Section 12
Control
12.4
12.4.1
12.4.2
352
Function
Time after position change
before the value is accepted
Tap changer constant time-
out
Raise/lower command output
pulse duration
Logic rotating switch for function selection and LHMI
presentation SLGGIO

Identification

Function description
Logic rotating switch for function
selection and LHMI presentation

Functionality

The logic rotating switch for function selection and LHMI presentation SLGGIO (or
the selector switch function block) is used to get an enhanced selector switch
functionality compared to the one provided by a hardware selector switch. Hardware
selector switches are used extensively by utilities, in order to have different functions
operating on pre-set values. Hardware switches are however sources for maintenance
issues, lower system reliability and an extended purchase portfolio. The logic selector
switches eliminate all these problems.
Range or value
(1–60) s
(1–120) s
(0.5–10.0) s
IEC 61850
identification
SLGGIO
1MRK 504 135-UEN A
Accuracy
± 0.5% ± 110 ms
± 0.5% ± 110 ms
± 0.5% ± 110 ms
IEC 60617 ANSI/IEEE C37.2
identification device number
- -
Technical manual
