priority settings when transmitting from ATM to frame relay.
  • Page 248: Modifying Frame Relay Frf.5 Circuit Parameters

    Configuring Frame Relay FRF.5 Circuits nrt-vbr (non-real-time Variable Bit Rate)—This traffic class carries variable bandwidth. It is well suited for data services such as frame relay over ATM that requires guaranteed bandwidth and lower Quality of Service. It is not well suited for LAN traffic due to the unpredictability of LAN traffic burst size.
  • Page 249 [-txlpmode (1|2)] The Tx LP mode determines the content of the FR-SSCS PDU header DE and ATM cell ATM CLP fields. 1—The frame header DE field is copied in the FR-SSCS PDU header DE field and mapped into the ATM CLP field of every ATM cell generated by the frame. 2—The frame header DE field is copied into the FR-SSCS PDU header DE field.
  • Page 250: Deleting Frame Relay Frf.5 Circuits

    Configuring Frame Relay FRF.5 Circuits Deleting Frame Relay FRF.5 Circuits From the ::frf5=> prompt, type show then press circuits. Note the index number of the frame relay FRF.5 circuit you want to delete. From the ::frf5=> prompt, type the delete command in the following format then press ENTER to delete the circuit.
  • Page 251: Displaying Frame Relay Frf.5 Circuit Settings

    Displaying Frame Relay FRF.5 Circuit Settings From the ::frf5=> prompt, type show then press Examples ::frf5=> show The following screen illustrates an example of the show command. ::frf5=> show Idx Fport DLCI Lp Vpi Vci Status Box Fport DLCI Admn Avidia System Configuration and Management User Manual Chapter 9: Configuring Frame Relay Interworking ENTER...
  • Page 252 Configuring Frame Relay FRF.5 Circuits Status Box TxLpM CLPM RxLpM TPIx Description The Tx LP mode, which determines the content of the FR-SSCS PDU header DE and ATM cell ATM CLP fields. 1—The frame header DE field is copied in the FR-SSCS PDU header DE field and mapped into the ATM CLP field of every ATM cell generated by the frame.
  • Page 253: Chapter 10: Configuring Bridging And Routing

    ONFIGURING This chapter describes how to create bridging and routing sessions and configure system bridging and routing parameters through the command-line interface. Section Configuring Bridging and Routing Sessions Configuring IP Routing Configuring IP ARP Modifying RIP Configuration Configuring Destination-MAC Address Filtering (Forwarding) Configuring System Bridging Parameters Configuring System STP Parameters Configuring Global IP Routing Settings...
  • Page 254: Configuring Bridging And Routing Sessions

    Configuring Bridging and Routing Sessions ONFIGURING You can configure bridging and routing sessions using PVCs that terminate on the management card (for example, PVCs between ADSL cards and the management card or PVCs between OC3 line cards and the management card). You can configure 96 bridging and routing sessions. To configure a bridging or routing session, you configure a PVC between a line or channel card and the management card, then set up the desired service for the session (bridging, routing or both).
  • Page 255 <dlci> The DLCI (Data Link Connection Identifier) of the frame relay circuit you want to use for this session. <(llc-snap|vcmuxbr|vcmuxrt)> The encapsulation mode you want to use for this PVC. The type of service specified for the -service parameter determines the appropriate encapsulation modes. In addition, the configured encapsulation mode must match the encapsulation mode used by the adjacent segments in the network.
  • Page 256: Modifying Sessions

    Configuring Bridging and Routing Sessions [-stppri <priority>] Omit this parameter if you specified route for the service type. This parameter sets the STP priority for the session. The valid range is from 0 to 255, with 0 being the highest priority.
  • Page 257 Parameters <index> The index number of the Session Configuration Table row that contains the session you want to modify. [-admin (up|down)] The admin status of the session. Up enables the session. Down disables the session. [-subs <subscriber>] A name that identifies the session. This is a text string that can be any length and can contain any character.
  • Page 258 Configuring Bridging and Routing Sessions [-encap(llc-snap|vcmuxbr|vcmuxrt)] The encapsulation mode you want to use for this PVC. The type of service specified for the -service parameter determines the appropriate encapsulation modes. In addition, the configured encapsulation mode must match the encapsulation mode used by the adjacent segments in the network.
  • Page 259: Displaying Sessions

    Displaying Sessions To verify your session configuration, from the ::session=> prompt, type the show command as follows then press show [<slot>] Parameter [<slot>] The slot number for which you want to display the session configurations. Omitting this parameter displays all session configurations. Examples ::session=>...
  • Page 260 Configuring Bridging and Routing Sessions The first row of the Session Configuration Table displays information for a session that connects the management card to the ATM network. The VPI and VCI for this session are assigned internally. Information Admin Oper IpAddr Encap STP Cost...
  • Page 261: Deleting Sessions

    Deleting Sessions From the ::session=> prompt, type show then press sessions. Note the index number of the Session Configuration Table row you want to delete. Type the delete command in the following format then press delete <index> Parameter <index> The Session Configuration Table row index number of the session you want to delete. Example ::session=>...
  • Page 262: Adding Ip Routing Table Entries

    Configuring IP Routing Adding IP Routing Table Entries From the ::routingtb=> prompt type the new command in the following format, then press ENTER new <destip> <nexthop> [-hopcount <hopcount>] Parameters <destip> The IP address to which packets must be sent to qualify for routing based on this IP Routing Table entry.
  • Page 263 Examples ::routingtb=> show ::routingtb=> show 10.0.0.0 A screen similar to the following displays. ::routingtb=> show Route Types Ty: D-Direct; I-Indirect; O-Other; IV-Invalid Protocol Types Pr: L-Local; -Network Mgnt; R-Rip; O-Other Column Headers: Sl-Slot; Po-Port; Hop-HopCount; Ty-Route Types; Pr-Protocol Index DestIp Mask 10.0.0.0 255.0.0.0...
  • Page 264 Configuring IP Routing Information Index DestIp Mask NextHop Description The index number of the IP Routing Table row. The IP address of the routing entry. The subnet mask used to specify what portion of the IP address is considered when determining whether to route the packet based on the data in this table row.
  • Page 265: Deleting Ip Routing Table Entries

    Deleting IP Routing Table Entries From the ::routingtb=> prompt, type show then press configured sessions. Note the index number of the IP Routing Table entry you want to delete. Type the delete command in the following format then press delete <index> Parameter <index>...
  • Page 266: Adding Ip Arp Table Entries

    Configuring IP ARP Adding IP ARP Table Entries From the ::arptb=> prompt type the new command in the following format, then press ENTER new <ipAddr> <macAddr> Parameters <ipAddr> The IP address you want to map to a MAC address (format xxx.xxx.xxx.xxx). <macAddr>...
  • Page 267: Deleting Ip Arp Table Entries

    A screen similar to the following displays. ::arptb=> show Index Slot Port IPAddr 10.0.0.120 10.0.0.121 10.0.11.37 Information Index Slot Port IPAddr MacAddr Type Deleting IP ARP Table Entries From the ::arptb=> prompt, type show then press sessions. Note the index number of the IP ARP Table entry you want to delete. Type the delete command in the following format then press delete <index>...
  • Page 268: Modifying Rip Configuration

    Modifying RIP Configuration Example ::arptb=> delete 2 RIP C ODIFYING The RIP Configuration Table displays information about the Routing Information Protocol (RIP) used for each routing session. You configure RIP information initially during session configuration, however you can modify it using the following procedures. You modify RIP information from the ::rip=>...
  • Page 269: Displaying The Rip Configuration Table

    [-recv(ripv1|ripv2|v1orv2|donotrecv)] • ripv1 — receive RIP Version 1 packets only • ripv2 — receive RIP Version 2 packets only • v1orv2 — receive either RIP Version 1 or RIP Version 2 packets • donotrecv — receive no RIP packets [-key <plain text password>] This parameter enables you to set a password, or key.
  • Page 270 Modifying RIP Configuration Examples ::rip=> show ::rip=> show 10.0.0.120 A screen similar to the following displays. ::rip=> show Index IPAddr Send 10.0.11.37 ripv1c Information Index IPAddr Send Receive Hop Count Authentication Receive Hop Count v1orv2 Description The RIP Configuration Table row index number. The IP address of the routing session.
  • Page 271: Configuring Destination-Mac Address Filtering (Forwarding)

    ONFIGURING ILTERING ORWARDING The Destination-MAC Address Filtering Table displays a list of ports from which frames may be received and the corresponding ports to which those frames are allowed to be forwarded. You add Destination-MAC Address Filtering Table entries from the ::filter=> prompt. From the ::root=>...
  • Page 272: Displaying The Destination-Mac Address Filtering Table

    Configuring Destination-MAC Address Filtering (Forwarding) Displaying the Destination-MAC Address Filtering Table To verify filtering configuration, from the ::filter=> prompt, type the show command as ENTER follows then press show [<macaddr>] Parameter [<macaddr>] The MAC address of the Destination-MAC Address Filtering Table entry you want to display (format xx:xx:xx:xx:xx:xx).
  • Page 273: Deleting Destination-Mac Address Filtering Table Entries

    Deleting Destination-MAC Address Filtering Table Entries From the ::filter=> prompt, type show then press sessions. Note the index number of the Destination-MAC Address Filtering Table entry you want to delete. Type the delete command in the following format then press delete <index>...
  • Page 274: Modifying System Bridging Parameters

    Configuring System Bridging Parameters Modifying System Bridging Parameters From the ::bridging=> prompt, type the modify command in the following format, then ENTER press modify [-brenable (on|off)] [-wanbcenable (on|off)] [-age <sec>] Parameters [-brenable (on|off)] Type -brenable on to enable bridging. Type -brenable off to disable bridging. [-wanbcenable (on|off)] Determines whether unknown WAN frames are broadcast to all WAN logical interfaces.
  • Page 275: Configuring System Stp Parameters

    Information Bridging Enabled WAN Broadcast Enabled Aging Time (sec) ONFIGURING You can configure several system-wide STP parameters. Each parameter comes preconfigured with a default value, however you can modify each setting. You modify system STP parameters from the ::globalstp=> prompt. From the ::root=>...
  • Page 276: Displaying System Stp Parameters

    Configuring System STP Parameters [-hellotime <sec>] The interval, in seconds, at which you want the system to send Spanning Tree Protocol packets. The valid range is 1 to 10. The default value is 2. [-fddelay <sec>] The number of seconds you want the system to wait before changing the state of a particular interface (changing to blocked, for example).
  • Page 277: Configuring Global Ip Routing Settings

    ONFIGURING You configure global settings to enable IP routing and specify the time-to-live value for IP datagrams. You configure global IP routing settings from the from the ::ip=> prompt. From the ::root=> prompt, type the following command then press prompt: configuration routing ip Configuring Global IP Routing Settings From the ::ip=>...
  • Page 278 Configuring Global IP Routing Settings Avidia System Configuration and Management User Manual...
  • Page 279: Chapter 11: Configuring Subtended Systems

    ONFIGURING This chapter describes how to configure subtended systems from the command-line interface. Section Adding a Subtended System Modifying a Subtended System Configuration Displaying Subtending Information You configure which systems are subtended and subtending from the ::subtend=> prompt. From the ::root=> prompt, type the following command then press ::subtend=>...
  • Page 280: Adding A Subtended System

    Adding a Subtended System DDING A UBTENDED From the ::subtend=> prompt, type the new command in the following format, then press ENTER new <slot.port> <vpi> <vci> -srcipaddr <sourceipaddr> -dstipaddr <destipaddr> -mask <subnetmask> -parentipaddr <paripaddr> -parentslotport <pslot.pport> [-admin(up|down)] Parameters <slot.port> The slot and port through which subtending occurs. <vpi>...
  • Page 281: Modifying A Subtended System Configuration

    Example ::subtend=> new 5.1 0 100 -srcipaddr 192.169.2.2 -dstipaddr 192.169.2.1 -mask 255.255.255.0 -parentipaddr 192.169.2.2 -parentslotport 5.1 -admin up ODIFYING A UBTENDED From the ::subtend=> prompt, type the new command in the following format, then press ENTER modify <index> <vpi> <vci> -srcipaddr <sourceipaddr> -dstipaddr <destipaddr>...
  • Page 282 Modifying a Subtended System Configuration -parentslotport <pslot.pport> The channel card slot and port through which the destination chassis is subtended. [-admin(up|down)] Specifies the administrative status of the line. Type -admin up to activate the line. Type -admin down to deactivate it. Example ::subtend=>...
  • Page 283: Displaying Subtending Information

    ISPLAYING UBTENDING From the ::subtend=> prompt, type the new command in the following format, then press ENTER show [<slot>] Parameters [<slot>] The slot and port for which you are displaying subtending information. Omitting this parameter displays all subtending information. Example ::subtend=>...
  • Page 284 Displaying Subtending Information The following table describes the information displayed after you type a show command. Column SVpi SVci DVpi DVci Smask operS Description The index number that is associated with a specific subtending configuration. The channel card slot through which subtending occurs. The channel card port through which subtending occurs.
  • Page 285: Chapter 12: Monitoring Subscriber Connections

    ONITORING This chapter describes how to monitor Avidia subscriber connections, including loop status, performance history and remote status for ADSL, IDSL and SDSL lines using the command-line interface. Section Monitoring ADSL Performance Monitoring SDSL Frame Performance Monitoring SDSL Frame CPE Statistics Monitoring SDSL Cell Performance Monitoring IDSL Current Performance Avidia System Configuration and Management User Manual...
  • Page 286: Monitoring Adsl Performance

    Monitoring ADSL Performance ADSL P ONITORING You can monitor ADSL loop status and performance history either by port or for all ADSL lines in the system at once. You access all ADSL statistics from the ::adsl=> prompt. From the ::root=> prompt, type the following command then press prompt.
  • Page 287 The following table describes the information displayed after you type a loop command. Information Current Transmit Rate Current Output Power SNR Margin (1/10 dB) Line Attentuation (1/10 dB) Interleave Delay (ms) Errored Seconds Loss of Frame Loss of Signal Current State Avidia System Configuration and Management User Manual Chapter 12: Monitoring Subscriber Connections Description...
  • Page 288: Monitoring Adsl Performance History

    Monitoring ADSL Performance Monitoring ADSL Performance History You can monitor 15-minute, current-day and previous-day ADSL performance history. From the ::adsl=> prompt, type the perf command in the following format then press ENTER perf [<port>] [-day (curr|prev)] Parameter [<port>] The port for which you want to display performance history (format slot.port). [-day(curr|prev)] The time period for which you want to display performance history.
  • Page 289 The following two screens illustrate an example of several ADSL performance commands. ::adsl=>perf 3.2 -day curr Upstream Port LOFs LOSs ::adsl=>perf 3.2 -day prev Upstream Port LOFs LOSs ::adsl=>perf 3.2 Upstream Port LOFs LOSs ::adsl=>perf -day curr Upstream Port LOFs LOSs ::adsl=>perf Upstream...
  • Page 290: Monitoring Sdsl Frame Performance

    Monitoring SDSL Frame Performance The following table describes the information displayed after you type a perf command. Information Port LOFs (Upstream/Downstream) LOSs (Upstream/Downstream) Loss of signal. The number of seconds in the ESs (Upstream/Downstream) SDSL F ONITORING You can monitor SDSL frame statistics and performance history either by port or for all SDSL frame lines in the system at once.
  • Page 291 Example ::frame=> loop 4.2 A screen similar to the following displays. ::frame=>loop 4.2 TipRing Port Reversal Up_State signaling The following table describes the information displayed after you type a line command. Information Port TipRing Reversal Up_State Mgn (Network/Customer) MgnH (Network/Customer) MgnL (Network/Customer) Atn (Network/Customer) Avidia System Configuration and Management User Manual...
  • Page 292: Displaying Sdsl Frame Performance History

