1MRK 504 135-UEN A
17.6.2
17.6.3
Table 492: TERMINALID Non group settings (basic)
Name Values (Range)
StationName
StationNumber
ObjectName
ObjectNumber
UnitName
UnitNumber
IEDMainFunType
TechnicalKey
17.7
17.7.1
17.7.2
Technical manual

Functionality

IED identifiers (TERMINALID) function allows the user to identify the individual
IED in the system, not only in the substation, but in a whole region or a country.
Use only characters A-Z, a-z and 0-9 in station, object and unit names.

Settings

Unit
0 - 18 -
0 - 99999 -
0 - 18 -
0 - 99999 -
0 - 18 -
0 - 99999 -
0 - 255 -
0 - 18 -

Product information

Identification

Function description
Product information

Functionality

The Product identifiers function identifies the IED. The function has seven pre-set,
settings that are unchangeable but nevertheless very important:
• IEDProdType
• ProductVer
• ProductDef
• SerialNo
• OrderingNo
• ProductionDate
Step Default
1 Station name
1 0
1 Object name
1 0
1 Unit name
1 0
1 0
1 AA0J0Q0A0
IEC 61850
identification
PRODINF
Section 17
Basic IED functions
Description
Station name
Station number
Object name
Object number
Unit name
Unit number
IED main function type for
IEC60870-5-103
Technical key
IEC 60617 ANSI/IEEE C37.2
identification device number
- -
579
