1MRK 504 135-UEN A
Section 16
16.1
16.2
16.2.1
16.2.2
Technical manual
Station communication

DNP3 protocol

DNP3 (Distributed Network Protocol) is a set of communications protocols used to
communicate data between components in process automation systems. For a detailed
description of the DNP3 protocol, see the DNP3 Communication protocol manual.

IEC 61850-8-1 communication protocol

Identification

Function description
IEC 61850-8-1 communication protocol

Functionality

The IED supports the communication protocols IEC 61850-8-1 and DNP3 over TCP/
IP. All operational information and controls are available through these protocols.
However, some communication functions, for example, horizontal communication
(GOOSE) between the IEDs, is only enabled by the IEC 61850-8-1 communication
protocol.
The IED is equipped with optical Ethernet rear port(s) for the substation
communication standard IEC 61850-8-1. IEC 61850-8-1 protocol allows intelligent
electrical devices (IEDs) from different vendors to exchange information and
simplifies system engineering. Peer-to-peer communication according to GOOSE is
part of the standard. Disturbance files uploading is provided.
Disturbance files are accessed using the IEC 61850-8-1 protocol. Disturbance files are
also available to any Ethernet based application via FTP in the standard Comtrade
format. Further, the IED can send and receive binary values, double point values and
measured values (for example from MMXU functions), together with their quality bit,
using the IEC 61850-8-1 GOOSE profile. The IED meets the GOOSE performance
requirements for tripping applications in substations, as defined by the IEC 61850
standard. The IED interoperates with other IEC 61850-compliant IEDs, and systems
and simultaneously reports events to five different clients on the IEC 61850 station
bus.
Station communication
IEC 61850 IEC 60617
identification identification
IEC 61850-8-1 -
Section 16
ANSI/IEEE C37.2
device number
-
533