    Monitoring SDSL Frame Performance Displaying SDSL Frame Performance History You can monitor SDSL frame 15-minute, 24-hour and 7-day performance history. Type the perf command in the following format then press perf [<port>] [-id (<number>|all) [-week]] Parameter <port> The port for which you want to view performance (format slot.port). Omitting this parameter displays the specified loop status for all SDSL frame ports.
  • Page 293: Monitoring Sdsl Frame Cpe Statistics

    The following table describes the information displayed after you type a perf command. Information Port ESs (Network/Customer) UASs (Network/Customer) SDSL F ONITORING You can monitor the transmitted and received octets for each modem that is attached to an SDSL frame port. You view SDSL frame CPE statistics using the command-line interface from the ::interfaces=>...
  • Page 294: Monitoring Sdsl Cell Performance

    Monitoring SDSL Cell Performance The following table describes the information displayed after you type a cpe command. Information CPEPort LAN inOctets LAN outOctets WAN inOctets WAN outOctets SDSL C ONITORING You can monitor SDSL cell statistics and performance history either by port or for all SDSL cell lines in the system at once.
  • Page 295 Examples ::cell=> line 18.1 ::cell=> line A screen similar to the following displays. ::cell=>line 18.1 Port SDSL_State 18.1 down(2) :cell=>line Port SDSL_State 18.1 down(2) 18.2 down(2) 18.3 down(2) 18.4 down(2) The following table describes the information displayed by a line command. Information Port SDSL_State...
  • Page 296: Displaying Sdsl Cell Performance History

    Monitoring SDSL Cell Performance Displaying SDSL Cell Performance History You can monitor SDSL cell 15-minute, 24-hour and 7-day performance history. Type the perf command in the following format then press perf [<port>] [-id (<number>|all) [-week]] Parameter <port> The port for which you want to view performance (format slot.port). Omitting this parameter displays the specified loop status for all SDSL cell ports.
  • Page 297: Displaying Sdsl Cell Tc Layer Statistics

    The following table describes the information displayed after you type a perf command. Information Port LOSS LOCD SLOCD History_Id Displaying SDSL Cell TC Layer Statistics You can display ATM transmission convergence (TC) layer statistics for cell-based SDSL circuits. Type the tclayer command in the following format and press tclayer [slot.port] Parameter [slot.port]...
  • Page 298 The number of cells received by the port from the modem since the counters were last cleared. Mismatched Cells This information is for internal ADC use only. LOCD Event Count Loss of cell delineation seconds are seconds in which some cells transmitted...
  • Page 299: Clearing Sdsl Cell Statistics

    Clearing SDSL Cell Statistics You can reset the SDSL cell statistical counters to zero. Type the clearstats command in the following format then press clearstats [slot.port] [-y] Parameter [slot.port] The slot and port for which you want to clear statistics (format slot.port). Omitting this parameter clears statistics for all SDSL cell ports.
  • Page 300: Monitoring Idsl Current Performance

    Monitoring IDSL Current Performance IDSL C ONITORING Current performance statistics display a summary of the performance data for a specified IDSL line and port. Monitoring IDSL Current Performance You access IDSL current performance statistics from the ::idsl=> prompt. From the ::root=>...
  • Page 301 Examples ::idsl=> perf 5.1 ::idsl=> perf 5.1 -interval all -day A screen similar to the following displays. ::idsl=> perf 4.1 Node Network Port Id The following table describes the information displayed after you type a perf command. indicates statistics for the upstream direction, toward the network. for the downstream direction, toward the customer.
  • Page 302 Monitoring IDSL Current Performance Avidia System Configuration and Management User Manual...
  • Page 303: Chapter 13: Monitoring Network Connections

    ONITORING This chapter describes how to monitor Avidia network connections, including loop status, performance history, and remote status for SONET, DS1/T1, and DS3 lines using the command-line interface. It also describes how to monitor ATM statistics. Section Monitoring SONET Performance Monitoring DS1/T1 Performance Monitoring DS3 Performance Monitoring ATM Connection Statistics...
  • Page 304: Monitoring Sonet Performance

    Monitoring SONET Performance SONET P ONITORING You can monitor SONET performance by Medium, Section, Line and Path layers. You access all SONET statistics from the ::sonet=> prompt. From the ::root=> prompt, type the following command then press display stats sonet Monitoring SONET Medium Statistics From the ::sonet=>...
  • Page 305 The following screen illustrates an example of both medium commands. ::sonet=> medium Port Type Time_Elapsed 12.1a 12.1b ::sonet=> medium 12.1b Port Type Time_Elapsed 12.1b The following table describes the information displayed after you type a medium command. Information Port Type Time_Elapsed Intervals Coding...
  • Page 306: Monitoring Sonet Section Statistics

    Monitoring SONET Performance Monitoring SONET Section Statistics From the ::sonet=> prompt, type the section command in the following format then press ENTER section [<port>] [-interval (<number>|all)] Parameter [<port>] Specifies a particular port for which to display statistics (format slot.port). Each OC3 line card has two SONET fiber ports, which are identified by 1a and 1b.
  • Page 307: Monitoring Sonet Line Statistics

    The following table describes the information displayed after you type a section command. Information Description Port The OC3 line card slot and port to which the row of statistics applies. Status The current status of the specified port. Options: • NoDefect —...
  • Page 308 Monitoring SONET Performance Parameters [<port>] Specifies a particular port for which to display statistics (format slot.port). Each OC3 line card has two SONET fiber ports, which are identified by 1a and 1b. Omitting this parameter displays statistics for all SONET ports. [-far] Displays statistics for the remote device.
  • Page 309: Monitoring Sonet Path Statistics

    The following table describes the information displayed after you type a line command. Information Description Port The OC3 card slot and port to which the row of statistics applies. Status Options: • NoDefect • AIS (Alarm Indication Signal) SONET line. •...
  • Page 310 Monitoring SONET Performance Parameters [<port>] Specifies a particular port for which to display statistics (format slot.port). Each OC3 line card has two SONET fiber ports, which are identified by 1a and 1b. Omitting this parameter displays statistics for all SONET ports. [-far] Displays statistics for the remote device.
  • Page 311 The following table describes the information displayed after you type a path command. Information Description Port The port to which the row of statistics applies. Status The current status of the interface. This information only displays when you type the path command without any additional parameters. Options: •...
  • Page 312: Monitoring Ds1/T1 Performance

    Monitoring DS1/T1 Performance DS1/T1 P ONITORING You can monitor DS1/T1 current performance and performance history, by port or for all ports at once. You monitor DS1 performance from the ::stats=> prompt. From the ::root=> prompt, type the following command then press display stats Type the ds1 command in the following format, then press ds1 [<port>...
  • Page 313 Examples ::stats=> ds1 3.1 -interval all ::stats=> ds1 3.1 -interval 3 ::stats=> ds1 3.1 ::stats=> ds1 A screen similar to the following displays. ::stats=>ds1 4.2 THE DS1 CURRENT/TOTAL TABLE FOR PORT 4.2 Errored Seconds: Severely Errored Seconds: Severely Errored Framing Seconds: Unavailable Seconds: Controlled Slip Seconds: Path Coding Violations:...
  • Page 314 Monitoring DS1/T1 Performance The following table describes the information displayed after you type the ds1 command. Information Port Errored Seconds Severely Errored Seconds Severely Errored Framing Seconds Unavailable Seconds Controlled Slip Seconds Path Coding Violations Line Errored Seconds Bursty Errored Seconds Degraded Minutes Line Code Violations Description...
  • Page 315: Monitoring Ds3 Performance

    DS3 P ONITORING You can monitor DS3 current performance and performance history, by port or for all ports at once. You monitor DS3 performance from the ::stats=> prompt. From the ::root=> prompt, type the following command then press display stats Type the ds3 command in the following format, then press ds3 [<port>...
  • Page 316 Monitoring DS3 Performance Examples ::stats=> ds3 3.1 -interval all ::stats=> ds3 3.1 -interval 3 ::stats=> ds3 3.1 ::stats=> ds3 A screen similar to the following displays. ::stats=>ds3 4.2 THE DS3 CURRENT/TOTAL TABLE FOR PORT 12.2 P-bit Errored Seconds: P-bit Severely Errored Seconds: Severely Errored Framing Seconds: Unavailable Seconds: Line Coding Violations:...
  • Page 317 The following table describes the information displayed after you type the ds3 command. Information Slot Card Description Port P-bit Errored Seconds P-bit Severely Errored Seconds Severely Errored Framing Seconds Unavailable Seconds Line Coding Violations P-bit Coding Violations Line Errored Seconds C-bit Coding Violations C-bit Errored Seconds C-bit Severely Errored Seconds...
  • Page 318: Monitoring Atm Connection Statistics

    Monitoring ATM Connection Statistics ATM C ONITORING You can monitor ATM connection statistics by PVCC or PVPC. ATM PVCC Connection Statistics You can monitor the number of cells transmitted and received, the number of nonconforming cells, and the number of discarded cells for each active PVCC. Two entries display for each configured PVCC—each end of the connection is a separate table entry.
  • Page 319: Atm Pvpc Connection Statistics

    Information Description Index The PVCC Connection Statistics Table row index number. Port The slot and port on which the PVCC is configured. The PVCC VPI and VCI. In Cells The number of cells received, represented in hexidecimal format. Out Cells The number of cells transmitted, represented in hexidecimal format.
  • Page 320 Monitoring ATM Connection Statistics A screen similar to the following displays. ::vpl=> show Index Port Information Index Port In Cells Out Cells Non Conforming Discard Cells Cells Cells Conforming 0x00 0x00 0x00 0x00 0x00 0x00 Description The PVPC Connection Statistics Table row index number. The slot and port on which the PVPC is configured.
  • Page 321: Monitoring Aps Status

    APS S ONITORING You can monitor APS information such as the date and time of APS events and the currently active channel. You monitor APS status using the command-line interface from the ::stats=> prompt. From the ::root=> prompt, type the following command then press ::stats=>...
  • Page 322: Monitoring Frame Relay Performance Statistics

    Monitoring Frame Relay Performance Statistics ONITORING RAME TATISTICS You monitor frame relay connection statistics using the command-line interface. You access frame relay statistics from the ::frame-relay=> prompt. From the ::root=> prompt, type the following command then press disp stats frame-relay Monitoring Link Statistics You access frame relay link statistics from the ::link=>...
  • Page 323 A screen similar to the following displays. ::link=> show 5.1 Link statistics for Frame Relay port 5.1: Total number of frames transmitted Total number of frames received Total number of characters transmitted Total number of characters received Total number of frames received with FECN Total number of frames received with BECN Total number of invalid frames received Total number of short(<...
  • Page 324: Monitoring Lmi Statistics

    Monitoring Frame Relay Performance Statistics • The total number of sent frames aborted. • The type of error last seen on this interface. • The number of times the link went down since it was initialized. Monitoring LMI Statistics You access frame relay Link Management Interface (LMI) statistics from the ::lmi=> prompt.
  • Page 325: Monitoring Circuit Statistics

    The following information displays: • The frame card slot number and port number in the format slot.port (for example, port 5.1). • The number of LMI status enquiries received. • The number of LMI full status enquiries received. • The number of LMI status responses sent. •...
  • Page 326 Monitoring Frame Relay Performance Statistics Parameters <fslot.port> The frame card slot and port. [<dlci>] The DLCI (Data Link Connection Identifier) for this virtual circuit. If omitted, statistics display for all DLCIs. Examples ::dlci=> show 5.1 16 ::dlci=> show 5.1 A screen similar to the following displays. ::dlci=>...
  • Page 327 The following information displays: • The frame card slot number and port number in the format slot.port (for example, port 5.1). • The DLCI (Data Link Connection Identifier) for this virtual circuit. • The number of frames transmitted. • The number of frames received. •...
  • Page 328: Monitoring Frf.5 Statistics

    Monitoring Frame Relay Performance Statistics Monitoring FRF.5 Statistics You access frame relay FRF.5 statistics from the ::frf5=> prompt. From the ::frame-relay=> prompt, type frf5 then press prompt. From the ::frf5=> prompt, type the following command then press FRF.5 statistics. show <fslot.port> Parameter <fslot.port>...
  • Page 329: Monitoring Frf.8 Statistics

    Monitoring FRF.8 Statistics You access frame relay FRF.8 statistics from the ::frf8=> prompt. From the ::frame-relay=> prompt, type frf8 then press prompt. From the ::frf8=> prompt, type the following command then press FRF.8 statistics. show <fslot.port> Parameter <fslot.port> The frame card slot and port. Example ::frf8=>...
  • Page 330 Monitoring Frame Relay Performance Statistics The following information displays: • The frame card slot number and port number in the format slot.port (for example, port 5.1). • The DLCI for this virtual circuit. • The cross connect frame relay PVC. This consists of the line card VPI, VCI and the channel card VPI, VCI.
  • Page 331: Chapter 14: Monitoring Bridging And Routing

    ONITORING This chapter describes how to monitor bridging and routing sessions using the command-line interface. Section Monitoring Bridge Port Status Monitoring STP Port Status Monitoring System Bridge/STP Statistics Monitoring System IP Statistics Monitoring Bridge Forwarding Statistics Avidia System Configuration and Management User Manual RIDGING OUTING Page...
  • Page 332: Monitoring Bridge Port Status

    Monitoring Bridge Port Status ONITORING RIDGE You can monitor the number of discarded packets on each configured logical bridge session port. You monitor bridge port status using the command-line interface from the ::bridge=> prompt. From the ::root=> prompt, type the following command then press display the ::bridge=>...
  • Page 333: Monitoring Stp Port Status

    STP P ONITORING You can monitor the Spanning Tree Protocol information for each configured logical bridge session port. You monitor STP port status using the command-line interface from the ::bridge=> prompt. From the ::root=> prompt, type the following command then press ::bridge=>...
  • Page 334 Monitoring STP Port Status Information Description Bridge Port The logical bridge session port number. The system automatically assigns this number when you configure a bridging session. Priority The configured Spanning Tree Protocol priority for the session port. Port State The current Spanning Tree Protocol state of the session port, either Forwarding, Blocked, or Learning.
  • Page 335: Monitoring System Bridge/Stp Statistics

    ONITORING YSTEM You can monitor system-wide bridging and Spanning Tree Protocol statistics. You monitor system bridge/STP statistics using the command-line interface from the ::bridge=> prompt. From the ::root=> prompt, type the following command then press ENTER to display the ::bridge=> prompt. display stats bridge Type global then press A screen similar to the following displays.
  • Page 336 Monitoring System Bridge/STP Statistics Information Bridge Addr Bridge Type Discarded Entries Protocol Aging Time (sec) Time Since Topology Change Topology Changes Since Reboot Designated Root Root Cost Root Port Current Max Age (sec) Current Hello Time (sec) Current Hold Time (sec) Current Forward Delay (sec) Description...
  • Page 337: Monitoring System Ip Statistics

    ONITORING YSTEM You can evaluate the efficiency of the routing engine by monitoring system IP statistics. The statistics are cumulative since the management card was last reset. You monitor system IP statistics using the command-line interface from the ::ip=> prompt. From the ::root=>...
  • Page 338 Monitoring System IP Statistics Information Datagrams Received Errored Header Errored IP Addresses Datagrams Forwarded Unknown Protocol Input Datagrams Discarded Datagrams Delivered Datagrams Transmitted Output Datagram Discards Output Datagram Discards (No Route) Reassembly Timeout Fragments Needed Reassembly Datagrams Reassembled Datagram Reassembly Failures Datagrams Fragmented Datagram Fragmentation...
  • Page 339: Monitoring Bridge Forwarding Statistics

    ONITORING RIDGE You can monitor bridge forwarding and filtering information by MAC address. You monitor bridge forwarding statistics using the command-line interface from the ::bridge=> prompt. From the ::root=> prompt, type the following command then press ENTER to display the ::bridge=> prompt. display stats bridge Type fwddb then press ENTER...
  • Page 340 Monitoring Bridge Forwarding Statistics Avidia System Configuration and Management User Manual...
  • Page 341: Chapter 15: Monitoring Physical Interfaces

