Settings - ABB RET650 Technical Manual

Section 14
Monitoring
14.1.2.4
Table 329: CVMMXN Non group settings (basic)
Name
Operation
GlobalBaseSel
Mode
PowAmpFact
PowAngComp
k
SLowLim
SLowLowLim
SMin
SMax
SRepTyp
PMin
PMax
PRepTyp
QMin
QMax
QRepTyp
PFMin
PFMax
Table continues on next page
412
Name
I_RANGE
F
F_RANGE

Settings

Values (Range) Unit
Off -
On
1 - 6 -
L1, L2, L3 -
Arone
Pos Seq
L1L2
L2L3
L3L1
L1
L2
L3
0.000 - 6.000 -
-180.0 - 180.0 Deg
0.00 - 1.00 -
0.0 - 2000.0 %SB
0.0 - 2000.0 %SB
0.0 - 2000.0 %SB
0.0 - 2000.0 %SB
Cyclic -
Dead band
Int deadband
-2000.0 - 2000.0 %SB
-2000.0 - 2000.0 %SB
Cyclic -
Dead band
Int deadband
-2000.0 - 2000.0 %SB
-2000.0 - 2000.0 %SB
Cyclic -
Dead band
Int deadband
-1.000 - 1.000 -
-1.000 - 1.000 -
Type Description
INTEGER Calculated current range
REAL System frequency magnitude of deadband value
INTEGER System frequency range
Step Default
- Off
1 1
- L1, L2, L3
0.001 1.000
0.1 0.0
0.01 0.00
0.1 80.0
0.1 60.0
0.1 50.0
0.1 200.0
- Cyclic
0.1 -200.0
0.1 200.0
- Cyclic
0.1 -200.0
0.1 200.0
- Cyclic
0.001 -1.000
0.001 1.000
1MRK 504 135-UEN A
Description
Operation Off / On
Selection of one of the Global Base Value
groups
Selection of measured current and
voltage
Amplitude factor to scale power
calculations
Angle compensation for phase shift
between measured I & U
Low pass filter coefficient for power
measurement
Low limit in % of SBase
Low Low limit in % of SBase
Minimum value in % of SBase
Maximum value in % of SBase
Reporting type
Minimum value in % of SBase
Maximum value in % of SBase
Reporting type
Minimum value in % of SBase
Maximum value in % of SBase
Reporting type
Minimum value
Maximum value
Technical manual
