Appendix D ZE5 Cell Analyzer Specifications

Table 44. ZE5 Cell Analyzer specifications, continued
Category
Optics
Electronics
Fluidics
384 | ZE5 Cell Analyzer and Everest Software
Description
Excitation lasers
Detection
Cuvette
Speed
Data processing
Bulk fluids
Sample flow rates
Specification
Up to five spatially separate lasers. Standard
options include:
n
355 nm 50 mW
n
405 nm 100 mW
n
488 nm 100 mW
n
561 nm 50 mW
n
640 nm 100 mW
Up to 30 detectors (PMTs) including:
n
Forward scatter (FSC) detector
n
Optional second FSC detector
n
Side scatter (SSC) detector
n
27 fluorescence detectors
Fused silica with 145 x 265 µm channel
>100,000 events per second with all parameters
enabled
Simultaneous measured peak, area, and width for
every channel
24-bit data for peak and area
17-bit data for width with high-resolution linear
interpolation at the half height
Four 4 L bulk fluid bottles onboard for sheath fluid
and waste
Onboard sheath additive concentrate and cleaner
Optional kit for connecting to house DI water and
waste (field upgrade)
0.1–3.5 µl/sec (6–210 µl/min) (standard mode)
0.5–2.5 µl/sec (30–150 µl/min) (high-throughput
mode)
