Function Block; Signals; Settings - ABB RET650 Technical Manual

1MRK 504 135-UEN A
17.4.3
17.4.4
17.4.5
Table 489: TESTMODE Non group settings (basic)
Name Values (Range)
TestMode
EventDisable
CmdTestBit
Technical manual
actually set and configured values within the IED. No settings will be changed, thus
mistakes are avoided.
Forcing of binary output signals is only possible when the IED is in test mode.

Function block

TESTMODE
INPUT
IEC09000219-1.vsd
IEC09000219 V1 EN
Figure 256: TESTMODE function block

Signals

Table 487: TESTMODE Input signals
Name
INPUT
Table 488: TESTMODE Output signals
Name
ACTIVE
OUTPUT
SETTING
NOEVENT

Settings

Unit
Off -
On
Off -
On
Off -
On
ACTIVE
OUTPUT
SETTING
NOEVENT
Type Default Description
BOOLEAN 0 Sets terminal in test mode when active
Type Description
BOOLEAN Terminal in test mode when active
BOOLEAN Test input is active
BOOLEAN Test mode setting is (On) or not (Off)
BOOLEAN Event disabled during testmode
Step Default
- Off
- Off
- Off
Section 17
Basic IED functions
Description
Test mode in operation (On) or not (Off)
Event disable during testmode
Command bit for test required or not
during testmode
575
