1MRK 504 135-UEN A
16.12.3
16.12.4
16.13
16.13.1
16.13.2
Table 469: ACTIVLOG Non group settings (basic)
Name Values (Range)
ExtLogSrv1Type
ExtLogSrv1Port
ExtLogSrv1IP
Table continues on next page
Technical manual

Function block

PRPSTATUS
LAN1-A
LAN1-B
IEC13000011-1-en.vsd
IEC13000011 V1 EN
Figure 247: PRPSTATUS function block
Table 468: PRPSTATUS Output signals
Name
LAN1-A
LAN1-B

Setting parameters

The PRPSTATUS function has no user settings.
However, the redundant communication is configured in the LHMI under Main
menu/Configuration/Communication/TCP-IP configuration/ETHLAN1_AB
where Operation mode, IPAddress and IPMask are configured.

Activity logging parameters ACTIVLOG

Activity logging ACTIVLOG

ACTIVLOG contains all settings for activity logging.
There can be 6 external log servers to send syslog events to. Each server can be
configured with IP address; IP port number and protocol format. The format can be
either syslog (RFC 5424) or Common Event Format (CEF) from ArcSight.

Settings

Unit
Off -
SYSLOG UDP/IP
SYSLOG TCP/IP
CEF TCP/IP
1 - 65535 -
0 - 18 IP
Address
Type Description
BOOLEAN LAN1 channel A status
BOOLEAN LAN1 channel B status
Step Default
- Off
1 514
1 127.0.0.1
Section 16
Station communication
Description
External log server 1 type
External log server 1 port number
External log server 1 IP-address
553
