ABB RET650 Technical Manual page 463

1MRK 504 135-UEN A
Name Values (Range)
InfNo31
FunType32
InfNo32
FunType33
InfNo33
FunType34
InfNo34
FunType35
InfNo35
FunType36
InfNo36
FunType37
InfNo37
FunType38
InfNo38
FunType39
InfNo39
FunType40
InfNo40
Table 376: A4RADR Non group settings (advanced)
Name Values (Range)
NomValue31
UnderTrigOp31
UnderTrigLe31
Table continues on next page
Technical manual
Unit
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
0 - 255 -
Unit
0.0 - 999999.9 -
Off -
On
0 - 200 %
Step Default
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
1 0
Step Default
0.1 0.0
- Off
1 50
Section 14
Monitoring
Description
Information number for analog channel 31
(IEC-60870-5-103)
Function type for analog channel 32
(IEC-60870-5-103)
Information number for analog channel 32
(IEC-60870-5-103)
Function type for analog channel 33
(IEC-60870-5-103)
Information number for analog channel 33
(IEC-60870-5-103)
Function type for analog channel 34
(IEC-60870-5-103)
Information number for analog channel 34
(IEC-60870-5-103)
Function type for analog channel 35
(IEC-60870-5-103)
Information number for analog channel 35
(IEC-60870-5-103)
Function type for analog channel 36
(IEC-60870-5-103)
Information number for analog channel 36
(IEC-60870-5-103)
Function type for analog channel 37
(IEC-60870-5-103)
Information number for analog channel 37
(IEC-60870-5-103)
Function type for analog channel 38
(IEC-60870-5-103)
Information number for analog channel 38
(IEC-60870-5-103)
Function type for analog channel 39
(IEC-60870-5-103)
Information number for analog channel 39
(IEC-60870-5-103)
Function type for analog channel 40
(IEC-60870-5-103)
Information number for analog channel40
(IEC-60870-5-103)
Description
Nominal value for analog channel 31
Use under level trigger for analog channel
31 (on) or not (off)
Under trigger level for analog channel 31
in % of signal
457
