ABB RET650 Technical Manual page 611

1MRK 504 135-UEN A
Technical manual
Terminal Description
X329-6 Binary input 3 +
X329-7 -
X329-8 Common - for inputs 4-5
X329-9 Binary input 4 +
X329-10 Binary input 5 +
X329-11 -
X329-12 Common - for inputs 6-7
X329-13 Binary input 6 +
X329-14 Binary input 7 +
X329-15 -
X329-16 Common - for inputs 8-9
X329-17 Binary input 8 +
X329-18 Binary input 9 +
Table 523: Binary inputs X334, 3U full 19"
Terminal Description
X334-1 - for input 1
X334-2 Binary input 1 +
X334-3 -
X334-4 Common - for inputs 2-3
X334-5 Binary input 2 +
X334-6 Binary input 3 +
X334-7 -
X334-8 Common - for inputs 4-5
X334-9 Binary input 4 +
X334-10 Binary input 5 +
X334-11 -
X334-12 Common - for inputs 6-7
X334-13 Binary input 6 +
X334-14 Binary input 7 +
X334-15 -
X334-16 Common - for inputs 8-9
X334-17 Binary input 8 +
X334-18 Binary input 9 +
Section 18
IED physical connections
PCM600 info
Hardware module
Hardware channel
instance
BIO_4 BI3
BIO_4 BI4
BIO_4 BI5
BIO_4 BI6
BIO_4 BI7
BIO_4 BI8
BIO_4 BI9
PCM600 info
Hardware module
Hardware channel
instance
BIO_5 BI1
BIO_5 BI1
BIO_5 BI2
BIO_5 BI3
BIO_5 BI4
BIO_5 BI5
BIO_5 BI6
BIO_5 BI7
BIO_5 BI8
BIO_5 BI9
605
