Table 18. Selected Media items and their functions
Item
Position Types
Below the plate map, the Type setting allows you to designate a sample position or group of sample
positions as Sample, Setup, Wash, or Reagent.
Table 19. Position Type items and their functions
Button
Function
Opens the media selector so that you can change the type of input
device (for example, switching a 40-tube rack to a 96-well plate).
Note:
Switching to a different media type resets the run list
order. For more information, see
page 179.
Adds a stat tube to the plate in the selected Sample position.
Note:
Stat tubes can be assigned only the Sample position on
the plate.
Removes the selected well(s) or stat tube from the run list.
When set to ON, allows you to quickly change the location of a
sample from a filled well to an empty well.
Note:
The default setting is OFF.
Allows you to assign a name to a well. The FCS file that is saved
for the well includes this name. Displays the assigned name of the
selected Plate Map position.
Function
Designates the position as wash, containing water
or cleaning solution. No data acquisition occurs for
this position type.
Designates the position as a sample. Data
acquisition occurs for this position type.
Designates the position as reagent that can be
added to other wells/tubes. No data acquisition
occurs for this position type.
Experiment Builder
Plate Settings Controls on
Appears in
plate map as
