Table 23. Plate map symbols, continued
Symbol Description
Sample position
Reagent position
Wash position
Unassigned position
PMT Control Panel
The PMT Control panel in the Settings workspace allows you to control initial settings related to lasers
and detectors. These settings can be adjusted later after acquisition begins.
Experiment Builder
User Guide | 85
