Section 12
Control
12.1.5
12.1.5.1
12.1.5.2
12.1.5.3
12.1.5.4
262

Bay control QCBAY

Identification

Function description
Bay control

Functionality

The Bay control QCBAY function is used together with Local remote and local
remote control functions to handle the selection of the operator place per bay. QCBAY
also provides blocking functions that can be distributed to different apparatuses within
the bay.

Function block

QCBAY
LR_OFF PSTO
LR_LOC UPD_BLKD
LR_REM CMD_BLKD
LR_VALID LOC
BL_UPD REM
BL_CMD
IEC09000080_1_en.vsd
IEC09000080 V1 EN
Figure 118: QCBAY function block

Signals

Table 187: QCBAY Input signals
Name Type
LR_OFF BOOLEAN
LR_LOC BOOLEAN
LR_REM BOOLEAN
LR_VALID BOOLEAN
BL_UPD BOOLEAN
BL_CMD BOOLEAN
Table 188: QCBAY Output signals
Name Type
PSTO INTEGER
UPD_BLKD BOOLEAN
CMD_BLKD BOOLEAN
LOC BOOLEAN
REM BOOLEAN
IEC 61850 IEC 60617
identification identification
QCBAY -
Default Description
0 External Local/Remote switch is in Off position
0 External Local/Remote switch is in Local position
0 External Local/Remote switch is in Remote
position
0 Data representing the L/R switch position is valid
0 Steady signal to block the position updates
0 Steady signal to block the command
Description
Value for the operator place allocation
Update of position is blocked
Function is blocked for commands
Local operation allowed
Remote operation allowed
1MRK 504 135-UEN A
ANSI/IEEE C37.2
device number
-
Technical manual
