Function Block; Signals - ABB RET650 Technical Manual

1MRK 504 135-UEN A
14.1.6.2
14.1.6.3
Technical manual

Function block

The available function blocks of an IED are depending on the actual hardware (TRM)
and the logic configuration made in PCM600.
VMSQI
U3P* 3U0
3U0RANG
3U0ANGL
U1
U1RANG
U1ANGL
U2
U2RANG
U2ANGL
IEC08000224-2-en.vsd
IEC08000224 V2 EN
Figure 189: VMSQI function block

Signals

Table 347: VMSQI Input signals
Name Type
U3P GROUP
SIGNAL
Table 348: VMSQI Output signals
Name Type
3U0 REAL
3U0RANG INTEGER
3U0ANGL REAL
U1 REAL
U1RANG INTEGER
U1ANGL REAL
U2 REAL
U2RANG INTEGER
U2ANGL REAL
Default Description
- Three phase group signal for voltage inputs
Description
3U0 Amplitude
3U0 Amplitude range
3U0 Angle
U1 Amplitude
U1 Amplitude range
U1 Angle
U2 Amplitude
U2 Amplitude range
U2 Angle
