Section 12
Control
12.6
12.6.1
12.6.2
12.6.3
12.6.4
358
IPOS1 IPOS2
0 0
1 0
0 1
1 1
IEC 61850 generic communication I/O functions
DPGGIO

Identification

Function description
IEC 61850 generic communication I/O
functions

Functionality

The IEC 61850 generic communication I/O functions DPGGIO function block is used
to send double indications to other systems or equipment in the substation using
IEC61850. It is especially used in the interlocking and reservation station-wide logics.

Function block

DPGGIO
OPEN POSITION
CLOSE
VALID
IEC09000075_1_en.vsd
IEC09000075 V1 EN
Figure 155: DPGGIO function block

Signals

Table 252: DPGGIO Input signals
Name Type
OPEN BOOLEAN
CLOSE BOOLEAN
VALID BOOLEAN
Table 253: DPGGIO Output signals
Name Type
POSITION INTEGER
Name of displayed string Default string value
PosUndefined
Position1
Position2
PosBadState
IEC 61850 IEC 60617
identification identification
DPGGIO
Default Description
0 Open indication
0 Close indication
0 Valid indication
Description
Double point indication
1MRK 504 135-UEN A
P00
P01
P10
P11
ANSI/IEEE C37.2
device number
- -
Technical manual