    ONITORING This chapter describes how to monitor physical interface statistics using the command-line interface. Section Monitoring ADSL Interfaces Monitoring SDSL Frame Interfaces Monitoring SDSL Cell Interfaces Monitoring DS1 Interfaces Monitoring DS3 Interfaces Monitoring OC3 Interfaces Monitoring Interfaces You can monitor the number of bytes transmitted and received on all system interfaces at once, or by interface type (ADSL, SDSL frame, SDSL Cell, DS1/T1, DS3, OC3 or Ethernet).
  • Page 342: Monitoring Adsl Interfaces

    Monitoring ADSL Interfaces ADSL I ONITORING From the ::interfaces=> prompt, type the adsl command in the following format, then ENTER press adsl [<port>] Parameter [<port>] The specific port for which you want to display interface statistics (format slot.port). Omitting this parameter displays statistics for all ADSL interfaces. Examples ::interfaces=>...
  • Page 343: Monitoring Sdsl Frame Interfaces

    The following table describes the information displayed after you type an adsl command. Information Port Number Interface Description Speed Admin Status Oper Status SDSL F ONITORING From the ::interfaces=> prompt, type the following command, then press display the ::sdsl=> prompt. sdsl From the ::sdsl=>...
  • Page 344 Monitoring SDSL Frame Interfaces Examples ::sdsl=> frame 4.3 ::sdsl=> frame The following screen illustrates examples of both frame interface commands. ::sdsl=>frame 4.3 Interface Port Description SDSL 24-port channel card ::sdsl=>frame Interface Port Description SDSL 24-port channel card SDSL 24-port channel card The following table describes the information displayed after you type a frame interface command.
  • Page 345: Monitoring Sdsl Cell Interfaces

    SDSL C ONITORING From the ::sdsl=> prompt, type the cell command in the following format, then press ENTER cell [<port>] Parameter [<port>] The specific port for which you want to display interface statistics (format slot.port). Omitting this parameter displays statistics for all SDSL cell interfaces. Examples ::sdsl=>...
  • Page 346: Monitoring Ds1 Interfaces

    Monitoring DS1 Interfaces The following table describes the information displayed after you type an sdsl cell interface command. Column Port Interface Description Speed Admin Status Oper Status DS1 I ONITORING From the ::interfaces=> prompt, type the ds1 command in the following format, then press ENTER ds1 [<port>]...
  • Page 347 The following screen illustrates examples of both ds1 interfaces commands. ::interfaces=>ds1 4.3 Admin Port Speed Status 1544000 ::interfaces=>ds1 Admin Port Speed Status 1544000 1544000 1544000 1544000 The following table describes the information displayed after you type a ds1 interface command. Column Port Speed...
  • Page 348: Monitoring Ds3 Interfaces

    Monitoring DS3 Interfaces DS3 I ONITORING From the ::interfaces=> prompt, type the ds3 command in the following format, then ENTER press ds3 [<port>] Parameter [<port>] The specific port for which you want to display interface statistics (format slot.port). Omitting this parameter displays statistics for all DS3 interfaces. Examples ::interfaces=>...
  • Page 349 The following table describes the information displayed after you type a ds3 interface command. Column Port Speed Admin Status Oper Status LinkUpDown TrapEnable High Speed Connector Present Avidia System Configuration and Management User Manual Chapter 15: Monitoring Physical Interfaces Description The slot and port for which the information is displayed.
  • Page 350: Monitoring Oc3 Interfaces

    Monitoring OC3 Interfaces OC3 I ONITORING From the ::interfaces=> prompt, type the oc3 command in the following format, then ENTER press oc3 [<port>] [-path] Parameter [<port>] The specific port for which you want to display interface statistics (format slot.port). Omitting this parameter displays statistics for all OC3 interfaces. [-path] Type this parameter when displaying OC3 interfaces to display the SONET Path layer interface statistics.
  • Page 351: Monitoring Interfaces

    The following table describes the interface information that displays when you type a port command. Information Description Port The port number of the interface. Speed An estimate of the interface current bandwidth in bits per second. Admin Status The configured state of the interface. Options: •...
  • Page 352 Monitoring Interfaces Examples ::interfaces=> port 4.3 ::interfaces=> port The following screen illustrates examples of both commands. ::interfaces=>port 4.3 Port in octets delta 144354 24369 ::interfaces=>port Port in octets delta 144354 24369 144500 25432 130000 28476 Column Port in Octets delta out octets delta out octets...
  • Page 353: Chapter 16: Monitoring System Alarms And Status

    ONITORING LARMS AND This chapter describes how to monitor system alarms and messages in the command-line interface. Section Monitoring System Alarms and Events Monitoring SDSL Frame Alarms Monitoring SDSL Cell Alarms Monitoring IDSL Alarm Status Monitoring System Hardware Status Avidia System Configuration and Management User Manual YSTEM TATUS Page...
  • Page 354: Monitoring System Alarms And Events

    Monitoring System Alarms and Events ONITORING YSTEM You monitor system alarms and events from the ::admin=> prompt. From the ::root=> prompt, type admin then press To display information about alarms and events that have occurred since the system was powered up, including internal alarms such as memory and system fans, from the ::admin=> prompt type the log command in the following format then press log (alarm|all|debug|error|info|trace) Parameter...
  • Page 355 The following table describes the alarm information that displays when you type the log alarm command. Information Timestamp Type Slot Description When you type log all, a screen similar to the following displays. ::admin=>log all Timestamp THU, DEC 23 1999 06:50:40 THU, DEC 23 1999 06:50:40 THU, DEC 23 1999 06:50:40 Avidia System Configuration and Management User Manual...
  • Page 356 Monitoring System Alarms and Events The following table describes the information that displays when you type the log all command. Information Description Timestamp The time and date the event occurred. Type The type of event that occurred. Options: • alarm •...
  • Page 357: Monitoring Sdsl Frame Alarms

    SDSL F ONITORING You can monitor SDSL frame current alarm status and alarm history. Monitoring SDSL Frame Alarm Status You view the SDSL frame alarm table from the ::frame=> prompt. From the ::root=> prompt, type the following command then press display stats sdsl frame To display the SDSL frame alarm table, type the alarm command as follows then press alarm [<port>]...
  • Page 358 Monitoring SDSL Frame Alarms A screen similar to the following displays. ::frame=>alarm 3.7 Port LOSW Margin ::frame=>alarm Port LOSW Margin The following table describes the SDSL frame alarm history information that displays when you type the display alarm command. Alarm Type Slot Port LOSW...
  • Page 359: Monitoring Sdsl Frame Alarm History

    Monitoring SDSL Frame Alarm History You view the SDSL frame alarm history from the ::alarm=> prompt. From the ::root=> prompt, type the following command then press display alarm To display SDSL frame alarm history, type the sdsl command as follows then press sdsl [<port>] Parameter [<port>]...
  • Page 360: Monitoring Sdsl Cell Alarms

    Monitoring SDSL Cell Alarms The following table describes the SDSL frame alarm history information that displays when you type the display alarm command. The date and time each alarm first occurred and the date and time each alarm last occurred displays for each alarm type. The Count column displays the number of times the alarm has occurred since the SDSL frame card was last reset.
  • Page 361 Examples ::cell=> alarm 18.1 ::cell=> alarm A screen similar to the following displays. ::cell=>alarm 18.1 *****SDSL Cell Current Alarm Status Port 18.1***** LOSS Alarm: inactive(1) LOCD Alarm: inactive(1) SLOCD Alarm: inactive(1) Alarm: inactive(1) Hardware Status: ok(1) Last Changed: Thu, Jul 13 2000 12:27:58 ::cell=>alarm *****SDSL Cell Current Alarm Status Port 18.1***** LOSS...
  • Page 362 Monitoring SDSL Cell Alarms The following table describes the SDSL cell alarm history information that displays when you type the display alarm command. Alarm Type Port LOSS LOCD SLOCD Hardware Status Last Changed Description The slot and port of the card for which the alarm information is displayed.
  • Page 363: Monitoring Idsl Alarm Status

    IDSL A ONITORING Alarm status displays a summary of the alarm data for a specified IDSL line and port. You access IDSL alarm status from the ::idsl=> prompt. From the ::root=> prompt, type the following command then press disp stats idsl From the ::idsl=>...
  • Page 364 Monitoring IDSL Alarm Status A screen similar to the following displays. ::idsl=> alarm 5.2 ***** THE IDSL ALARM STATUS TABLE FOR PORT 5.2 Network Hourly Errored Seconds (ES): Network Hourly Severely Errored Seconds (SES): Network Daily Errored Seconds (ES): Network Daily Severely Errored Seconds (SES): Customer Hourly Errored Seconds (ES): Customer Hourly Severely Errored Seconds (SES): Customer Daily Errored Seconds (ES):...
  • Page 365: Monitoring System Hardware Status

    ONITORING YSTEM You monitor system status information, such as fuse and power alarms, and whether a critical, major or minor alarm condition exists. From the ::root=> prompt, type the following command then press ENTER display hardware system A screen similar to the following displays. ::hardware=>...
  • Page 366 Monitoring System Hardware Status Information FAN1, FAN2, FAN3, FAN4 PWR_MIN IP1 and IP2 FU1 and FU2 Port Card Description Most_Serious_Alarm Severity Description Chassis minor alarm LED status. Indicates whether a minor alarm condition exists. Displays either OFF or ON. Indicates whether an audio alarm is activated. Displays either OFF or ON.
  • Page 367: Chapter 17: System Maintenance And Administration

    YSTEM The command-line interface provides several convenient maintenance and administrative features. Go to the appropriate section listed below, based on the task you want to perform. Section Configuring and Initiating OAM Loopbacks Initiating Communication Path Loopbacks Managing IDSL Diagnostics Detecting Network Devices Managing Image Files Downloading Files to a Modem Managing Security...
  • Page 368: Configuring And Initiating Oam Loopbacks

    Configuring and Initiating OAM Loopbacks ONFIGURING AND OAM loopbacks enable the testing of PVCs by sending cells from one connection point of a PVC to another, where they are looped back to the originating point. Before beginning any OAM loopbacks, ensure that the OAM Source Location ID is set for the Avidia system as described in the following paragraph.
  • Page 369: Configuring And Initiating Oam Loopbacks

    Configuring and Initiating OAM Loopbacks Configure and initiate OAM loopbacks from the ::atm=> prompt. From the ::root=> prompt, type the following command then press diagnostic atm Select either an F4 OAM loopback or an F5 OAM loopback by doing one of the following: •...
  • Page 370 Configuring and Initiating OAM Loopbacks [-count <count>] The total number of cells to be sent (cells are sent one at a time). The range is 1 to 10. [-timeout <sec>] The number of seconds allowed for the looped back cells to return to the originating device before the loopback is designated as failed.
  • Page 371: Initiating Communication Path Loopbacks

    NITIATING OMMUNICATION The Avidia system supports loopbacks that enable you to test the data communication path between a card in the Avidia system and another device with the same transmission. You can run these loopbacks on DS1/DSX-1, DS3, and OC3 lines. The end-points for these tests are the near-end, which is the local Avidia card, and the far-end, which is the device (this could be another Avidia card) that is the remote end for the test.
  • Page 372: Initiating Oc3 Loopbacks

    Initiating Communication Path Loopbacks Initiating OC3 Loopbacks Configure OC3 service from the ::oc3=> prompt. From the ::root=> prompt, type the following command then press configuration oc3 From the ::oc3=> prompt, type the set command in the following format then press set <port>...
  • Page 373: Initiating Ds3 Loopbacks

    Parameters [-loopback (none|local|line|payload|remote)] The type of loopback to start. See the table on cancel the loopback. Examples ::ds1=> 2.1 -loopback payload ::ds1=> 2.1 -loopback none Initiating DS3 Loopbacks Configure DS3 service from the ::ds3=> prompt. From the ::root=> prompt, type the following command then press configuration ds3 From the ::ds3=>...
  • Page 374: Managing Idsl Diagnostics

    Managing IDSL Diagnostics IDSL D ANAGING IDSL diagnostics consist configuring and initiating IDSL loopbacks and the corrupted CRC test for a node or the entire connection path (loop). Corrupted CRC test results can be viewed (see “Monitoring IDSL Current Performance” on page Clearing Statistics You clear IDSL current performance statistics (see From the ::root=>...
  • Page 375: Configuring And Initiating Idsl Loopbacks

    Configuring and Initiating IDSL Loopbacks You can configure loopbacks on a specific loopback point for each port. The loopbacks occur in both the customer (downstream) and network (upstream) directions. The performance monitoring mode setting determines how statistics are collected (see Profiles”...
  • Page 376: Configuring And Initiating Corrupted Crcs

    Managing IDSL Diagnostics Configuring and Initiating Corrupted CRCs The corrupted CRC test generates CRC errors on the IDSL line. If the testing node is odd numbered (node 1, 3, 5, or 7), the CRCs generate upstream (toward the network). If the testing node is even numbered (0, 2, 4, or 6), the CRCs generate downstream (toward the customer).
  • Page 377: Displaying Idsl Loopback And Corrupted Crc Test Configurations

    Displaying IDSL Loopback and Corrupted CRC Test Configurations You view IDSL loopback and corrupted CRC test settings from the ::idsl=> prompt. From the ::root=> prompt, type the following command then press ::idsl=> prompt. disp stats idsl Type the following command in the following format, then press line [<port>] Parameter [<port>]...
  • Page 378 Managing IDSL Diagnostics The following screen illustrates an example of both line idsl commands. ::idsl=> line 5.1 Port Up_State Num_Seg down ::idsl=> line Port Up_State Num_Seg down down waiting down down down down down 5.10 down 5.11 down 5.12 down 5.13 down 5.14...
  • Page 379: Detecting Network Devices

    ETECTING ETWORK Use the ping command to detect whether a network device is online. When you issue a Ping command, an IP packet is sent to the requested remote device. If the target device receives the packet, it sends a reply back to the Avidia system, indicating that the target is online. From the ::admin=>...
  • Page 380: Managing Image Files

    Managing Image Files ANAGING MAGE It is recommended that you upload a copy of all configuration files to a TFTP server, so that you can easily download and restore the files if they get corrupted. You manage image files from the ::admin=> prompt. At the ::root=> prompt, type admin then press ENTER Uploading Files to a TFTP Server...
  • Page 381: Downloading Files From A Tftp Server

    Downloading Files from a TFTP Server You can restore Avidia system files by downloading the files from a TFTP server. Prior to downloading system files, it is recommended that you create a backup copy of your existing image file (if it is valid), using an .alt file name extension. See instructions.
  • Page 382: Copying Files

    Managing Image Files <slot> The slot number to which you want to download the file. To download the file to multiple slots, type each slot number separated by a space. [<file name>] The complete destination path and filename, using a forward slash (/) to indicate a directory.
  • Page 383: Displaying A Directory Of Files On A Card

    Examples ::admin=> copy 1 bigfile.txt 10 bigfile.txt (Copies the file to a different card using the same file name.) ::admin=> copy 1 amc.bin 1 amc.alt (Copies the file to a different file name on the same card.) Displaying a Directory of Files on a Card To display a directory of all the files stored in NVRAM on a particular card, from the ::admin=>...
  • Page 384: Downloading Files To A Modem

    Downloading Files to a Modem OWNLOADING You can download files from an ADSL, SDSL frame, or SDSL cell channel card to an attached modem, however you can only download a single file to a single modem at one time. You download files to a modem from the ::admin=> prompt. From the ::root=> prompt, type the following command then press admin Type the modemxfer command in the following format then press...
  • Page 385: Managing Security

