ABB RET650 Technical Manual page 56

Section 3
Analog inputs
Name
CTprim4
CTStarPoint5
CTsec5
CTprim5
VTsec6
VTprim6
VTsec7
VTprim7
VTsec8
VTprim8
VTsec9
VTprim9
VTsec10
VTprim10
50
Values (Range) Unit
1 - 99999 A
FromObject -
ToObject
0.1 - 10.0 A
1 - 99999 A
0.001 - 999.999 V
0.001 - 9999.999 kV
0.001 - 999.999 V
0.001 - 9999.999 kV
0.001 - 999.999 V
0.001 - 9999.999 kV
0.001 - 999.999 V
0.001 - 9999.999 kV
0.001 - 999.999 V
0.001 - 9999.999 kV
Step Default
1 1000
- ToObject
0.1 1.0
1 1000
0.001 110
0.001 132
0.001 110.000
0.001 132.000
0.001 110
0.001 132
0.001 110.000
0.001 132.000
0.001 110.000
0.001 132.000
1MRK 504 135-UEN A
Description
Rated CT primary current
ToObject= towards protected object,
FromObject= the opposite
Rated CT secondary current
Rated CT primary current
Rated VT secondary voltage
Rated VT primary voltage
Rated VT secondary voltage
Rated VT primary voltage
Rated VT secondary voltage
Rated VT primary voltage
Rated VT secondary voltage
Rated VT primary voltage
Rated VT secondary voltage
Rated VT primary voltage
Technical manual
