Function Block; Signals; Settings - ABB RET650 Technical Manual

1MRK 504 135-UEN A
12.13.2
12.13.3
12.13.4
Table 273: I103POSCMD Non group settings (basic)
Name Values (Range)
FunctionType
InfNo
Technical manual
The BLOCK input will block only the signals in monitoring direction (the position
information), not the commands via IEC 60870-5-103. The SELECT input is used to
indicate that the monitored apparatus has been selected (in a select-before-operate
type of control)

Function block

I103POSCMD
BLOCK
POSITION
SELECT
IEC10000286-1-en.vsd
IEC10000286 V1 EN
Figure 162: I103POSCMD function block

Signals

Table 272: I103POSCMD Input signals
Name
BLOCK
POSITION
SELECT

Settings

Unit
1 - 255 -
160 - 196 -
Type Default Description
BOOLEAN 0 Block of command
INTEGER 0 Position of controllable object
BOOLEAN 0 Select of controllable object
Step Default
1 1
4 160
Section 12
Description
Fucntion type (1-255)
Information number for command output
(1-255)
Control
369
