Operation principle

Disturbance report DRPRDRE is a common name for several functions to supply the
operator, analysis engineer, and so on, with sufficient information about events in the
system.
The functions included in the disturbance report are:
• Event list
• Indications
• Event recorder
• Trip value recorder
• Disturbance recorder
Figure 204 shows the relations between Disturbance Report, included functions and
function blocks. Event list , Event recorder and Indications uses information from the
binary input function blocks (BxRBDR). Trip value recorder uses analog information
from the analog input function blocks (AxRADR). Disturbance recorder DRPRDRE
acquires information from both AxRADR and BxRBDR.
