Table 29. System buttons and their functions, continued
Button Function
Pause System/Resume System
and disables the lasers, or resumes the sheath flow and enables the
lasers.
Decontamination — initiates the Decontamination wizard.
Fluidics — displays status of fluidics bottles and calibration beads;
allows you to swap the large fluidics bottles. Displays remaining fluidics
run time. See Checking Fluidics Status on page
Low Fluidics Warning
low and should be replaced soon.
Extremely Low Fluidics Warning
should be immediately replaced.
Swap Fluidics — switches the active waste and sheath fluidics
bottles. See Refilling Bulk Fluidics on page
Bottle Use Indicator
and DI water bottles are in use.
Waste Fluid Level — indicates the level of fluid in the waste bottles.
DI Water Level — indicates the level of fluid in the DI water (sheath)
bottles.
Additive Fluid Level
additive bottles.
Cleaner Fluid Level
cleaner bottles.
— pauses the sheath fluid flow
142.
— indicates that the level of bulk fluidics is
— indicates that the bulk fluidics
143.
— indicates whether the top or bottom waste
— indicates the level of fluid in the sheath
— indicates the level of fluid in the system
The Toolbar
