Directional overpower protection GOPPDOP

Identification

Function description
Directional overpower protection

Function block

GOPPDOP
I3P* TRIP
U3P* TRIP1
BLOCK TRIP2
BLKST1 START
BLKST2 START1
START2
PPERCENT
Q
QPERCENT
IEC08000506-2-en.vsd
IEC08000506 V2 EN
Figure 86: GOPPDOP function block

Signals

Table 110: GOPPDOP Input signals
Name Type
I3P GROUP
SIGNAL
U3P GROUP
SIGNAL
BLOCK BOOLEAN
BLKST1 BOOLEAN
BLKST2 BOOLEAN
Table 111: GOPPDOP Output signals
Name Type
TRIP BOOLEAN
TRIP1 BOOLEAN
TRIP2 BOOLEAN
START BOOLEAN
Table continues on next page
IEC 61850
identification
GOPPDOP
P
Default Description
- Three phase group signal for current inputs
- Three phase group signal for voltage inputs
0 Block of function
0 Block of step 1
0 Block of step 2
Description
General trip signal
Trip signal from stage 1
Trip signal from stage 2
General start signal
1MRK 504 135-UEN A
IEC 60617 ANSI/IEEE C37.2
identification device number
32
P >
2
DOCUMENT172362-IMG158942
V2 EN