    ANAGING ECURITY The command-line interface comes with the user account admin and password dslam preconfigured. You can change the admin password, however you cannot delete the admin user account. You can add up to 11 additional user accounts, and configure the password, security level and access methods for each account.
  • Page 386 Managing Security Parameters <name> The unique user name for the account. This is the name the user will use to log on to the command-line interface. The user name must contain between four and 16 alphanumeric characters and the first character must be a letter. The user name cannot contain spaces, but can contain multiple words separated by an underscore.
  • Page 387: Displaying User Accounts

    Displaying User Accounts From the ::user=> prompt, type the show command then press show The following screen illustrates an example of the show command. ::user=> show Index UserName ------------------------------------------------------- admin general_access Monitor manager Modifying User Accounts Only users with a security level of Administrator can modify existing user accounts.
  • Page 388 Managing Security Parameters <index> The index number of the user you want to modify. <security level> The access level for the account. Choose one of the following. Security Abbreviation Level Monitoring Provisioning Administrator Admin <access method> The method(s) by which the user is allowed to access the command line interface. For multiple access methods, list the letter for each.
  • Page 389: Deleting User Accounts

    Deleting User Accounts Only users with a security level of Administrator can delete user accounts. The admin user account cannot be deleted. From the ::user=> prompt, type the show command then press Note the index number of the user you want to delete. From the ::user=>...
  • Page 390: Changing A User Password

    Displaying System Inventory Changing a User Password The password command changes the login password for the current user. No user can change the password for another user. From the ::user=> prompt, type the show command then press password At the prompt, type the current password then press At the prompt, type the new password then press The password must be between 4 and 16 alphanumeric characters and the first character must be a letter.
  • Page 391: Viewing Sdsl Frame Cpe General Information

    The following screen illustrates an example of both display cards commands. ::hardware=> cards Slot Description management 12 port,ADSL/DMT/CELL OC-3/ATM/LINE ::hardware=> cards 3 Slot Description 12 port,ADSL/DMT/CELL SDSL F IEWING You can view the software version number for each modem that is attached to an SDSL frame port.
  • Page 392: Rebooting Cards

    Rebooting Cards A screen similar to the following displays. ::frame=> SDSL Modem (CPE) Port Version Information Port VerNo EBOOTING ARDS You can reboot an individual card, or the entire Avidia system, two different ways: • Perform a cold boot by recycling power to the system. This reinitializes the card memory, including resetting the system log.
  • Page 393: Rebooting An Individual Card

    Rebooting an Individual Card To reboot an individual card, from the ::admin prompt type the reboot command in the following format then press reboot <slot> [-y] Parameter <slot> The slot in which the card you want to reboot is installed. <-y>...
  • Page 394: Deleting Files

    Deleting Files Parameter <minutes> Specifies the number of minutes after which, if no keyboard input is received, the command-line interface automatically logs the current user off the command-line interface. The maximum timeout value is 2146483647. Omitting this parameter displays the current timeout value.
  • Page 395: Part Iii: The Avidia Web Interface

    This section contains the following chapters, which explain how to manage an Avidia system using the Avidia Web interface: Chapter Number Chapter Title Introduction to the Web Interface Configuring System Parameters Configuring Subscriber Services Configuring Network Services Configuring ATM Virtual Circuits Configuring Frame Relay Interworking Configuring Bridging and Routing Monitoring Subscriber Connections...
  • Page 396 Avidia System Configuration and Management User Manual...
  • Page 397: Chapter 18: Introduction To The Web Interface

    The Avidia Web interface provides Avidia system management, including configuration, performance monitoring, and system maintenance and administration. The Web interface comes preinstalled on the Avidia management card built-in Web server. You access the Web interface using a Web browser, either over a network or using a PC connected directly to the Fast Ethernet port on the back of the Avidia system.
  • Page 398: Logging On To The Web Interface

    Logging On to the Web Interface OGGING N TO THE Open your Web browser, type the Avidia management card IP address in the address box (format xxx.xxx.xxx.xxx), then press address, see “Preparing for System Configuration and Management” on page 11 instructions.
  • Page 399 Click Log On Close Window? dialog displays. Click to close the dialog. Site Map Navigation Multiple users can access the Web interface simultaneously, as all user configurations are stored in a queue and executed in the order in which the Web interface receives them.
  • Page 400: Navigating The Web Interface

    Navigating the Web Interface AVIGATING THE The Web interface provides two different methods of navigation: the window and the Tree Navigation which displays immediately after you successfully log on to the Web interface. To display the Tree Navigation window, click Site Map Navigation Window Site Map Navigation indicate window category headings, and are not selectable.
  • Page 401: Tree Navigation Window

    Tree Navigation Window Tree Navigation window contains five primary folders, from which a hierarchy of folders and windows stem. Click a folder to display its subfolders. Selectable windows are underlined in blue. Click a window name to open that window. Avidia System Configuration and Management User Manual Chapter 18: Introduction to the Web Interface...
  • Page 402: Web Interface Conventions

    Web Interface Conventions NTERFACE Typeface conventions: • This font indicates a reference to an element on the screen. • Italic type indicates the format in which you type the information specified in the procedure. ETTING Each Web interface window contains a system that corresponds to that window.
  • Page 403: Chapter 19: Configuring System Parameters

    ONFIGURING This chapter describes how to configure system parameters, such as system identifiers and management card IP addresses. Section Opening the System Settings Window Configuring System Identification Configuring Management Card IP Addresses Configuring System Trap Generation Status Configuring Boot File Information Configuring System Date and Time Avidia System Configuration and Management User Manual YSTEM...
  • Page 404: System Settings Window

    Opening the System Settings Window PENING THE You configure system parameters from the • In the Site Map Navigation • In the Tree Navigation System Settings window opens, with the following read-only information displayed: Information AMC Card Ethernet Port MAC Address AMC Card Ethernet Port IP Address AMC Card Ethernet Port Subnet Mask AMC Card Ethernet Port Default Gateway The management card Ethernet port default gateway IP address.
  • Page 405 Chapter 19: Configuring System Parameters Avidia System Configuration and Management User Manual...
  • Page 406: Configuring System Identification

    Configuring System Identification ONFIGURING To facilitate network management, you should assign a name to the system, identify who to contact regarding the system, and specify the system location. You use text strings to specify this information. In the System Settings The text string can contain any keyboard characters other than quotation marks and can be any length.
  • Page 407: Configuring Management Card Ip Addresses

    ONFIGURING You set the management card IP address, subnet mask and default gateway (if one exists) to enable communication with external networks. While you must initially set the IP addresses using the command-line interface, you can change this information using the Web interface. All IP addresses use the format xxx.xxx.xxx.xxx.
  • Page 408: Configuring System Trap Generation Status

    Configuring System Trap Generation Status ONFIGURING Traps are messages sent from the management card regarding system events, such as alarms. The Avidia system distinguishes between two types of traps. Agent authentication traps are generated when the system receives an invalid SNMP community string. (See Community Strings”...
  • Page 409 If the Boot Mode is set to In the Boot Server IP Address image file you want to boot is stored (format xxx.xxx.xxx.xxx). In the Boot File box type the complete path and file name, including file name extension, of the image file you want the management card to boot. The management card image file name is amc.bin.
  • Page 410: Configuring System Date And Time

    Configuring System Date and Time ONFIGURING It is important to set the system date and time so the alarms and events logs reflect the actual time each event occurred. In the System Settings Set Date/Time window displays. In the Date box, type the current date in mm/dd/yyyy format.
  • Page 411: Chapter 20: Configuring Subscriber Services

    ONFIGURING This chapter describes how to configure service for ADSL, SDSL and IDSL lines. Section Configuring ADSL Line Profiles Configuring ADSL Alarm Profiles Configuring ADSL Service Configuring SDSL Frame Line Profiles Configuring SDSL Frame Alarm Profiles Configuring SDSL Frame Service Configuring SDSL Cell Line Profiles Configuring SDSL Cell Alarm Profiles Configuring SDSL Cell Service...
  • Page 412: Configuring Adsl Line Profiles

    Configuring ADSL Line Profiles ADSL L ONFIGURING ADSL line profiles contain a preconfigured set of parameters, including the transmit rate, rate adaptation mode, target margin and interleave depth. You assign line profiles to ADSL ports during port configuration. A default profile exists with an index of 1. You cannot delete the default profile.
  • Page 413 Adding ADSL Line Profiles You add ADSL line profiles from the In the Rate Mode box, select the desired rate mode ( The rate mode defines the form of transmit rate adaptation. be able to come up at the specified maximum transmit rate at all.
  • Page 414: Configuring Adsl Alarm Profiles

    Configuring ADSL Alarm Profiles Deleting ADSL Line Profiles You cannot delete profiles that are assigned to ports. You cannot delete the default profile. In the ADSL Line Profile Table configuration profile you want to delete. Click if necessary to view the entire table. table.
  • Page 415 ADSL Alarm Profile Table if necessary to view the entire table. displays the next page of the table. Adding ADSL Alarm Profiles You add ADSL Alarm profiles from the In the Upstream Downstream 15 Minutes Threshold Loss of Frame this threshold, or type 0 to disable the trap. The loss of frame threshold determines the acceptable number of seconds in a 15-minute ADSL performance data collection period during which the frames lose sync on the ADSL interface.
  • Page 416 Configuring ADSL Alarm Profiles In the Upstream Downstream 15 Minutes Threshold Errored Seconds this threshold, or type 0 to disable the trap. The errored seconds threshold determines the acceptable number of seconds during which errors occur on the ADSL interface that prevent the payload from being corrected. In a normal environment with sufficient margin, a typical errored seconds threshold value is 10.
  • Page 417: Configuring Adsl Service

    ADSL S ONFIGURING You configure ADSL service for each port by specifying a line profile and an alarm profile. Each ADSL port is assigned a default configuration. The default profile index for each ADSL profile type is 1. This procedure describes how to modify the configuration to reflect the desired service.
  • Page 418 Configuring ADSL Service In the boxes, type the desired line profile index for each port you want to Line Profile configure. Click the Line Profile Browse is not yet configured, you can configure it now. See page 386 for instructions. In the Alarm Profile boxes, type the desired alarm profile index for each port you want to...
  • Page 419: Configuring Sdsl Frame Line Profiles

    If handshaking is set to g.dmt Do one of the following: • Click to activate the new settings. • Click to cancel the new settings. You can only cancel the settings if you have not clicked • In the Slot box select the slot number to configure ports on another card.
  • Page 420: Adding Sdsl Frame Line Profiles

    Configuring SDSL Frame Line Profiles Adding SDSL Frame Line Profiles Fixed Rate is the only supported setting. In the box, type the transmit rate in Kbps. Rate (Kbps) The valid range supported by the SDSL card is from 64 to 2,048, in increments of 64. However, the specified rate must be supported by the remote modem.
  • Page 421: Configuring Sdsl Frame Alarm Profiles

    SDSL F ONFIGURING SDSL alarm profiles determine the conditions that generate SNMP traps. When the configured thresholds are met or exceeded, the SNMP agent sends a trap to the configured trap receiver(s). Only one trap is sent for each 15-minute data collection period. You assign SDSL alarm profiles to ports during port configuration.
  • Page 422: Deleting Sdsl Frame Alarm Profiles

    Configuring SDSL Frame Alarm Profiles In the Alarm Setting UAS enable In the Threshold Margin When the margin falls below the specified threshold, the margin alarm is activated. A typical margin threshold value is 6. In the Threshold ES box, type the desired errored seconds threshold. When the number of errored seconds in the current 15-minute data collection interval exceeds the specified threshold, the errored seconds alarm is activated.
  • Page 423: Configuring Sdsl Frame Service

    Click Delete Checked Row(s) A confirmation dialog displays. Click to delete the selected table rows, otherwise click SDSL F ONFIGURING You configure SDSL service for each port by specifying a line profile and an alarm profile. Each SDSL port is assigned a default configuration. The default profile index for each SDSL profile type is 1.
  • Page 424 Configuring SDSL Frame Service In the Line Profile boxes, type the desired line profile index for each port you want to configure. Click the Line Profile Browse is not yet configured, you can configure it now. See Profiles” on page 393 button to display the configured profiles.
  • Page 425: Configuring Sdsl Cell Line Profiles

    In the Alarm Profile boxes, type the desired alarm profile index for each port you want to configure. Click the Alarm Profile Browse is not yet configured, you can configure it now. See Profiles” on page 395 Do one of the following: •...
  • Page 426: Adding Sdsl Cell Line Profiles

    Configuring SDSL Cell Line Profiles Adding SDSL Cell Line Profiles You add SDSL cell line profiles from the In the Code box, select the line coding. The line code sets the line coding for the port. Currently, coding. 2B1Q SDSL cell technology provides the equivalent of 1.544 Mbps digital transmission rates, plus signaling over two copper pairs.
  • Page 427: Deleting Sdsl Cell Line Profiles

    Deleting SDSL Cell Line Profiles You cannot delete profiles that are assigned to ports. You cannot delete the default profile. In the SDSL Cell Line Profile Table line configuration profile you want to delete. Click if necessary to view the entire table. table.
  • Page 428: Adding Sdsl Cell Alarm Profiles

    Configuring SDSL Cell Alarm Profiles SDSL Cell Alarm Profile Table Click if necessary to view the entire table. displays the next page of the table. Adding SDSL Cell Alarm Profiles You add SDSL cell alarm profiles from the In the Loss of Cell Delineation trap.
  • Page 429: Deleting Sdsl Cell Alarm Profiles

    In the box, type a value for this threshold, or type 0 to disable the trap. The signal-to-noise ratio threshold determines how much margin can be dropped before the number of bit errors exceeds the ratio of 1x10 Click to add the SDSL cell alarm profile. Deleting SDSL Cell Alarm Profiles You cannot delete profiles that are assigned to ports.
  • Page 430: Configuring Sdsl Cell Service

    Configuring SDSL Cell Service SDSL C ONFIGURING You configure SDSL service for each port by specifying a line profile and an alarm profile. Each SDSL cell port is assigned a default configuration. The default profile index for each SDSL cell profile type is 1.
  • Page 431 Chapter 20: Configuring Subscriber Services In the Line Profile boxes, type the desired line profile index for each port you want to configure. Click the Line Profile Browse button to display the configured profiles. If the desired profile is not yet configured, you can configure it now. See “Configuring SDSL Cell Line Profiles”...
  • Page 432: Configuring Idsl Line Profiles

    Configuring IDSL Line Profiles In the Alarm Profile boxes, type the desired alarm profile index for each port you want to configure. Click the Alarm Profile Browse is not yet configured, you can configure it now. See Profiles” on page 401 Do one of the following: •...
  • Page 433: Adding Idsl Line Profiles

    Adding IDSL Line Profiles You add IDSL line profiles from the In the Rate box, select the desired transmission rate on the link in kbps (64, 128, or 144). In the Performance Monitor The mode determines how IDSL current performance data (see Performance”...
  • Page 434: Deleting Idsl Line Profiles

    Configuring IDSL Alarm Profiles Deleting IDSL Line Profiles You cannot delete profiles that are assigned to ports. You cannot delete the default profile. In the IDSL Line Configuration Profile Table IDSL line configuration profile you want to delete. Click if necessary to view the entire table. table.
  • Page 435: Adding Idsl Alarm Profiles

    IDSL Alarm Profile Table if necessary to view the entire table. the next page of the table. Adding IDSL Alarm Profiles You add IDSL Alarm profiles from the In the Hourly ES box, type the errored second threshold in seconds, or type trap.
  • Page 436: Deleting Idsl Alarm Profiles

    Configuring IDSL Alarm Profiles In the Daily SES box, type the desired severely errored second threshold in seconds, or type to disable this trap. The range is 0 to 2047, with 25 as the default. The Daily SES Threshold is the number of severely errored seconds that must be met or exceeded on the IDSL line within a day for an alarm to display.
  • Page 437: Configuring Idsl Service

