Status Displays on the LEDs
LAN LED (COMpact 5200): Status of the Ethernet Interface:
Flashes orange
LAN-Link LED (COMpact
5020R/5500R):
Off
Lit in green
LAN-Activity LED
(COMpact 5200R/5500R):
Off
Flashes orange
COMpact 5200/5200R/5500R - Firmware V7.4A - Advanced Information V08 06/2019
An Ethernet connection to a computer/
network exists (link) and packets are
being transmitted.
Status of the Ethernet Interface:
No Ethernet connection to a computer/
network exists.
An Ethernet connection to a computer/
network exists (link).
Transfer Activities on the Ethernet
Interface:
No transfer activity on the Ethernet
interface.
Packets are being transmitted.
