Auerswald COMpact 5200 Advanced Information page 1246

Status Displays on the LEDs
Status LED:
Flashes red
(1/1 s)
Flashes orange
(1/1 s)
Note: If the Power LED remains constantly lit in red even after
a restart, an error has occured. Please contact your dealer or the
manufacturer directly.
Status LED:
Lit in green
Lit in green
LAN LED (COMpact 5200): Status of the Ethernet Interface:
Off
Lit in orange
COMpact 5200/5200R/5500R - Firmware V7.4A - Advanced Information V08 06/2019
Power LED:
Lit in red
Lit in red
Power LED:
Flashes green
Lit in red
No Ethernet connection to a computer/
network exists.
An Ethernet connection to a computer/
network exists (link).
PBX status (in the case of an error):
No valid boot partition was found.
System is paused.
In both boot partitions no constant
kernel data were found. System is
paused.
PBX status (during powering
down):
The delayed powering down has been
enabled and the PBX waits for the
termination of the last call.
The PBX is powered down completely.
- 1246 -