    IDSL S ONFIGURING You assign IDSL service for the card by specifying the transmit clock source and for each port by specifying a line profile and alarm profile. Each IDSL port is assigned a default configuration. This procedure describes how to modify the configuration to reflect the desired service.
  • Page 438 Configuring IDSL Service Avidia System Configuration and Management User Manual...
  • Page 439 In the Clock Source box, select the transmit clock source for the IDSL card ( System B • Local —The IDSL card derives timing from the IDSL card clock. • System A —The IDSL card derives timing from the Avidia system reference clock on channel A.
  • Page 440 Configuring IDSL Service Avidia System Configuration and Management User Manual...
  • Page 441: Chapter 21: Configuring Network Services

    ONFIGURING This chapter describes how to set up network-side services by configuring line card ports. Section Configuring OC3 Service Configuring DS1 Service Configuring DS3 Service Avidia System Configuration and Management User Manual ETWORK ERVICES Page...
  • Page 442: Configuring Oc3 Service

    Configuring OC3 Service OC3 S ONFIGURING Do one of the following to open the • In the Site Map Navigation • In the Tree Navigation Configuration Select the slot and port you want to configure, then click OC3 Configuration In the Optic Medium Type SONET ERVICE...
  • Page 443: Configuring Ds1 Service

    In the Cell Scrambling Enables or disables cell scrambling. Cell scrambling, used in Avidia, is not an ATM defined format for DS1, but is implemented by many vendors. An ATM cell has two parts: header and payload. Cell scrambling scrambles the payload so that it does not resemble the header.
  • Page 444 Configuring DS1 Service Do one of the following to open the • In the Site Map Navigation • In the Tree Navigation Configuration Select the slot and port you want to configure, then click window. Port Configuration - Slot/Port Selection window, click Port Configuration window, click...
  • Page 445 Chapter 21: Configuring Network Services Avidia System Configuration and Management User Manual...
  • Page 446 Configuring DS1 Service DS1 Configuration changed. Information Card Description Slot Port Oper Status Elapsed Time Valid Intervals Invalid Intervals Line Status Last Line Status Change Send Code Facilities Data Link Loopback Status window displays the following status information that cannot be Descriptions The slot number, port number and description of the selected card.
  • Page 447 In the Circuit Identifier In the LBO/Equalization • For a DS1 line, select the equalization ( • For a DSX1 line, select the line length ( 266 to 399 feet (121 m), In the Line Code box, select the type of coding on the line ( In the Framing box, select the type of line connected to the selected port (...
  • Page 448: Configuring Ds3 Service

    Configuring DS3 Service DS3 S ONFIGURING Do one of the following to display the • In the Site Map Navigation • In the Tree Navigation Configuration Select the slot and port you want to configure, then click window. ERVICE Port Configuration - Slot/Port Selection window, click Port Configuration window, click...
  • Page 449 Chapter 21: Configuring Network Services Avidia System Configuration and Management User Manual...
  • Page 450 Configuring DS3 Service DS3 Configuration changed. Information Card Description Slot Port Oper Status Elapsed Time Valid Intervals Invalid Intervals Send Code Line Status Last Line Status Change Loopback Status In the box, select the line length ( In the Framing box, select the type of line connected to the selected port ( CbitParity is not currently supported.
  • Page 451 In the Cell Scrambling Enables or disables cell scrambling. Cell scrambling, used in Avidia, is not an ATM defined format for DS1, but is implemented by many vendors. An ATM cell has two parts: header and payload. Cell scrambling scrambles the payload so that it does not resemble the header.
  • Page 452 Configuring DS3 Service Avidia System Configuration and Management User Manual...
  • Page 453: Chapter 22: Configuring Atm Virtual Circuits

    ONFIGURING This chapter describes how to establish connections between ports across the Avidia chassis. Section Configuring ATM Traffic Profiles Configuring APS Configuring PVPCs Configuring PVCCs Configuring SPVCs Configuring ATM Routing Configuring ATM Interface Information Configuring ATM Policing Avidia System Configuration and Management User Manual ATM V IRTUAL IRCUITS...
  • Page 454: Configuring Atm Traffic Profiles

    Configuring ATM Traffic Profiles ATM T ONFIGURING You configure ATM traffic profiles from the To open the ATM Traffic Descriptor Configuration Table Do one of the following: • In the Site Map Navigation Configuration • In the Tree Navigation Configuration PVPC Configuration In the window you opened in In the Traffic Profile box, click...
  • Page 455: Adding Atm Traffic Profiles

    Adding ATM Traffic Profiles ATM traffic profiles are stored in the profile has an index number assigned to it. You use the index number to assign a profile to an ATM connection. In the Traffic Type box, select the desired traffic descriptor type ( The text boxes to the right display the default parameter values for the selected traffic type.
  • Page 456: Deleting Atm Traffic Profiles

    Configuring APS Deleting ATM Traffic Profiles You cannot delete profiles that are assigned to ports. In the ATM Traffic Descriptor Configuration Table the ATM traffic descriptor profile you want to delete. Click if necessary to view the entire table. table. displays the next page of the table.
  • Page 457: Configuring Aps

    Select the slot you want to configure, then click Configuring APS In the box, select Admin Status The default is disabled. In the Trap box, select In the Mode box, select the desired APS mode: • Non Revertive Manual— automatically switch back to the working channel when the failure on that channel has been cleared (this is the default).
  • Page 458: Issuing Manual Aps Commands

    Configuring APS If you selected Revertive that you want the system to wait before switching traffic from the protection channel back to the working channel after a failure on the main channel has been cleared. Otherwise, skip this step. The range is 300 to 720 seconds. The default is 300 seconds. Do one of the following: •...
  • Page 459 PVPC ONFIGURING Configure PVPCs from the optionally configure backup PVPCs for the primary PVPCs. Backup PVPCs are redundant to primary PVPCs. A primary PVPC automatically switches to a backup PVPC if the primary PVPC were to fail. Do one of the following to open the •...
  • Page 460: Configuring Pvpcs

    Configuring PVPCs The following sections provide instruction on: • adding primary PVPCs • changing PVPC admin status • deleting PVPCs (page • adding backup PVPCs • deleting backup PVPCs • returning service from a backup PVPC to a primary PVPC Adding Primary PVPCs page 433 to open the...
  • Page 461 In the Admin Status box, select the administrative status for the PVPC ( activates the PVPC. In the Channel Slot box, select the channel-side card slot number you want to use for this PVPC. In the Channel Port box, select the channel-side card port number you want to use for this PVPC.
  • Page 462 Configuring PVPCs Identify the two index numbers for the profiles you want to apply to the downstream and upstream traffic directions for this PVPC, then window. Table In the Traffic Profile Tx Idx direction. In the Traffic Profile Rx Idx direction.
  • Page 463: Changing Pvpc Admin Status

    Changing PVPC Admin Status page 433 to open the In the PVPC Configuration Table contains the PVPC for which you want to change the status. Click if necessary to view the entire table. table. displays the next page of the table. The Down activates the PVPC;...
  • Page 464: Deleting Pvpcs

    Configuring PVPCs Deleting PVPCs page 433 to open the If you remove a card from the system, the PVPCs associated with the ports on that card are disabled, however the PVPC configuration is not automatically removed from the PVPC Configuration Table. Be sure to delete unused PVPC configurations so the PVPC Configuration Table accurately reflects the PVPCs in use in the system.
  • Page 465: Adding Backup Pvpcs

    Do one of the following: • Click Delete to delete the selected PVPC, then in the confirmation dialog click return to the PVPC Configuration Table • Click Cancel to return to the PVPC. Adding Backup PVPCs page 433 to open the PVPC Configuration Table of the following: •...
  • Page 466 Configuring PVPCs Add to an Existing Primary PVPC From the PVPC Configuration Table you will create a backup. The following Add PVPC Dual Homing Backup Line Slot Port , and values for the primary PVPC automatically display. In the Secondary Slot box, select the slot for the secondary or backup line-side card you want to use for this backup PVPC.
  • Page 467: Deleting Backup Pvpcs

    Deleting Backup PVPCs page 433 to open the Backup Line window, you can only delete a backup PVPC. Locate the table row that contains the Click if necessary to view the entire table. table. displays the next page of the table. Under Backup for the backup PVPC you want to delete, click the...
  • Page 468: Returning Service From A Backup Pvpc To A Primary Pvpc

    Configuring PVPCs Returning Service from a Backup PVPC to a Primary PVPC page 433 to open the primary PVPC. Locate the table row that contains the primary PVPC that has switched to a backup PVPC. Click if necessary to view the entire table. table.
  • Page 469 PVCC ONFIGURING Configure PVCCs from the optionally configure backup PVCCs for the primary PVCCs. Backup PVCCs are redundant to primary PVCCs. A primary PVCC automatically switches to a backup PVCC if the primary PVCC were to fail. Do one of the following to open the •...
  • Page 470: Configuring Pvccs

    Configuring PVCCs The following sections provide instruction on: • adding primary PVCCs • changing PVCC admin status • deleting PVCCs (page • adding backup PVCCs • deleting backup PVCCs • returning service from a backup PVCC to a primary PVCC Adding Primary PVCCs page 443 to open the...
  • Page 471 In the PVCC Configuration Table PVCC Configuration Table is automatically assigned, therefore no In the Admin Status box, select the desired setting ( activates the PVCC. In the Channel Slot box, select the slot number you want to use for this PVCC. In the Channel Port box, select the port number you want to use for this PVCC.
  • Page 472 Configuring PVCCs In the Channel Encap box, select the encapsulation mode. (For llc-8023 vc-mux-8023 proprietary protocol service type, select This setting must match the encapsulation protocol used at the remote end. The default is llc-8023 encapsulation. The llc-8023 (Logical Link Control) encapsulation is supported by most ATM devices but has more overhead than vc-mux encapsulation.
  • Page 473 Identify the two index numbers for the profiles you want to apply to the downstream and upstream traffic directions for this PVCC, then window. Table In the Traffic Profile Tx Idx direction. In the Traffic Profile Rx Idx direction. Do one of the following in the •...
  • Page 474: Changing Pvcc Admin Status

    Configuring PVCCs Changing PVCC Admin Status page 443 to open the In the PVCC Configuration Table contains the PVCC for which you want to change the status. Click if necessary to view the entire table. table. displays the next page of the table. The Down activates the PVCC.
  • Page 475: Deleting Pvccs

    Deleting PVCCs page 443 to open the If you remove a card from the system, the PVCCs associated with the ports on that card are disabled, however the PVCC configuration is not automatically removed from the PVCC Configuration Table. Be sure to delete unused PVCC configurations so that the PVCC Configuration Table accurately reflects the PVCCs in use in the system.
  • Page 476: Adding Backup Pvccs

    Configuring PVCCs Do one of the following: • Click Delete to delete the selected profile, then in the confirmation dialog click to return to the PVCC Configuration Table • Click Cancel to return to the the profile. Adding Backup PVCCs page 443 to open the PVCC Configuration Table...
  • Page 477 Add to an Existing Primary PVCC From the PVCC Configuration Table you will create a backup. The following Add PVCC Dual Homing Backup Line Slot Port , and values for the primary PVCC automatically display. In the Secondary Slot box, select the slot for the secondary or backup line-side card you want to use for this backup PVCC.
  • Page 478: Deleting Backup Pvccs

    Configuring PVCCs Deleting Backup PVCCs page 443 to open the Backup Line window, you can only delete a backup PVCC. Locate the table row that contains the Click if necessary to view the entire table. table. displays the next page of the table. Under Backup for the backup PVCC you want to delete, click the...
  • Page 479: Returning Service From A Backup Pvcc To A Primary Pvcc

    Returning Service from a Backup PVCC to a Primary PVCC page 443 to open the primary PVCC. Locate the table row that contains the primary PVCC that has switched to a backup PVCC. Click if necessary to view the entire table. table.
  • Page 480: Configuring Spvcs

    Configuring SPVCs SPVC ONFIGURING SPVCs (Soft Permanent Virtual Circuits) provide a PVC between the CPE and the line card, and an SVC (Switched Virtual Circuit) between the line card and the destination ATM end system. SVCs are virtual connections that are established through an ATM network using signaling (the end-points are defined when the call is initiated and terminated at the end of the call).
  • Page 481 Click if necessary to view the entire table. displays the next page of the table. The SPVC Configuration table displays the following information for each SPVC. Information Admin Status Oper Status Source Slot Source VPI Source VCI Source Encap Destination Address Destination Retry Interval The number of seconds the system waits before attempting Destination Retry Limit Last Rel.
  • Page 482 Configuring SPVCs Adding SPVCs In the SPVC Configuration Add SPVC Configuration In the Admin Status box, select In the Channel Slot In the Channel VPI the line card. If the PVCC uses a frame channel card, in the mode (options: LLC_8023 In the Destination ATM Address...
  • Page 483: Configuring Atm Routing

    In the Destination Retry Limit The retry limit is the maximum number of allowable unsuccessful call setup attempts. In the Tx Idx box, type the traffic descriptor profile index to assign to transmitted traffic. To view the ATM Traffic Descriptor Configuration Table In the Rx Idx box, type the traffic descriptor profile index to assign to received traffic.
  • Page 484 Configuring ATM Routing Click if necessary to view the entire table. displays the next page of the table. The ATM Routing table displays the following information. Information Slot Admin Status Oper Status ATM Destination Address The destination ATM address of the static route. Matching Length Description The line card slot to which you want to route the traffic when the current...
  • Page 485 Adding ATM Routing Table Entries In the ATM Routing Table want to route traffic when the current line card fails. In the Admin box, select In the Matching Length want the system to consider when determining whether the ATM Routing Table entry matches a particular SPVC.
  • Page 486: Configuring Atm Interface Information

    Configuring ATM Interface Information ATM I ONFIGURING ATM System Interface window displays the ATM System Prefix for the Avidia system as well as ATM interface information for the selected line card. The ATM interface parameters are initially set to default values, however you can modify the parameters. You configure ATM interface information in the Do one of the following: •...
  • Page 487 In the ATM System Prefix 19 octets. Use the Type box to select the type of ATM interface for the selected card: • IISP Private —an interface between two Avidia systems that uses IISP static routes for line card redundancy. •...
  • Page 488: Configuring Atm Policing

    Configuring ATM Policing ATM P ONFIGURING Policing, or UPC, enables you to specify whether traffic must conform to the configured traffic contract. When policing is enabled, traffic that does not conform to the contract is deleted. You can enable or disable policing by: •...
  • Page 489 For each physical port, in the policing on the corresponding ATM port. Do one of the following: • To activate the settings and close the confirmation dialog click • Click to cancel the new settings. You can only cancel the new settings if you have not clicked Avidia System Configuration and Management User Manual Chapter 22: Configuring ATM Virtual Circuits...
  • Page 490: Pvcc Policing

    Configuring ATM Policing PVCC Policing You configure PVCC policing from the open the ATM PVCC Policing • In the Site Map Navigation • In the Tree Navigation Policing Click if necessary to view the entire beginning of the table. status of a PVCC, click the button in the corresponding between Enabled Disabled...
  • Page 491: Pvpc Policing

    PVPC Policing You configure PVPC policing from the open the ATM PVPC Policing • In the Site Map Navigation • In the Tree Navigation Policing Click if necessary to view the entire beginning of the table. status for a PVPC, click the button in the corresponding between Enabled Disabled...
  • Page 492 Configuring ATM Policing Avidia System Configuration and Management User Manual...
  • Page 493: Chapter 23: Configuring Frame Relay Interworking

    ONFIGURING This chapter describes how to configure frame relay from the Web interface. Section The Frame Relay Interworking Configuration Table Adding a Frame Relay Configuration Modifying a Frame Relay Configuration Viewing an Entire Frame Relay Configuration Deleting a Frame Relay Configuration Avidia System Configuration and Management User Manual RAME ELAY...
  • Page 494: The Frame Relay Interworking Configuration Table

