Using Plot and Histogram Tools

After creating a plot or histogram, you can modify it using the tools that appear when you point at the
plot or histogram. Different tools are available for bivariate density plots (next figure, left) versus
univariate histogram plots (next figure, right). Tools for time plots are similar to those for density plots.
Table 37. Plot and histogram tools and their functions
Tool Function
Add Polygon Region — adds a
polygon region to the plot; click each
point to create the shape and double-
click to close. Applies only to density
and time plots.
Add Rectangle Region
rectangle region to the plot. Applies
only to density and time plots.
Add Ellipse Region — adds an
ellipse region to the plot. Applies only
to density and time plots.
— adds
Add Quadrant Region
quadrant regions to the plot. Applies
only to density plots.
— adds a bar region
Add Bar Region
to the plot. Applies only to histograms.
Further information
Adding Regions to Density Plots and Time
Plots on page 225
Adding Regions to Density Plots and Time
— adds a
Plots on page 225
Adding Regions to Density Plots and Time
Plots on page 225
Adding Regions to Density Plots and Time
Plots on page 225
Adding Bar Regions to Histograms on page
234
