ABB RET650 Technical Manual page 315

1MRK 504 135-UEN A
Technical manual
Name Type
QB62_OP BOOLEAN
QB62_CL BOOLEAN
QC4_OP BOOLEAN
QC4_CL BOOLEAN
QC5_OP BOOLEAN
QC5_CL BOOLEAN
QC3_OP BOOLEAN
QC3_CL BOOLEAN
QC21_OP BOOLEAN
QC21_CL BOOLEAN
EXDU_ES BOOLEAN
QB62_EX1 BOOLEAN
QB62_EX2 BOOLEAN
QB2_EX1 BOOLEAN
QB2_EX2 BOOLEAN
Table 215: DB_LINE Input signals
Name Type
QA1_OP BOOLEAN
QA1_CL BOOLEAN
QA2_OP BOOLEAN
QA2_CL BOOLEAN
QB61_OP BOOLEAN
QB61_CL BOOLEAN
QC1_OP BOOLEAN
QC1_CL BOOLEAN
QC2_OP BOOLEAN
QC2_CL BOOLEAN
QB62_OP BOOLEAN
QB62_CL BOOLEAN
QC4_OP BOOLEAN
QC4_CL BOOLEAN
QC5_OP BOOLEAN
QC5_CL BOOLEAN
QB9_OP BOOLEAN
QB9_CL BOOLEAN
QC3_OP BOOLEAN
Table continues on next page
Default Description
0 QB62 is in open position
0 QB62 is in closed position
0 QC4 is in open position
0 QC4 is in closed position
0 QC5 is in open position
0 QC5 is in closed position
0 QC3 is in open position
0 QC3 is in closed position
0 Earthing switch QC21 on busbar WA2 is in open
position
0 Earthing switch QC21 on busbar WA2 is in closed
position
0 No transmission error from bay containing earthing
switch QC21
0 External condition for apparatus QB62
0 External condition for apparatus QB62
0 External condition for apparatus QB2
0 External condition for apparatus QB2
Default Description
0 QA1 is in open position
0 QA1 is in closed position
0 QA2 is in open position
0 QA2 is in closed position
0 QB61 is in open position
0 QB61 is in closed position
0 QC1 is in open position
0 QC1 is in closed position
0 QC2 is in open position
0 QC2 is in closed position
0 QB62 is in open position
0 QB62 is in closed position
0 QC4 is in open position
0 QC4 is in closed position
0 QC5 is in open position
0 QC5 is in closed position
0 QB9 is in open position
0 QB9 is in closed position
0 QC3 is in open position
Section 12
Control
309