    The Frame Relay Interworking Configuration Table RAME ELAY ABLE You configure frame relay from the Do one of the following: • In the Site Map Navigation • In the Tree Navigation Relay Frame Relay Interworking Configuration Table configurations. Click beginning of the table. NTERWORKING Frame Relay Interworking Configuration Table window, click...
  • Page 495 Frame Relay Interworking Configuration Table subset of the frame relay parameters set using the window. Status Box Admin Status Oper. Status Channel Slot Line Card Line Slot Line VPI Line VCI Data Link LMI Type Circuit DLCI Interworking Traffic Type Avidia System Configuration and Management User Manual Chapter 23: Configuring Frame Relay Interworking window displays the operating status and a...
  • Page 496: Adding A Frame Relay Configuration

    Adding a Frame Relay Configuration DDING A RAME You add a frame relay configuration from the window. In the Frame Relay Interworking Configuration Table Interworking Configuration In the Admin Status box, select connection or Down to deactivate it. In the Channel row, do the following: In the...
  • Page 497 In the Line row, do the following: In the Slot box, select the slot of the line card. In the Port box, select the port of the line card. In the box, type the frame relay (fr) VPI of the fr VCC between the frame channel card and the line card.
  • Page 498 Adding a Frame Relay Configuration In the Error Threshold 3 as the default. Error Threshold is the number of consecutive poll intervals in which the LMI status inquiry messages are not received that are required for the link to be declared down. In the Monitor Events 4 as the default.
  • Page 499 In the Committed Burst is 0 to 144000, with 0 as the default. Committed Burst is the maximum number of data bits that the network will transfer under normal conditions during the measurement interval. In the Throughput 144000, with 0 as the default. Throughput is the average number of data bits transferred per second across the network interface in one direction.
  • Page 500 Adding a Frame Relay Configuration In the CLP Mask box, select the mask used when The CLP Mask determines the content of the ATM cell CLP field when set to —The network cannot discard cells. —The network can discard cells. If you selected Interworking In the LP Mode...
  • Page 501: Modifying A Frame Relay Configuration

    In the DE Value box, select the value used when The DE Value determines the content of the frame relay DE field when —The network cannot discard frames. —The network can discard frames. Do one of the following: • To save the frame relay configuration click to return to the Back •...
  • Page 502 Modifying a Frame Relay Configuration To modify the administrative status, in the activate the frame channel card and line card connection or In the row, unless Data Link To modify the poll interval value, in the valid range is 5 to 30, with 10 as the default. To modify the inquiry interval value, in the range is 1 to 255, with 6 as the default.
  • Page 503 Interworking FRF.8 displays, you can do the following: To modify the LP Mode, in the To modify the LP Value. in the To modify the CI Mode, in the To modify the DE Mode, in the To modify the DE Value, in the Do one of the following: •...
  • Page 504: Viewing An Entire Frame Relay Configuration

    Viewing an Entire Frame Relay Configuration IEWING AN NTIRE You view an entire frame relay configuration from the Table window. In the Frame Relay Interworking Configuration Table the frame relay interworking configuration you want to view. Click if necessary to view the entire table. table.
  • Page 505 Status Box Admin Status Channel Slot Channel Port Line Slot Line Port Line VPI Line VCI Data Link LMI Type Data Link Poll Interval Data Link Inquiry Interval Data Link Error Threshold Data Link Monitor Events Avidia System Configuration and Management User Manual Chapter 23: Configuring Frame Relay Interworking Description The administrative status of the frame channel card...
  • Page 506 Viewing an Entire Frame Relay Configuration Status Box Circuit Traffic Type Circuit DLCI Circuit Excess Burst Circuit Committed Burst Circuit Throughput FRF.5 Rx LP Mode Description The type determines the traffic class. ubr (Unspecified Bit Rate)—This is a best-effort class of traffic that is best suited for LAN.
  • Page 507 Status Box FRF.5 Tx LP Mode FRF.5 CLP Mask FRF.8 LP Mode FRF.8 LP Value FRF.8 CI Mode Avidia System Configuration and Management User Manual Chapter 23: Configuring Frame Relay Interworking Description The Tx LP Mode, which determines the content of the FR-SSCS PDU header DE and ATM cell ATM CLP fields.
  • Page 508 Viewing an Entire Frame Relay Configuration Status Box FRF.8 DE Mode FRF.8 DE Value To cancel viewing the configuration and to return to the Configuration Table window, click Description The DE Mode, which determines the content of the frame relay DE field when transmitting from ATM to frame relay.
  • Page 509: Deleting A Frame Relay Configuration

    ELETING A RAME You delete a frame relay configuration from the window. You cannot delete configurations where the Operating Status is Up. In the Frame Relay Interworking Configuration Table the frame relay interworking configuration you want to delete. Click if necessary to view the entire table. table.
  • Page 510 Deleting a Frame Relay Configuration Avidia System Configuration and Management User Manual...
  • Page 511: Chapter 24: Configuring Bridging And Routing

    ONFIGURING This chapter describes how to create bridging and routing sessions and configure system bridging and routing parameters from the Web interface. Section Configuring Bridging and Routing Sessions Configuring Router Groups Configuring IP Routing Modifying RIP Configuration Configuring System Bridging and STP Parameters Configuring Global IP Routing Settings Avidia System Configuration and Management User Manual RIDGING AND...
  • Page 512: Configuring Bridging And Routing Sessions

    Configuring Bridging and Routing Sessions ONFIGURING You can configure bridging and routing sessions using PVCs that terminate on the management card (for example, PVCs between ADSL cards and the management card or PVCs between OC3 line cards and the management card). You can configure 96 bridging and routing sessions. To configure a bridging or routing session, you configure a PVC between a line or channel card and the management card, then set up the desired service for the session (bridging, routing or both).
  • Page 513 The first row of the Session Configuration Table the management card to the ATM network. The VPI and VCI for this session are assigned internally. Click displays the beginning of the table. Configuration Table window displays the following information: Information Admin Status Oper Status Slot...
  • Page 514: Adding Sessions

    Configuring Bridging and Routing Sessions Adding Sessions In the Session Configuration Table Add Session Entry In the Subscriber box, type a name to identify this session. In the Admin Status box, select enables the session. In the Slot Port boxes, select the line or channel card slot and port you want to use for this session.
  • Page 515 In the Encap box, select the type of encapsulation you want to use for this session PVC LLC_SNAP VC_MUX_Routed The type of service you specify in In addition, the encapsulation mode must match the encapsulation mode used by the adjacent segments in the network. The encapsulation mode is automatically set to VC_MUX_Bridged for PVCs that use SDSL cards, and cannot be modified.
  • Page 516 Configuring Bridging and Routing Sessions If you selected Routing In the RIP Send box, select the desired type of RIP packets to be sent ( packets, RIP Version1 RIP 1), or RIP Version2 The RIP type is determined by the RIP version used by the other routers in the network. In the RIP Receive RIP 1 or RIP2...
  • Page 517: Modifying Sessions

    Modifying Sessions In the Session Configuration Table Modify Session Entry To modify the subscriber name, type a name in the To modify the admin status, in the enables the session. To modify the encapsulation mode, in the VC_MUX_Routed VC_MUX_Bridged The encapsulation mode must match the encapsulation mode used by the adjacent segments in the network.
  • Page 518 Configuring Bridging and Routing Sessions If you selected Bridging in In the STP Priority for the session. The default range is from 0 to 255, with 0 being the highest priority. The default value is 128. In the STP Path Cost valid range is from 1 to 65535.
  • Page 519: Deleting Sessions

    Deleting Sessions Locate the table row that contains the session entry you want to delete. Click if necessary to view the entire the beginning of the table. Click next to the row that contains the information you want to delete. A confirmation dialog displays.
  • Page 520: Adding Router Groups

    Configuring Router Groups Click if necessary to view the entire of the table. displays the next page of the table. The following information: Information IP Address Subnet Mask Adding Router Groups In the Router Group Table group. In the Subnet Mask box, type the subnet mask to assign to the router group.
  • Page 521: Configuring Ip Routing

    IP R ONFIGURING The IP Routing Table contains the information that is used by the management card to route data. Packets for which the network portion of the destination IP address match the IP address listed in the first column of the table are routed based on the data displayed in the corresponding table row.
  • Page 522: Adding Ip Routing Table Entries

    Configuring IP Routing Click if necessary to view the entire the table. displays the next page of the table. Click IP Routing Table window displays the following information: Information Destination IP Subnet Mask Next Hop Port Hop Count Type Protocol Age (sec) Adding IP Routing Table Entries In the...
  • Page 523: Deleting Ip Routing Table Entries

    Deleting IP Routing Table Entries Locate the table row that contains the IP routing entry you want to delete. Click if necessary to view the entire table. table. displays the next page of the table. Click the Delete checkbox next to the row that contains the information you want to delete Click the Delete Checked Row(s) A confirmation dialog displays.
  • Page 524 Modifying RIP Configuration Click if necessary to view the entire beginning of the table. window displays the following information: Information IP Address Send Receive Hop Count Authentication RIP Configuration Table displays the next page of the table. The Description The IP address of the routing session. The type of RIP packets to be sent.
  • Page 525 To modify RIP information: In the RIP Configuration Table Modify RIP Configuration To modify the Send mode in the RIP1 Compatible RIP Version 2 To modify the Receive mode, in the 1 or RIP 2 Do Not Receive To modify the hop count, in the allowed to cross before arriving at their destination.
  • Page 526: Configuring System Bridging And Stp Parameters

    Configuring System Bridging and STP Parameters In the Password box, type the text string you want to use for a password, then in the Password box, re-type the text string. The text string can be any length and can use any keyboard character. Do one of the following: •...
  • Page 527: Modifying System Bridging Parameters

    Modifying System Bridging Parameters In the System Bridging Configuration Use the WAN Broadcast to all WAN logical interfaces. Use the Bridging box to In the Aging Time Interval entries are deleted if they are not relearned. The valid rate is 10 - 1000000. The default is 300 seconds.
  • Page 528: Modifying System Stp Parameters

    Configuring Global IP Routing Settings Modifying System STP Parameters In the System Bridging Configuration In the box, type the priority of the system (the entire chassis) within the network. Priority The valid range is 0 to 65535. The value 0 indicates the highest priority. The default value is 32768.
  • Page 529 In the IP Gateways Forwarding forwarding. In the Time-To-Live field for the IP header internally-generated IP datagrams that do not contain a time-to-live value. The time-to-live value is the number of hops a packet is allowed to cross before it reaches it’s destination.
  • Page 530 Configuring Global IP Routing Settings Avidia System Configuration and Management User Manual...
  • Page 531: Chapter 25: Monitoring Subscriber Connections

    ONITORING This chapter describes how to monitor Avidia subscriber connections, including ADSL, SDSL frame, SDSL cell and IDSL lines, from the Web Interface. Section Monitoring ADSL Status Monitoring SDSL Frame Current Statistics Monitoring SDSL Cell Performance Monitoring IDSL Performance Avidia System Configuration and Management User Manual UBSCRIBER ONNECTIONS Page...
  • Page 532: Monitoring Adsl Status

    Monitoring ADSL Status ADSL S ONITORING ADSL Loop Status window displays current loop status for a specified ADSL line. Do one of the following: • In the Site Map Navigation • In the Tree Navigation ADSL Loop Status ADSL Loop Status - Slot/Port Selection Select the slot and port you want to monitor.
  • Page 533 Chapter 25: Monitoring Subscriber Connections Avidia System Configuration and Management User Manual...
  • Page 534 Monitoring ADSL Status ADSL Loop Status window provides the following information: Status Box Card Slot Port Oper Status Admin Status Current Transmit Rate (Upstream/Downstream) Current Output Power (Upstream/Downstream) SNR Margin (1/10 dB) (Upstream/Downstream) Line Attenuation (1/10 dB) (Upstream/Downstream) Interleave Delay (ms) (Upstream/Downstream) Errored Seconds (Upstream/Downstream) Loss of Frame (Upstream/Downstream)
  • Page 535 Status Box Current State (Upstream/Downstream) Vendor ID (ATU-R/ATU-C) Version Number (ATU-R/ATU-C) Avidia System Configuration and Management User Manual Chapter 25: Monitoring Subscriber Connections Description The current status of the ADSL loop. Options: • noDefect — There are no errors on the line. •...
  • Page 536: Monitoring Sdsl Frame Current Statistics

    Monitoring SDSL Frame Current Statistics SDSL F ONITORING SDSL Loop Status window displays current statistics for a specified SDSL line. Do one of the following: • In the Site Map Navigation • In the Tree Navigation Loop Status SDSL Statistics - Slot/Port Selection Select the slot and port you want to monitor.
  • Page 537 SDSL Loop Status window provides the following information. the upstream direction, toward the network. direction, toward the customer. Status Box Card Slot Port Margin (1/10 dB) (Network/Customer) Pulse Attenuation (1/10 dB) (Network/Customer) 24 Hour ES 24 Hour UAS Total LOS Avidia System Configuration and Management User Manual Chapter 25: Monitoring Subscriber Connections Network...
  • Page 538: Monitoring Sdsl Cell Performance

    Monitoring SDSL Cell Performance SDSL C ONITORING SDSL Cell Loop Status Do one of the following: • In the Site Map Navigation • In the Tree Navigation Loop Statistics SDSL Cell Loop Status - Slot/Port Selection Select the slot and port you want to monitor. To continue to the SDSL Cell Loop Status discontinue this procedure.
  • Page 539 Chapter 25: Monitoring Subscriber Connections Avidia System Configuration and Management User Manual...
  • Page 540 Monitoring SDSL Cell Performance SDSL Cell Loop Status Status Box Card Description Slot Ports SNR Margin (1/10 dB) Attenuation (1/10 dB) Status Click to refresh the window with current data. window provides the following information: Description The slot number and description of the card for which the SDSL cell loop status is displayed.
  • Page 541: Monitoring Idsl Performance

    IDSL P ONITORING IDSL Current Performance Do one of the following: • In the Site Map Navigation • In the Tree Navigation Performance IDSL Current Performance- Slot/Port Selection Select the slot and port you want to monitor. To continue to the IDSL Current Performance discontinue this procedure.
  • Page 542 Monitoring IDSL Performance In the IDSL Current Performance • Click to refresh the window with current data. • In the Port box, select another port to monitor, then click • In the Slot box, select another slot to monitor, then click IDSL Current Performance statistics for the upstream direction, toward the network.
  • Page 543: Chapter 26: Monitoring Network Connections

    ONITORING This chapter describes how to monitor Avidia network connections, including loop status, performance history, and remote status for SONET, DS1, E1, and DS3 lines from the Web interface. It also describes how to monitor ATM statistics. Section Monitoring SONET Performance Monitoring DS1 Performance Monitoring E1 Performance Monitoring DS3 Performance...
  • Page 544: Monitoring Sonet Performance

    Monitoring SONET Performance SONET P ONITORING You can monitor SONET current performance by Medium, Section, Line and Path layer. Medium/Section/Line Current Performance Do one of the following: • In the Site Map Navigation • In the Tree Navigation SONET Medium/Section/Line Current Performance Medium/Section/Line Current Performance - Slot Selection Select the slot you want to monitor.
  • Page 545 Medium/Section/Line Current Performance current 15-minute data collection period. Information Slot Card Description Medium Current Performance Port Type Time Elapsed Valid Intervals Line Coding Avidia System Configuration and Management User Manual Chapter 26: Monitoring Network Connections window provides the following information for the Description The slot number and description of the line card for which the current performance is displayed.
  • Page 546 Monitoring SONET Performance Information Line Type Section Current Performance Port Status Errored Seconds Severely Errored Seconds Severely Errored Framing Seconds Coding Violation Description The type of SONET line. The Avidia system currently supports short-reach single-mode, multi-mode, and other SONET lines. The port number for which the Section current performance is displayed (each line card has two ports).
  • Page 547 Information Line Current Performance Port Status Errored Seconds Severely Errored Seconds Coding Violation Unavailable Seconds Far End Errored Seconds Far End Severely Errored Seconds Far End Code Violations Far End Unavailable Seconds The number of seconds during which the line is unavailable at Avidia System Configuration and Management User Manual Chapter 26: Monitoring Network Connections Description...
  • Page 548: Path Current Performance

