Functionality
The OR function is used to form general combinatory expressions with boolean
variables. The OR function block has six inputs and two outputs. One of the outputs
is inverted.
Function block
OR
INPUT1
INPUT2 NOUT
INPUT3
INPUT4
INPUT5
INPUT6
IEC09000288-1-en.vsd
IEC09000288 V1 EN
Figure 167: OR function block
Signals
Table 282: OR Input signals
Name Type
INPUT1 BOOLEAN
INPUT2 BOOLEAN
INPUT3 BOOLEAN
INPUT4 BOOLEAN
INPUT5 BOOLEAN
INPUT6 BOOLEAN
Table 283: OR Output signals
Name Type
OUT BOOLEAN
NOUT BOOLEAN
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).

Inverter function block INVERTER

Identification
Function description
Inverter function block
OUT
Default Description
0 Input signal 1
0 Input signal 2
0 Input signal 3
0 Input signal 4
0 Input signal 5
0 Input signal 6
Description
Output signal
Inverted output signal
IEC 61850
identification
INVERTER
