Chapter 5 Configuring the System
640 nm Laser Filter Choices
Red
4 Detectors
640 nm
670/30
100 mW
690 DLP
720/60
752 DLP
775/50
800 DLP (changeable)
800 LP
Replacing Optical Filters
Important:
Only authorized and trained personnel should access or modify the optical
configuration of the ZE5 Cell Analyzer system. The coated pieces of glass are delicate; handle
them with care. Any scrape or scratch on the surface could significantly affect the light passing
through. Always wear gloves when removing or replacing filters to avoid depositing smudges and
fingerprints on the glass surfaces. See
instructions on cleaning optical filters.
To replace optical filters
1.
Open the outer optical filter access door.
2.
Lift the black optical filter cover and attach it to the side of the instrument using the built-in magnet.
130 | ZE5 Cell Analyzer and Everest Software
Fluorophores
APC
Cy5
Alexa Fluor 647
Cy5.5
Alexa Fluor 680
Alexa Fluor 700
APC-Cy7
APC-H7
APC-Alexa Fluor 750
Cleaning the Optical Filters on page 334
for specific
