ABB RET650 Technical Manual page 613

1MRK 504 135-UEN A
Technical manual
Table 525: Output contacts X317, 3U full 19"
Terminal Description
Power output 1, normally open
(TCS)
X317-1 -
X317-2 +
Power output 2, normally open
(TCS)
X317-3 -
X317-4 +
Power output 3, normally open
(TCS)
X317-5 -
X317-6 +
X317-7 Power output 4, normally open
X317-8
X317-9 Power output 5, normally open
X317-10
X317-11 Power output 6, normally open
X317-12
Table 526: Output contacts X321, 3U full 19"
Terminal Description
X321-1 Power output 1, normally open
X321-2
X321-3 Power output 2, normally open
X321-4
X321-5 Power output 3, normally open
X321-6
Table 527: Output contacts X326, 3U full 19"
Terminal Description
X326-1 Power output 1, normally open
X326-2
X326-3 Power output 2, normally open
Table continues on next page
Section 18
IED physical connections
PCM600 info
Hardware module Hardware channel
instance
PSM_102 BO1_PO_TCS
PSM_102 BO2_PO_TCS
PSM_102 BO3_PO_TCS
PSM_102 BO4_PO
PSM_102 BO5_PO
PSM_102 BO6_PO
PCM600 info
Hardware module Hardware channel
instance
BIO_3 BO1_PO
BIO_3 BO2_PO
BIO_3 BO3_PO
PCM600 info
Hardware module Hardware channel
instance
BIO_4 BO1_PO
BIO_4 BO2_PO
607
