Section 14
Monitoring
14.2.5
Table 360: CNTGGIO Group settings (basic)
Name
Operation
14.2.6
14.2.7
440
Name
COUNTER5
COUNTER6
RESET
Table 359: CNTGGIO Output signals
Name
VALUE1
VALUE2
VALUE3
VALUE4
VALUE5
VALUE6

Settings

Values (Range) Unit
Off -
On

Monitored data

Table 361: CNTGGIO Monitored data
Name
VALUE1
VALUE2
VALUE3
VALUE4
VALUE5
VALUE6

Operation principle

Event counter (CNTGGIO) has six counter inputs. CNTGGIO stores how many times
each of the inputs has been activated. The counter memory for each of the six inputs
is updated, giving the total number of times the input has been activated, as soon as an
input is activated.
To not risk that the flash memory is worn out due to too many writings, a mechanism
for limiting the number of writings per time period is included in the product. This
Type Default Description
BOOLEAN 0 Input for counter 5
BOOLEAN 0 Input for counter 6
BOOLEAN 0 Reset of function
Type Description
INTEGER Output of counter 1
INTEGER Output of counter 2
INTEGER Output of counter 3
INTEGER Output of counter 4
INTEGER Output of counter 5
INTEGER Output of counter 6
Step Default
- Off
Type Values (Range)
INTEGER -
INTEGER -
INTEGER -
INTEGER -
INTEGER -
INTEGER -
1MRK 504 135-UEN A
Description
Operation Off / On
Unit Description
- Output of counter 1
- Output of counter 2
- Output of counter 3
- Output of counter 4
- Output of counter 5
- Output of counter 6
