Section 14
Monitoring
Y
Value Reported
(1st)
(*)Set value for t: XDbRepInt
IEC05000500 V1 EN
Figure 192: Periodic reporting
430
Value Reported
Y2
Y1
t (*)
Amplitude dead-band supervision
If a measuring value is changed, compared to the last reported value, and the change
is larger than the ±ΔY pre-defined limits that are set by user (UDbRepIn), then the
measuring channel reports the new value to a higher level. This limits the information
flow to a minimum necessary. Figure
band supervision. The picture is simplified: the process is not continuous but the
values are evaluated with a time interval of one execution cycle from each other.
Value Reported
Y3
Y4
t (*) t (*)
193 shows an example with the amplitude dead-
1MRK 504 135-UEN A
Value Reported
Value Reported
Y5
t (*)
en05000500.vsd
Technical manual
