Technical manual

Settings

The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).

Operation principle

Upon receiving a signal at its input, IEC61850 generic communication I/O functions
(SPGGIO) function sends the signal over IEC 61850-8-1 to the equipment or system
that requests this signal. To get the signal, PCM600 must be used to define which
function block in which equipment or system should receive this information.
IEC 61850 generic communication I/O functions 16
inputs SP16GGIO

Identification

Function description
IEC 61850 generic communication I/O
functions 16 inputs

Functionality

IEC 61850 generic communication I/O functions 16 inputs SP16GGIO function is
used to send up to 16 logical signals to other systems or equipment in the substation.

Function block

SP16GGIO

BLOCK
^IN1
^IN2
^IN3
^IN4
^IN5
^IN6
^IN7
^IN8
^IN9
^IN10
^IN11
^IN12
^IN13
^IN14
^IN15
^IN16
IEC09000238_en_1.vsd
IEC09000238 V1 EN
Figure 209: SP16GGIO function block
IEC 61850 IEC 60617
identification identification
SP16GGIO -
Section 14
Monitoring
ANSI/IEEE C37.2
device number
-
483
