Monitored Data - ABB RET650 Technical Manual

1MRK 504 135-UEN A
Name Values (Range)
ILMax
ILRepTyp
ILAngDbRepInt
Table 335: CMMXU Non group settings (advanced)
Name Values (Range)
ILZeroDb
ILHiHiLim
ILHiLim
ILLowLim
ILLowLowLim
ILMin
ILLimHys
IAmpComp5
IAmpComp30
IAmpComp100
IAngComp5
IAngComp30
IAngComp100
14.1.3.5
Technical manual
Unit
0 - 500000 A
Cyclic -
Dead band
Int deadband
1 - 300 Type
Unit
0 - 100000 m%
0 - 500000 A
0 - 500000 A
0 - 500000 A
0 - 500000 A
0 - 500000 A
0.000 - 100.000 %
-10.000 - 10.000 %
-10.000 - 10.000 %
-10.000 - 10.000 %
-10.000 - 10.000 Deg
-10.000 - 10.000 Deg
-10.000 - 10.000 Deg

Monitored data

Table 336: CMMXU Monitored data
Name
IL1
IL1ANGL
IL2
IL2ANGL
IL3
IL3ANGL
Step Default
1 1300
- Dead band
1 10
Step Default
1 500
1 1200
1 1100
1 0
1 0
1 0
0.001 5.000
0.001 0.000
0.001 0.000
0.001 0.000
0.001 0.000
0.001 0.000
0.001 0.000
Type Values (Range)
REAL -
REAL -
REAL -
REAL -
REAL -
REAL -
Section 14
Monitoring
Description
Maximum value
Reporting type
Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
Description
Zero point clamping
High High limit (physical value)
High limit (physical value)
Low limit (physical value)
Low Low limit (physical value)
Minimum value
Hysteresis value in % of range and is
common for all limits
Amplitude factor to calibrate current at 5%
of Ir
Amplitude factor to calibrate current at
30% of Ir
Amplitude factor to calibrate current at
100% of Ir
Angle calibration for current at 5% of Ir
Angle calibration for current at 30% of Ir
Angle calibration for current at 100% of Ir
Unit Description
A IL1 Amplitude
deg IL1 Angle
A IL2 Amplitude
deg IL2 Angle
A IL3 Amplitude
deg IL3 Angle
417
