Section 14
Monitoring
14.4.2
14.4.2.1
14.4.2.2
14.4.2.3
14.4.2.4
Table 369: DRPRDRE Non group settings (basic)
Name
Operation
PreFaultRecT
PostFaultRecT
TimeLimit
PostRetrig
Table continues on next page
446
used to get information about the recordings. The disturbance report files may be
uploaded to PCM600 for further analysis using the disturbance handling tool.

Disturbance report DRPRDRE

Identification

Function description
Disturbance report

Function block

DRPRDRE
RECSTART
RECMADE
CLEARED
MEMUSED
IEC09000346-1-en.vsd
IEC09000346 V1 EN
Figure 200: DRPRDRE function block

Signals

Table 368: DRPRDRE Output signals
Name
DRPOFF
RECSTART
RECMADE
CLEARED
MEMUSED

Settings

Values (Range) Unit
Off -
On
0.05 - 9.90 s
0.1 - 10.0 s
0.5 - 10.0 s
Off -
On
IEC 61850
identification
DRPRDRE
DRPOFF
Type
BOOLEAN
BOOLEAN
BOOLEAN
BOOLEAN
BOOLEAN
Step Default
- Off
0.01 0.10
0.1 0.5
0.1 1.0
- Off
1MRK 504 135-UEN A
IEC 60617
identification
-
Description
Disturbance report function turned off
Disturbance recording started
Disturbance recording made
All disturbances in the disturbance report cleared
More than 80% of memory used
Description
Operation Off/On
Pre-fault recording time
Post-fault recording time
Fault recording time limit
Post-fault retrig enabled (On) or not (Off)
ANSI/IEEE C37.2
device number
-
Technical manual