    Monitoring SONET Performance Path Current Performance Do one of the following: • In the Site Map Navigation • In the Tree Navigation Current Performance Path Current Performance Select the slot containing the port you want to monitor. To continue to the Path Current Performance discontinue this procedure.
  • Page 549 Path Current Performance Information Slot Card Description Port Width Status Errored Seconds Severely Errored Seconds Coding Violations Unavailable Seconds Far End Errored Seconds Far End Severely Errored Seconds Far End Coding Violations Far End Unavailable Seconds Avidia System Configuration and Management User Manual Chapter 26: Monitoring Network Connections window provides the following information: Description...
  • Page 550: Monitoring Ds1 Performance

    Monitoring DS1 Performance DS1 P ONITORING DS1 Current Performance Do one of the following: • In the Site Map Navigation • In the Tree Navigation Performance DS1/E1 Current Performance - Slot Selection ERFORMANCE window displays current statistics for a specified DS1 line. window, click DS1 Current Performance window, click...
  • Page 551 Chapter 26: Monitoring Network Connections Select the slot that contains the port you want to monitor, then click . Otherwise, click Cancel to discontinue this procedure. DS1 Current Performance Table window displays. Avidia System Configuration and Management User Manual...
  • Page 552 Monitoring DS1 Performance DS1 Current Performance Table Information Card Slot Port Errored Seconds Severely Errored Seconds Severely Errored Framing Seconds Unavailable Seconds Path Coding Violations Line Errored Seconds Bursty Errored Seconds Degraded Minutes Line Code Violations window displays the following information. Description The description, slot number and port of the card.
  • Page 553: Monitoring E1 Performance

    E1 P ONITORING E1 Current Performance Do one of the following: • In the Site Map Navigation • In the Tree Navigation Performance DS1/E1 Current Performance - Slot Selection Avidia System Configuration and Management User Manual ERFORMANCE window displays current statistics for a specified E1 line. window, click E1 Current Performance window, click...
  • Page 554 Monitoring E1 Performance Select the slot that contains the port you want to monitor, then click Cancel to discontinue this procedure. E1 Current Performance Table window displays. Avidia System Configuration and Management User Manual . Otherwise, click...
  • Page 555 E1 Current Performance Table Information Card Slot Port Errored Seconds Severely Errored Seconds Severely Errored Framing Seconds Unavailable Seconds Path Coding Violations Line Errored Seconds Bursty Errored Seconds Degraded Minutes Line Code Violations Avidia System Configuration and Management User Manual Chapter 26: Monitoring Network Connections window displays the following information.
  • Page 556: Monitoring Ds3 Performance

    Monitoring DS3 Performance DS3 P ONITORING DS3 Current Performance Do one of the following: • In the Site Map Navigation • In the Tree Navigation Performance DS3 Current Performance - Slot Selection Select the slot that contains the port you want to monitor, then click to discontinue this procedure.
  • Page 557 DS3 Current Performance Table Information Card Slot Port P-bit Errored Seconds P-bit Severely Errored Seconds Severely Errored Framing Seconds Unavailable Seconds Line Code Violations P-bit Coding Violations Line Errored Seconds C-bit Coding Violations C-bit Errored Seconds C-bit Severely Errored Seconds Avidia System Configuration and Management User Manual Chapter 26: Monitoring Network Connections window displays the following information.
  • Page 558: Monitoring Aps Status

    Monitoring APS Status APS S ONITORING You can monitor APS information such as the date and time of APS events and the currently active channel. You monitor APS status for both the local APS and the APS at the remote end of the connection from the APS Status window.
  • Page 559 APS Status window displays the following information. Information Description Card The description and slot number of the card. Slot K1 Channel Indicates whether the ATM traffic is being carried on the working channel or the protection channel. If this box is empty, there is no cable connected to the port.
  • Page 560 Monitoring APS Status Information Description Last Switched Time The date and time of the last APS switch. Number of Switches The number of switches that have occurred since the OC3 card was last reset. Signal Degraded Count The number of times the signal has degraded and the traffic has switched to the protection channel as a result.
  • Page 561: Chapter 27: Monitoring Physical Interfaces

    ONITORING This chapter describes how to monitor physical interfaces and ATM cell switch status from the Web interface. Section Opening the Interface Window Physical SONET Interfaces Physical ADSL Interfaces Physical SDSL Frame Interfaces Physical SDSL Cell Interfaces Physical DS1 Interfaces Physical E1 Interfaces Physical DS3 Interfaces Avidia System Configuration and Management User Manual...
  • Page 562: Opening The Interface Window

    Opening the Interface Window PENING THE NTERFACE You monitor all physical interfaces monitor the interfaces by slot. Do one of the following: • In the Site Map Navigation • In the Tree Navigation Interfaces Physical Slot Interfaces (By Card) - Slot Selection Select the slot you want to monitor, then click procedure.
  • Page 563 Information Admin Status Operation Status In Octet Count In Unicast Pkt Count In Discard Count In Error Pkt Count In Unknown Pkt Count Out Octet Count Out Unicast Pkt Count Out Discard Count Out Error Pkt Count Link Up/Down High Speed Connect Avidia System Configuration and Management User Manual Chapter 27: Monitoring Physical Interfaces...
  • Page 564: Physical Sonet Interfaces

    Physical SONET Interfaces SONET I HYSICAL ADSL I HYSICAL NTERFACES NTERFACES Avidia System Configuration and Management User Manual...
  • Page 565: Physical Sdsl Frame Interfaces

    Chapter 27: Monitoring Physical Interfaces SDSL F HYSICAL RAME NTERFACES Avidia System Configuration and Management User Manual...
  • Page 566: Physical Sdsl Cell Interfaces

    Physical SDSL Cell Interfaces SDSL C HYSICAL NTERFACES Avidia System Configuration and Management User Manual...
  • Page 567: Physical Ds1 Interfaces

    DS1 I HYSICAL E1 I HYSICAL NTERFACES Avidia System Configuration and Management User Manual NTERFACES Chapter 27: Monitoring Physical Interfaces...
  • Page 568: Physical Ds3 Interfaces

    Physical DS3 Interfaces DS3 I HYSICAL NTERFACES Avidia System Configuration and Management User Manual...
  • Page 569: Chapter 28: Monitoring System Alarms And Status

    ONITORING LARMS AND This chapter describes how to monitor system alarms and messages from the Web interface. Section Monitoring System Events Monitoring System Alarms Monitoring SDSL Frame Alarms Monitoring SDSL Cell Alarms Monitoring IDSL Alarm Status Avidia System Configuration and Management User Manual YSTEM TATUS Page...
  • Page 570: Monitoring System Events

    Monitoring System Events ONITORING YSTEM System Log reports events that occur on all cards installed in the chassis. Reported events include alarms, traps, changes in slot status and diagnostic trace messages. Do one of the following to display the • In the Site Map Navigation •...
  • Page 571 System Log Table window provides the following information: Information Date/Time Event Type Slot ID Description Avidia System Configuration and Management User Manual Chapter 28: Monitoring System Alarms and Status Description The time and date the event occurred. The type of event that occurred. Options: •...
  • Page 572: Monitoring System Alarms

    Monitoring System Alarms ONITORING YSTEM Chassis Alarm Status Table system. Do one of the following: • In the Site Map Navigation • In the Tree Navigation Chassis Alarm Status Table Click if necessary to view the entire the beginning of the table. LARMS window displays the alarm status for all components of the Avidia window, click...
  • Page 573 Chassis Alarm Status Table Information Description LED Status Displays a graphical representation of the current chassis LED status. Green indicates there is no alarm. Red indicates an alarm. When red, the LEDs correspond to the following: • Critical • Major •...
  • Page 574 Monitoring System Alarms Information Description Most Serious Alarm The most serious alarm that is occurring in the corresponding slot. The currently supported alarms are: Chassis Alarms • Chassis power alarm • Chassis fan failure • Chassis temperature alarm • Chassis line card down alarm •...
  • Page 575: Monitoring Sdsl Frame Alarms

    SDSL F ONITORING You can monitor current SDSL frame alarm status and SDSL frame alarm history. Do one of the following: • In the Site Map Navigation • In the Tree Navigation SDSL Alarm History Slot/Port Selection Select the slot and port you want to monitor, then click discontinue this procedure.
  • Page 576 Monitoring SDSL Frame Alarms In the SDSL Alarm History • Click to refresh the window with current data. • In the Port box, select another port to monitor, then click • In the Slot box, select another slot to monitor, then click window, you can do any of the following: Avidia System Configuration and Management User Manual...
  • Page 577: Monitoring Sdsl Cell Alarms

    SDSL Alarm History window displays the following information for the selected port, including both alarm history (since the card was last reset) and alarm status for the current 15-minute data collection interval. The current alarm status displays for both the (upstream) and Customer (downstream) traffic.
  • Page 578 Monitoring SDSL Cell Alarms Select the slot and port you want to monitor, then click discontinue this procedure. SDSL Cell Alarm Status In the SDSL Cell Alarm Status • Click to refresh the window with current data. • Click to go to the selected Slot and Port window displays.
  • Page 579: Monitoring Idsl Alarm Status

    SDSL Cell Alarm Status collection interval. The current alarm status displays for both the Customer (downstream) traffic. Information Card Description Slot Port Loss of Signal Seconds (LOSS) Loss of Cell Delineation (LOCD) Severe Loss of Cell Delineation (SLOCD) Severe loss of cell delineation seconds are seconds Last Time Alarm Status Changed IDSL A ONITORING...
  • Page 580 Monitoring IDSL Alarm Status Select the slot and port you want to monitor. To continue to the IDSL Alarm Status discontinue this procedure. In the IDSL Alarm Status • Click to refresh the window with current data. • In the Port box, select another port to monitor, then click •...
  • Page 581 IDSL Alarm Status window provides the following information. The alarm thresholds for errored seconds and severely errored seconds were configured using the Profile Table (see “Configuring IDSL Alarm Profiles” on page for the upstream direction, toward the network. direction, toward the customer. Status Box Slot Port...
  • Page 582 Monitoring IDSL Alarm Status Avidia System Configuration and Management User Manual...
  • Page 583: Chapter 29: System Maintenance And Administration

    YSTEM The Web interface provides several convenient maintenance and administrative features. Go to the appropriate section listed below, based on the task you want to perform. Section Configuring and Initiating OAM Loopbacks Initiating Communication Path Loopbacks Managing IDSL Diagnostics Managing Image Files Downloading Files to a Modem Managing Security Configuring the System Timers...
  • Page 584: Configuring And Initiating Oam Loopbacks

    Configuring and Initiating OAM Loopbacks ONFIGURING AND Configure OAM Loopbacks from the open the OAM Loopback Table • In the Site Map Navigation • In the Tree Navigation OAM L NITIATING OAM Loopback Table window: window, click OAM Loopback window, click Diagnostics Management Avidia System Configuration and Management User Manual OOPBACKS...
  • Page 585 Click to update the OAM Loopback Table the entire table. displays the beginning of the table. The OAM Loopback Table displays the following configuration and status information for each loopback. Information Description Slot The slot and port from which the loopback was initiated. Port The VPI of the VPC or VCC.
  • Page 586 Configuring and Initiating OAM Loopbacks From the OAM Loopback Table, set the Source Location ID for the Avidia system. This is important, as it enables the Avidia system to determine whether or not it is the originator of received loopback cells. The Source Location ID default is ff:ff:ff:ff:ff:ff:ff:ff:ff:ff:ff:ff:ff:ff:ff:ff.
  • Page 587 Adding OAM Loopbacks In the OAM Loopback Table Add OAM Loopback Entry In the Slot Port boxes, select the slot and port where the loopback will be initiated. In the OAM Flow Type OAM F4 flow loopbacks test circuits at a VPC level (requires a VPI only), where OAM F5 flow loopbacks test circuits at a VCC level (requires a VPI and a VCI).
  • Page 588 Configuring and Initiating OAM Loopbacks In the Function Type box, select the loopback type ( Segment loopbacks test the connectivity between any two uniquely addressable points in a VPC or VCC. End-to-end loopbacks test the connectivity between any uniquely addressable point in the VPC or VCC and any end point (such as a modem or a network end point) where a VPC or VCC terminates.
  • Page 589: Initiating Communication Path Loopbacks

    Deleting OAM Loopbacks Locate the table row that contains the Click if necessary to view the entire table. table. displays the next page of the table. Click next to the row that contains the information you want to delete. A confirmation dialog displays. Do one of the following: •...
  • Page 590 Initiating Communication Path Loopbacks The following table lists supported loopbacks. Loopback Card(s) Type Supported Local Line DS1/DSX-1 Payload DS1/DSX-1 For this loopback, framing for the DS1/DSX-1 port must be set to ESF. Remote DS1/DSX-1 Initiate loopbacks from the depending on the type of card. To open the configuration window for the card: Do one of the following to open the •...
  • Page 591: Oc3 Loopbacks

    Select the slot and port on which you want to initiate a loopback, then click See the following sections to initiate loopbacks for specific line card types: • “OC3 Loopbacks” on page 565 • “DS1 Loopbacks” on page 566 • “DS3 Loopbacks”...
  • Page 592: Ds1 Loopbacks

    Initiating Communication Path Loopbacks DS1 Loopbacks Initiate DS1 loopbacks from the In the Loopback box, select the loopback type you want to initiate, either Remote , or Local . The table on Click to initiate the loopback. To disable the loopback and return the port to normal service, set the click DS1 Configuration window.
  • Page 593: Ds3 Loopbacks

    DS3 Loopbacks Initiate DS3 loopbacks from the In the Loopback box, select the loopback type you want to initiate, either Remote , or Local . The table on Click to initiate the loopback. To disable the loopback and return the port to normal service, set the click Avidia System Configuration and Management User Manual Chapter 29: System Maintenance and Administration...
  • Page 594: Managing Idsl Diagnostics

    Managing IDSL Diagnostics IDSL D ANAGING You use the IDSL Diagnostic Table node or the entire connection path (loop). Do one of the following: • In the Site Map Navigation • In the Tree Navigation IDSL Diagnostic - Slot Selection Select the slot you want to manage.
  • Page 595 Chapter 29: System Maintenance and Administration Avidia System Configuration and Management User Manual...
  • Page 596: Detecting Network Devices

    Detecting Network Devices In the IDSL Diagnostic • Click to activate the new settings. • Click to cancel the new settings. You can only cancel the settings if you have not clicked • In the Slot box, select another slot to manage. ETECTING ETWORK Use the...
  • Page 597: Managing Image Files

    Click Ping Ping window displays one of the following messages (where xxx.xxx.xxx.xxx is the IP address of the target network device: Message xxx.xxx.xxx.xxx is alive. No answer from xxx.xxx.xxx.xxx. Ping xxx.xxx.xxx.xxx -- 5 second time out occurred. xxx.xxx.xxx.xxx statistics: ??% loss Ping window also displays the following statistics: Information...
  • Page 598: Uploading Files To A Tftp Server

    Managing Image Files Uploading Files to a TFTP Server You can backup Avidia system files by uploading them to a TFTP server. Make sure the system to which you want to upload the file is running as a TFTP server. In the Image Manager A list of files stored on the selected card displays in the...
  • Page 599: Downloading Files To The Avidia System

