ABB RET650 Technical Manual page 465

1MRK 504 135-UEN A
Name Values (Range)
OverTrigLe36
NomValue37
UnderTrigOp37
UnderTrigLe37
OverTrigOp37
OverTrigLe37
NomValue38
UnderTrigOp38
UnderTrigLe38
OverTrigOp38
OverTrigLe38
NomValue39
UnderTrigOp39
UnderTrigLe39
OverTrigOp39
OverTrigLe39
NomValue40
UnderTrigOp40
UnderTrigLe40
OverTrigOp40
OverTrigLe40
Technical manual
Unit
0 - 5000 %
0.0 - 999999.9 -
Off -
On
0 - 200 %
Off -
On
0 - 5000 %
0.0 - 999999.9 -
Off -
On
0 - 200 %
Off -
On
0 - 5000 %
0.0 - 999999.9 -
Off -
On
0 - 200 %
Off -
On
0 - 5000 %
0.0 - 999999.9 -
Off -
On
0 - 200 %
Off -
On
0 - 5000 %
Step Default
1 200
0.1 0.0
- Off
1 50
- Off
1 200
0.1 0.0
- Off
1 50
- Off
1 200
0.1 0.0
- Off
1 50
- Off
1 200
0.1 0.0
- Off
1 50
- Off
1 200
Section 14
Monitoring
Description
Over trigger level for analog channel 36 in
% of signal
Nominal value for analog channel 37
Use under level trigger for analog channel
37 (on) or not (off)
Under trigger level for analog channel 37
in % of signal
Use over level trigger for analog channel
37 (on) or not (off)
Over trigger level for analog channel 37 in
% of signal
Nominal value for analog channel 38
Use under level trigger for analog channel
38 (on) or not (off)
Under trigger level for analog channel 38
in % of signal
Use over level trigger for analog channel
38 (on) or not (off)
Over trigger level for analog channel 38 in
% of signal
Nominal value for analog channel 39
Use under level trigger for analog channel
39 (on) or not (off)
Under trigger level for analog channel 39
in % of signal
Use over level trigger for analog channel
39 (on) or not (off)
Over trigger level for analog channel 39 in
% of signal
Nominal value for analog channel 40
Use under level trigger for analog channel
40 (on) or not (off)
Under trigger level for analog channel 40
in % of signal
Use over level trigger for analog channel
40 (on) or not (off)
Over trigger level for analog channel 40 in
% of signal
459
