BIO RAD ZE5 User Manual page 385

Appendix D
The specifications for the ZE5™ Cell Analyzer are shown in
Table 44. ZE5 Cell Analyzer specifications
Category
System
ZE5 Cell Analyzer Specifications
Description
Fluorescence sensitivity
Scatter sensitivity
Loader
Table 44.
Specification
<100 MESF (molecules of equivalent soluble
fluorochrome) for FITC, PE, APC
<0.5 µm FSC resolution with standard FSC
detector
<0.3 µm FSC resolution with small particle
detection module
Integrated sample loader with agitation
Sample and collection temperature control from
4–37°C, Peltier solid state system
Media types:
n
5 ml tubes (12 x 75 mm, 1–40 tubes per rack)
n
1.5 ml tubes (1–24 tubes per rack)
n
96-well plates
n
96 deep-well plates
n
384-well plates
n
Stat tube position for single tube, 5 ml
(12 x 75 mm)
User Guide | 383
