Legend
5
Enable and disable neutral density filter (FSC only).
6
Enable and disable detectors.
7
Modify detector names.
8
Modify PMT voltages (text entry, slider, or mouse scroll wheel).
9
Set threshold.
10
Set primary trigger (and optional secondary trigger).
For information about using this panel, see
Multipanel Experiments
You can configure a plate or tube rack with multiple experiments by adding panels in the Experiment
Builder. Adding a panel returns you to the Experiment Builder Name screen. After assigning a unique
name, you can set up a unique run list in a portion of the plate map. The name of each panel in the
experiment is shown at the bottom of the Settings screen, as shown in the next figure.
Groups of positions in the plate map can have uniquely defined settings and workspaces, including:
n Active parameters (fluorophores)
n
Parameter names
n
Sampling settings (such as target flow rate or target event rate, washing, and agitation)
n
PMT voltages
n
Trigger and threshold
Configuring Instrument Settings on page
Experiment Builder
257.
User Guide | 87
