Name Type
QA1_EX1 BOOLEAN
QA1_EX2 BOOLEAN
QA1_EX3 BOOLEAN
QB1_EX1 BOOLEAN
QB1_EX2 BOOLEAN
QB1_EX3 BOOLEAN
QB2_EX1 BOOLEAN
QB2_EX2 BOOLEAN
QB2_EX3 BOOLEAN
Table 222: AB_TRAFO Output signals
Name Type
QA1CLREL BOOLEAN
QA1CLITL BOOLEAN
QB1REL BOOLEAN
QB1ITL BOOLEAN
QB2REL BOOLEAN
QB2ITL BOOLEAN
QC1REL BOOLEAN
QC1ITL BOOLEAN
QC2REL BOOLEAN
QC2ITL BOOLEAN
QB1OPTR BOOLEAN
QB1CLTR BOOLEAN
QB2OPTR BOOLEAN
QB2CLTR BOOLEAN
QB12OPTR BOOLEAN
QB12CLTR BOOLEAN
VPQB1TR BOOLEAN
VPQB2TR BOOLEAN
VPQB12TR BOOLEAN

Settings

The function does not have any settings available in Local HMI or Protection and
Control IED Manager (PCM600).
Default Description
0 External condition for apparatus QA1
0 External condition for apparatus QA1
0 External condition for apparatus QA1
0 External condition for apparatus QB1
0 External condition for apparatus QB1
0 External condition for apparatus QB1
0 External condition for apparatus QB2
0 External condition for apparatus QB2
0 External condition for apparatus QB2
Description
Closing of QA1 is allowed
Closing of QA1 is forbidden
Switching of QB1 is allowed
Switching of QB1 is forbidden
Switching of QB2 is allowed
Switching of QB2 is forbidden
Switching of QC1 is allowed
Switching of QC1 is forbidden
Switching of QC2 is allowed
Switching of QC2 is forbidden
QB1 is in open position
QB1 is in closed position
QB2 is in open position
QB2 is in closed position
QB1 or QB2 or both are in open position
QB1 and QB2 are not in open position
Switch status of QB1 is valid (open or closed)
Switch status of QB2 is valid (open or closed)
Switch status of QB1 and QB2 are valid (open or
closed)
