Section 18
IED physical connections
604
Terminal Description
X304-13 Common - for inputs 10-12
X304-14 Binary input 10 +
X304-15 Binary input 11 +
X304-16 Binary input 12 +
Table 521:
Terminal Description
X324-1 - for input 1
X324-2 Binary input 1 +
X324-3 -
X324-4 Common - for inputs 2-3
X324-5 Binary input 2 +
X324-6 Binary input 3 +
X324-7 -
X324-8 Common - for inputs 4-5
X324-9 Binary input 4 +
X324-10 Binary input 5 +
X324-11 -
X324-12 Common - for inputs 6-7
X324-13 Binary input 6 +
X324-14 Binary input 7 +
X324-15 -
X324-16 Common - for inputs 8-9
X324-17 Binary input 8 +
X324-18 Binary input 9 +
Table 522: Binary inputs X329, 3U full 19"
Terminal Description
X329-1 - for input 1
X329-2 Binary input 1 +
X329-3 -
X329-4 Common - for inputs 2-3
X329-5 Binary input 2 +
Table continues on next page
1MRK 504 135-UEN A
PCM600 info
Hardware module
Hardware channel
instance
COM_101 BI10
COM_101 BI11
COM_101 BI12
PCM600 info
Hardware module
Hardware channel
instance
BIO_3 BI1
BIO_3 BI1
BIO_3 BI2
BIO_3 BI3
BIO_3 BI4
BIO_3 BI5
BIO_3 BI6
BIO_3 BI7
BIO_3 BI8
BIO_3 BI9
PCM600 info
Hardware module
Hardware channel
instance
BIO_4 BI1
BIO_4 BI1
BIO_4 BI2