    To store the uploaded file in a TFTP server directory other than the default directory, type the target directory name in the You can only specify directory names that are subdirectories of the default directory. See your TFTP server documentation to determine the required path syntax. In the To: File Name box, type the file name you want to use to store the uploaded image file...
  • Page 600 Managing Image Files In the Image Manager Download to Selected Card In the From: IP Address download the file, using the xxx.xxx.xxx.xxx format. The default TFTP server IP address is 192.168.0.100. If the file you want to download is not located in the TFTP server default directory, in the From: File Path box, type the directory in which the file is located.
  • Page 601 To save the settings and begin the download process, click The selected file downloads to the specified card. You can monitor the download progress in the Status field, located in the upper right corner of the field indicates whether the download is indicates that no download activity has taken place.
  • Page 602: Copying Files

    Managing Image Files Copying Files You can restore the system files required to run a particular card by copying the files from another card of the same type. In the Image Manager A list of files stored on the selected card displays in the Select the file to copy.
  • Page 603: Deleting Files

    In the To: File Name box, type the name, including file name extension, under which you want to store the copied file. To save the settings and copy the file, click You can monitor the copy progress in the Image Manager window.
  • Page 604 Downloading Files to a Modem You download files to a modem from the Do one of the following to open the • In the Site Map Navigation • In the Tree Navigation In the Card box, select the channel card to which the modem is connected. In the Modem File Transfer window.
  • Page 605 For each channel card port over which you want to download files to the attached modem: In the corresponding To download the same file to all of the ports, in the row labeled The file name for each of the individual ports is automatically set to the same file name. When a source file is selected, the the file name required by the modem.
  • Page 606: Managing Security

    Managing Security For each channel card port over which you do not want to download files, in the column select None To begin the download, click Modem File Transfer Status automatically updated every five seconds. You can also refresh the data by clicking The download progress is also reflected in the the data, click While one file is downloading, you can set up the next file to be downloaded.
  • Page 607 Chapter 29: System Maintenance and Administration You can also set the Inactivity Timeout and Refresh Time settings in the User Table window. See “Configuring the System Timers” on page 586 instructions. Avidia System Configuration and Management User Manual...
  • Page 608: Adding User Accounts

    Managing Security Adding User Accounts In the User Table window, click In the User Name box, type a unique user name for this account. This is the name the user will use to log on to the Web interface. The user name must contain between four and 20 alphanumeric characters and the first character must be a letter.
  • Page 609 In the Access Level box, select the desired security level for this user. Access Level Monitoring Provisioning Admin In the box, select Telnet Access using a Telnet session, otherwise select In the Craft Access box, select using the management card craft port, otherwise select In the Web Access box, select...
  • Page 610: Deleting User Accounts

    Managing Security Deleting User Accounts You cannot delete the admin user account. In the User Table window, click Do one of the following: • In the confirmation box, click delete the user account. • Click Cancel to return to the Modifying User Accounts In the User Table...
  • Page 611 To modify the user name, type a unique user name for this account In the This is the name the user will use to log on to the Web interface. The user name must contain between four and 20 characters and the first character must be a letter. The user name cannot contain spaces, but can contain multiple words separated by an underscore.
  • Page 612: Restoring The Admin Account Password

    Configuring the System Timers Restoring the Admin Account Password If you change the admin user account password to something other than dslam, then forget the new password, you can restore the dslam password as follows: Delete the pguser.cnf file from the management card. “Deleting Files”...
  • Page 613: Setting The Inactivity Timeout

    Setting the Inactivity Timeout In the User Table window, which the Web interface automatically logs the current user off the system if no keyboard input is received. The valid range is 60 to 86,400 seconds. Do one of the following: •...
  • Page 614: Setting The Refresh Rate

    Displaying System Inventory Setting the Refresh Rate The Web interface refresh rate determines the interval at which the data on the performance data screens is automatically refreshed. When the management card is rebooted, this setting reverts to the default value of five minutes. In the User Table window...
  • Page 615: Resetting Cards

    ESETTING ARDS You can reboot an individual card, or the entire Avidia system, two different ways: • Perform a cold boot by recycling power to the system. This reinitializes the card memory, including resetting the system log. If you do not want to lose the data stored in the system log, do not perform a cold boot.
  • Page 616: Activating And Deactivating Ports

    Activating and Deactivating Ports CTIVATING AND The management card does not issue a trap when you activate and deactivate ports. Do one of the following to open the • In the Site Map Navigation • In the Tree Navigation In the Please Select A Slot deactivate.
  • Page 617 Port Activation Table in the selected slot. The following screen shows an example of an Similar tables display for other port types. Do one of the following: • Change the Admin Status selecting Down to disable a port. • In the Select All Ports •...
  • Page 618 Activating and Deactivating Ports Avidia System Configuration and Management User Manual...
  • Page 619: Part Iv

    These appendixes provide additional information about the software. Appendix Number Appendix Title Troubleshooting and Diagnostics Contacting ADC SPVC Last Release Cause Codes Glossary Avidia System Configuration and Management User Manual PPENDIXES Begins on page...
  • Page 620 Avidia System Configuration and Management User Manual...
  • Page 621: Appendix A: Troubleshooting And Diagnostics

    The troubleshooting and diagnostic procedures contained in this Appendix require interrupting the system boot sequence by pressing the slash (/) key. Unless you are a ADC technician, do not press the slash key while the system is booting. CCESSING THE Each of the procedures contained in this section are performed from the DMU Test Main Menu, which you access by booting the system and interrupting the regular boot sequence.
  • Page 622: Downloading An Image File From Atftp Server

    Downloading an Image File from a TFTP Server Before the ten-second counter reaches zero, press the forward slash key ( / ). The DMU Test Main Menu displays. DMU Test Main Menu: 1 PCI device detect 2 NAND EEPROM/DOSFS 3 TRAM CUBIT 4 IP address config and Image download 5 Start running 6 Display/Set system time...
  • Page 623 Do one of the following: • Type c to download a configuration file from a TFTP server. • Type i to download an image from a TFTP server. The system also enables you to download a configuration file, Web interface application file or command-line interface application file during this process.
  • Page 624: Booting The System

    Booting the System If you are downloading an image file: To accept the default boot server IP address, press server IP address using the xxx.xxx.xxx.xxx format then press The system prompts you for the boot image file name. The default boot image file name displays for your reference.
  • Page 625: Performing System Diagnostics

    ERFORMING YSTEM The diagnostic tests described in this section can help you determine why the system is not performing properly. Detecting PCI Devices From the DMU Test Main Menu, type 1. The system detects the PCI devices in the system and displays a list on the screen.
  • Page 626: Testing The Tram Cubit

    Performing System Diagnostics From the NAND EEPROM/DOSFS Menu you can do the following: • Test the read/write functionality of the NAND EEPROM by typing t then pressing ENTER . The system runs a test and reports the results on the screen. •...
  • Page 627: Setting The System Date And Time

    ETTING THE YSTEM From the DMU Test Main Menu, type 6 then press prompt: To adjust time/date enter HH:MM:SS or MM-DD-YYYY. X to exit. FRI MAY 14 12:49:25 1999 To change the system time, type the current time in hh:mm:ss two-digit 24-hour format, then press ENTER (for example 04:30:00).
  • Page 628 Setting the System Date and Time Avidia System Configuration and Management User Manual...
  • Page 629: Appendix B: Contacting Adc

    ECHNICAL UPPORT Technical support is available 24 hours a day, 7 days a week by contacting the ADC Wireline Systems Division Customer Service Engineering Group at one of the following numbers: • Telephone: 800.638.0031 714.730.3222 • Fax: 714.832.9924 • Email wsd_support@adc.com...
  • Page 630: Advance Replacement

    ADC during the 90-day warranty period is, at ADC’s option, either (a) return of the price paid or (b) repair or replace of the software. ADC also warrants that, for a period of thirty (30) days from the date of purchase, the media on which software is stored will be free from material defects under normal use.
  • Page 631: Billing

    ADC will contact the customer for disposition on any equipment that is in this condition or found to be unrepairable.
  • Page 632 Number you received from Customer Service clearly on the outside of the carton and return ADC Wireline Systems Division 14352 Franklin Ave. Tustin, CA 92780-7013 Attention: RMA (Number) All shipments are to be returned prepaid. ADC will not accept any collect shipments. Avidia System Configuration and Management User Manual...
  • Page 633: Appendix C: Spvc Last Release Cause Codes

    SPVC L The following table defines the last release cause codes for SPVCs. Last Release Definition Cause Value invalid cause value - proprietary unallocated (unassigned) number no route to transit network no route to destination call preempted by higher priority call UNI 3.0: VPCI/VCI unacceptable UNI 3.1: normal call clearing user busy...
  • Page 634 Last Release Definition Cause Value network out of order temporary failure access info discarded no VPCI/VCI unavailable resources unavailable, unspecified Quality of Service unavailable requested facility not subscribed UNI 3.0: user cell rate unavailable PNNI: call cleared due to change in PGL Q2931: outgoing Calls Barred with CUG Q2931: incoming Calls Barred with CUG bearer capability not authorized...
  • Page 635 Last Release Definition Cause Value recovery on timer expiry incorrect message length protocol error, unspecified opt info el content error (non-std) next node unreachable DTL Transit not my node ID Avidia System Configuration and Management User Manual CSPVC Last Release Cause Codes...
  • Page 636 Avidia System Configuration and Management User Manual...
  • Page 637: Appendix D: Glossary

    10BASE T The Institute of Electrical and Electronic Engineers (IEEE) 802.3 Ethernet Specification. ADSL (Asymmetrical A technology in which data is transferred from the service provider to the Digital Subscriber Line) subscriber at up to 7.5 Mbps, and transferred from subscriber to service provider at up to 928 kbps.
  • Page 638 Glossary Cell A fixed-length packet. Also, the unit of data transmission used in ATM. Each ATM cell contains a fixed-size frame (53 bytes) consisting of a five-byte header and a 48-byte payload. Channel A physical (cable) or virtual path that carries data between two devices. Circuit A communications link between two devices.
  • Page 639 IP Address A 32-bit address used in IP routing. The address consists of four octets separated by decimals. The octets comprise a network section, an optional subnet section, and a host section. Line The link between the Avidia system and the WAN. Also, a SONET interface layer that is responsible for transporting data.
  • Page 640 Glossary Path A SONET layer that handles transport of services. PCR (Peak Cell Rate) The maximum rate at which data is transferred on the line, measured in cells per second. Ping A program used to test the communication link between two computers on a network.
  • Page 641 Subnet Mask A type of IP address that allows a site to use a single IP address for multiple physical networks. TCP (Transmission A connection-oriented protocol in which datagrams are divided when sent Control Protocol) and reassembled when received. This allows the different components of the message to be routed differently to increase the speed of transmission.
  • Page 642 Glossary Avidia System Configuration and Management User Manual...
  • Page 643: Index

    accessing boot monitor 595 command-line interface 15 Web interface 16 accounts user access levels 359, 580 activating ports 590 PVCCs cell card 174, 448 frame card 183 PVPCs 167, 437 adding ADSL alarm profiles 104, 388 line profiles 100, 386 port configurations 109, 391 ATM routing table entries 459 ATM traffic profiles 155...
  • Page 644 admin user account password 586 administration, system 341, 557 ADSL alarm profiles 104, 388 deleting 106 displaying 105 cell transfer rates 154 configuring overview 74 hardware version number 364, 588 interfaces, monitoring 316, 538 line profiles 100, 386 performance monitoring 260, 506 vendor ID 364, 588 alarm manager 69 alarm profiles...
  • Page 645 bridging 37 bridge forwarding statistics 313 bridge port status 306 sessions 228, 486 statistics 309 STP port status 307 brouting sessions 228, 486 CAC 22 cards cell transfer rates 154 copying files 356, 576 displaying a directory of files 357, 571 rebooting 367 resetting 366, 367, 589 CBR 20...
  • Page 646 configuring (continued) APS 158, 430 OC3 ports 142, 416 policing 200, 462 traffic profiles 20, 154, 428 bridging and routing sessions 228, 486 communication path loopbacks 563 community strings 97 configuration files 8 DS1 service 143, 417 DS3 service 149, 422 frame relay 206, 468 gateways 93, 381 IDSL...
  • Page 647 deleting ADSL alarm profiles 106, 390 line profiles 103, 388 ATM traffic profiles 156, 430 bridging and routing sessions 493 community strings 98 frame relay configuration 483 frame relay links 209 IDSL alarm profiles 133, 410 line profiles 408 image files 368, 577 IP routing table entries 497 PVCCs cell card 175, 449...
  • Page 648 displaying (continued) PVCC information 177 PVCC policing table 202 PVPC information 169 PVPC policing table 203 RIP configuration table 243 SDSL Cell alarm profiles 123 line profiles 120 line statistics 268 loop status 512 performance history 270 SDSL Frame alarm profiles 115 line profiles 112, 393 line statistics 264, 510 loop status 510...
  • Page 649 features 6 files configuration files 8 copying files between cards 356, 576 deleting image files 368, 577 displaying a directory on a card 357, 571 downloading from a TFTP server 355, 573 downloading to a modem 358, 577 hardware profile files 9 image files 8 managing image files 571 restoring 355, 573...
  • Page 650 initiating communication path loopbacks 345, 563 OAM loopbacks 342, 558 interface information, ATM 460 interfaces ADSL, monitoring 316, 538 DS1, monitoring 320, 541 DS3, monitoring 322, 542 E1, monitoring 541 OC3, configuring 142, 416 SDSL Cell, monitoring 319, 540 SDSL Frame, monitoring 317, 539 selecting a management interface 15 SONET, monitoring 538 introduction to the...
  • Page 651 LOS, ADSL 104 LOSW SDSL Cell 122 SDSL Frame 114, 395 MAC address forwarding 245 mapping to IP address 239 maintenance, system 341, 557 management image files 571 inband 44 preparing for system configuration and management 11 protocols 9 security 580 selecting a management interface 15 system file management 8 management card IP address 91, 381...
  • Page 652 monitoring (continued) interfaces 325 performance monitoring features 6 physical interfaces 315 SDSL Cell alarms 334, 551 interfaces 319, 540 performance 268, 512 SDSL Frame alarms 331, 549 interfaces 317, 539 performance 264, 510 SONET interfaces 538 performance 278, 518 system alarms 328, 339, 546 traps 328, 544 multiple systems, subtending 45 names for xDSL ports 138...
  • Page 653 prefix for ATM addresses 460 preparing for configuration and management 11 primary PVCCs 443 profiles ADSL alarm profiles 104, 388 line profiles 100, 386 ATM traffic profiles configuring 154, 428 IDSL alarm profiles 130, 408 line profiles 127, 406 SDSL Cell alarm profiles 121, 401 line profiles 119, 399 SDSL Frame...
  • Page 654 resetting cards 367 system 366, 589 restarting SPVCs 195 restoring admin password 586 files 355, 573 Returns 605 RIP 38 configuration 242, 497 router groups 493 routing 37 ATM 196, 457 global settings 251, 502 IP routing table 235, 495 protocols 38 statistics 311 Routing Information Protocol...
  • Page 655 SONET description 28 interface, monitoring 538 performance monitoring 278, 518 source location ID 342 Spanning Tree Protocol See STP SPVCs configuring 188, 454 restarting 195 status IDSL 515 SDSL Cell 512 SDSL Frame 510 STP 38 port status 307 statistics 309 system parameters 249, 502 subnet mask 42 configuring 13, 92, 381...
  • Page 656 time, setting 89, 384 timeout setting the command-line interface timeout option 367 setting the Web interface timeout option 586 traffic ATM configuration 20 management 22 traffic profiles, ATM adding 155 configuring 154, 428 trap generation, configuring status 94 trap receivers adding 95 configuring 94 deleting 96...
  • Page 658 ADC DSL Systems, Inc. 14402 Franklin Avenue Tustin, CA 92780 Tel: 714.832.9922 Fax: 714.832.9924 For Technical Assistance: 800.638.0031 714.730.3222 ´+L^¶2X¨ 1144622 Rev A...
